20
Component Feeding
Component Trolley/Fixed Table
Technical Data
Feeder locations
Changeover table with 60 tracks
Fixed table with 60 tracks
60 feeders with SIPLACE SmartFeeder 8mm E
60 feeders with SIPLACE SmartFeeder 8mm E
Changeover table changeover time < 1 minute
Max. component feeding
E by SIPLACE double sided
E by SIPLACE single sided
120 locations for feeders with SIPLACE SmartFeeder 8mm E
60 locations for feeders with SIPLACE SmartFeeder 8mm E
Feeder module types (E by SIPLACE) SIPLACE SmartFeeder E
SIPLACE StickFeeder E
SIPLACE Component Reject Conveyor E
Label Feeder (OEM Product)
Bowl Feeder (OEM Product)
Manual Tray holder E (Speed)
Manual Tray holder E (Flex)
SIPLACE JTF-MW
Feeding capacity
(2 change over tables on the
E by SIPLACE)
120 tape feeder modules, SIPLACE SmartFeeder 8 mm E
60 tape feeder modules, SIPLACE SmartFeeder 2x8 mm E
60 tape feeder modules, SIPLACE SmartFeeder 12 mm E
60 tape feeder modules, SIPLACE SmartFeeder 16 mm E
40 tape feeder modules, SIPLACE SmartFeeder 24 mm E
30 tape feeder modules, SIPLACE SmartFeeder 32 mm E
24 tape feeder modules, SIPLACE SmartFeeder 44 mm E
20 tape feeder modules, SIPLACE SmartFeeder 56 mm E
16 tape feeder modules, SIPLACE SmartFeeder 72 mm E
a
12 tape feeder modules, SIPLACE SmartFeeder 88 mm E
a
a) On request
21
Component Feeding
SIPLACE SmartFeeder E
SIPLACE SmartFeeder E
modules are intelligent tape
feeder modules for flexible
production environments,
which simplify upgrading and
conversion tasks consider-
ably. All SIPLACE Smart-
Feeder E modules support
tape splicing as a standard,
which prevents machine
stoppages when refilling.
The benefits at a glance:
Conversion-friendly
• Omega profiles on the
tape feeder module and
table facilitate safe and
reliable upgrading and
conversion of tape feeder
modules during ongoing
production.
Robust
• Brushless motors extend
the service life of the
SIPLACE SmartFeeder E
modules.
Intelligent
• A unique tape feeder mod-
ule ID ensures a precise
assignment of the compo-
nent to the tape feeder
module. This makes reli-
able setup verification
very simple.
• Component pitch, feeder
speed and other functions
are automatically set
when the setup program is
downloaded.
High feeding accuracy
• Closed loop control path
measurement ensures
highly accurate compo-
nent feeding, even for
01005 placements.
Operator-friendly
• Contactless data and
power transmission make
it easier to attach/remove
the tape feeder modules
• A multicolor status display
signals the operating sta-
tuses of the SIPLACE
SmartFeeder E module:
- Green: "Ready for opera-
tion/in current setup"
- Orange: "Component
runs empty"
- Red: "Malfunction"
- LED off: "Tape feeder
module is not in current
setup and can be torn
down"
Technical data
Tape feeder module L x H
[mm]
Width
[mm]
Location Transport
increment
[mm]
Max. tape
height
[mm]
SIPLACE SmartFeeder 8 mm E 587x200 10.8 1 1/2/4/8 3.5
SIPLACE SmartFeeder 2x8 mm E 587x200 22.9 2 1/2/4/8 3.5
SIPLACE SmartFeeder 12 mm E 587x200 22.6 2 4 - 16
a
16
SIPLACE SmartFeeder 16 mm E 587x200 22.6 2 4 - 20
a
16
SIPLACE SmartFeeder 24 mm E 587x200 34.4 3 4 - 32
a
25
SIPLACE SmartFeeder 32 mm E 587x200 46.2 4 4 - 40
a
25
SIPLACE SmartFeeder 44 mm E 587x200 58.0 5 4 - 52
a
25
SIPLACE SmartFeeder 56 mm E 587x200 69.8 6 4 - 64
a
25
SIPLACE SmartFeeder 72 mm E
b
587x200
81.6
74 - 80
a
25
SIPLACE SmartFeeder 88 mm E
b
587x200
105.2
94 - 96
a
25
Tape reels 178 to 432 mm in diameter (7“ - 19“)
Changeover time ≤ 8 s
a) In 4mm steps
b) On request
22
Component Feeding
Manual Tray Holder
Manual Tray Holder
The Manual Tray Holder is
used at Location 2 of an E by
SIPLACE, to provide tray
support for 2x standard JE-
DEC trays at one time. Com-
ponents can be made
available quickly on JEDEC
trays with the help of the
Manual Tray Holder.
If the Manual Tray Holder is
not present, you can use all
60 feeder tracks on the E by
SIPLACE changeover table
or the fixed table. When the E
by SIPLACE is a single sided
machine, there is a plate (Ar-
bitray Plate E) instead of the
changeover table/fixed table
that allows a Manual Tray
Holder setup.
To use the Manual Tray
Holder on an E by SIPLACE
changeover table, you need
to fit the machine with a mod-
ified empty tape channel.
Technical Data
Occupation of locations on the changeover table/fixed table
Manual Tray holder E Speed
Manual Tray holder E Flex
1 to 32
a
1 to 29
b
a) Tracks 33-60 are available for SIPLACE SmartFeeder E docking
b) Tracks 30-60 are available for SIPLACE SmartFeeder E docking
Configuration in the placement machine
E by SIPLACE Location 2
Placement head range SIPLACE TH, PP, CP14/12/6
Max. waffle pack tray height including components
With SIPLACE TH / SIPLACE PP 25 mm
Manual Tray Holder E
Manual Tray Holder E Flex
Manual Tray Holder E Speed
