主要功能说明
输入 (INPUT) : X3203 #1 CN1 PART
PIN NO. DEF. DESCRIPTION 备注
A1, B1 Y1(Y2)_CW Y1(Y2 ) Axis CW Positive Signal
A2, B2 Y1(Y2)_CW# Y1(Y2) Axis CW Negative Signal
A3, B3 Y1(Y2)_CCW Y1(Y2) Axis CCW Positive Signal
A4, B4 Y1(Y2)_CCW# Y1(Y2) Axis CCW Negative Signal
A5, B5 Y1(Y2)_CLR Y1(Y2) Axis Counter Clear Positive Signal
A6, B6 Y1(Y2)_CLR# Y1(Y2) Axis Counter Clear Negative Signal
A7, B7 +COM +24VDC I/O Power
A8, B8 Y1(Y2)_SON_2#
Y1(Y2) Servo-On Signal (From X3203
Board)
A9, B9 Y1(Y2)_SP1 Y1(Y2) Axis Output 1 Signal
A10, B10 Y1(Y2)_SP2 Y1(Y2) Axis Output 2 Signal
A11, B11 Y1(Y2)_ARM_RST# Y1(Y2) Axis Alarm Reset Signal
A12, B12 Y1(Y2)_ARM_1# Y1(Y2) Axis Alarm Signal
A13, B13 -COM +24VDC I/O Power
A14, B14 Y1(Y2)_INP Y1(Y2) Axis In-Position Signal
A15, B15 -COM +24VDC I/O Power
A16, B16 Y1(Y2)_PA_1
Y1(Y2) Axis Encoder Phase A Positive
Signal
A17, B17 Y1(Y2)_PA_1#
Y1(Y2) Axis Encoder Phase A Negative
Signal
A18, B18 Y1(Y2)_PB_1
Y1(Y2) Axis Encoder Phase B Positive
Signal
A19, B19 Y1(Y2)_PB_1#
Y1(Y2) Axis Encoder Phase B Negative
Signal
A20, B20 Y1(Y2)_PZ_1
Y1(Y2) Axis Encoder Phase Z Positive
Signal
A21, B21 Y1(Y2)_PZ_1#
Y1(Y2) Axis Encoder Phase Z Negative
Signal
A22, B22 GND +5VDC Power(Common Power With VME)
A23, B23 N.C N.C
A24, B24 +5VDC +5VDC Power(Common Power With VME)
A25, B25 N.C N.C
A26, B26 +5VDC +5VDC Power(Common Power With VME)
A27, B27 +5VDC +5VDC Power(Common Power With VME)
A28, B28 Y1(Y2)_CS Not Used.
A29, B29 Y1(Y2)_H_OFF Not Used
CN2
A30, B30 Y1(Y2)_O_HEAT Not Used
7-20
控制单元检验
输出 (OUTPUT) – Y1, Y2 SERVO AMPLIFIER PART
PIN NO. DEF. DESCRIPTION 备注
A1, B1 Y1(Y2)_CW Y1(Y2 ) Axis CW Positive Signal
A2, B2 Y1(Y2)_CW# Y1(Y2) Axis CW Negative Signal
A3, B3 Y1(Y2)_CCW Y1(Y2) Axis CCW Positive Signal
A4, B4 Y1(Y2)_CCW# Y1(Y2) Axis CCW Negative Signal
A5, B5 Y1(Y2)_CLR Y1(Y2) Axis Counter Clear Positive Signal
A6, B6 Y1(Y2)_CLR# Y1(Y2) Axis Counter Clear Negative Signal
A7, B7 +COM +24VDC I/O Power
A8, B8 Y1(Y2)_SON_2# Y1(Y2) Servo-On Signal (To SERVO AMP.)
A9, B9 Y1(Y2)_SP1 Y1(Y2) Axis Output 1 Signal
A10, B10 Y1(Y2)_SP2 Y1(Y2) Axis Output 2 Signal
A11, B11
Y1(Y2)_ARM_RS
T#
Y1(Y2) Axis Alarm Reset Signal
A12, B12 Y1(Y2)_ARM_1# Y1(Y2) Axis Alarm Signal
A13, B13 -COM +24VDC I/O Power
A14, B14 Y1(Y2)_INP Y1(Y2) Axis In-Position Signal
A15, B15 -COM +24VDC I/O Power
A16, B16 Y1(Y2)_PA_2
Y1(Y2) Axis Encoder Phase A Positive
Signal
A17, B17 Y1(Y2)_PA_2#
Y1(Y2) Axis Encoder Phase A Negative
Signal
A18, B18 Y1(Y2)_PB_2
Y1(Y2) Axis Encoder Phase B Positive
Signal
A19, B19 Y1(Y2)_PB_2#
Y1(Y2) Axis Encoder Phase B Negative
Signal
A20, B20 Y1(Y2)_PZ_2
Y1(Y2) Axis Encoder Phase Z Positive
Signal
A21, B21 Y1(Y2)_PZ_2#
Y1(Y2) Axis Encoder Phase Z Negative
Signal
A22, B22 GND +5VDC Power(Common Power With VME)
A23, B23 N.C N.C
A24, B24 +5VDC +5VDC Power(Common Power With VME)
A25, B25 N.C N.C
A26, B26 +5VDC +5VDC Power(Common Power With VME)
A27, B27 +5VDC +5VDC Power(Common Power With VME)
A28, B28 Y1_CS Not Used.
A29, B29 Y1_H_OFF Not Used
CN3
A30, B30 Y1_O_HEAT Not Used
7-21
Samsung Component Placer SM320 Maintenance Reference
基板状态诊断LED信息
LED ON DESCRIPTION Remark LED ON DESCRIPTION Remark
LED1-L
SKEW FAULT INT
ENABLE LED1-H N.C
LED2-L
SKEW CHECK
ENABLE LED2-H
OP INDICATING
LED
LED3-L SKEW CHECK CLR LED3-H N.C
LED4-L Y2_CNT_CLR LED4-H N.C
LED5-L Y1_CNT_CLR LED5-H N.C
LED6-L Y2_CNT_ENABLE LED6-H N.C
LED7-L Y1_CNT_ENABLE LED7-H N.C
SWITCH 及 JUMPER SETTING信息
SWITCH1 DESCRIPTION Remark SWITCH1 DESCRIPTION Remark
SW 1 OFF SW 2 OFF
SW 3 OFF SW 4
OFF
SW 5 ON SW 6
ON
SW 7 ON SW 8 ON
SWITCH2 DESCRIPTION Remark SWITCH2 DESCRIPTION Remark
SW 1 OFF SW 2 ON
SW 3 OFF SW 4
OFF
SW 5
OFF
SW 6
OFF
SW 7
OFF
SW 8
OFF
JUNPER DESCRIPTION Remark JUMPER DESCRIPTION Remark
JP2 2 – 3 Connected JP3 1 – 2 Connected
JP4 1 – 2 Connected JP5 2 – 3 Connected
