PRECISION WAFER PALLET REPLACEMENT PROCEDURES Chapter Issue 1 Aug 11 Wafer Transport Solutio n 2.17 Figure 2-9 300mm Wafer Pallet V acuum T ubing Shim V acuum Shim V acuum Lift Pin V acuum Switched V acuum Supply (Pin) S…
PRECISION WAFER PALLET
REPLACEMENT PROCEDURES
2.16 Wafer Transport Solution Chapter Issue 1 Aug 11
Figure 2-8 300mm Wafer Pallet
Connector Chart
2 Stacked Elbows 201141
Y Union 169265 with 2
Reducers 189520
Delta Union 201137
Elbow 201138
Elbow 201138
Branch T 201139
Branch T 201139
Push Fit Joint 201143
T Connector 201140
Branch T 201139
T Connector 201140
Elbow 201138
Branch T 201139
Elbow 201138
Elbow 201138
Branch T 201139
Union Y 169265
Delta Union 201137
Reducer 189520
Push Fit Joint 201143
T Connector 201140
Union Elbow 201141
PRECISION WAFER PALLET
REPLACEMENT PROCEDURES
Chapter Issue 1 Aug 11 Wafer Transport Solution 2.17
Figure 2-9 300mm Wafer Pallet Vacuum Tubing
Shim Vacuum
Shim Vacuum
Lift Pin Vacuum
Switched Vacuum
Supply (Pin)
Switched Vacuum
Supply (Wafer)
Vacuum
Supply (Shim)
PRECISION WAFER PALLET
REPLACEMENT PROCEDURES
