Instruction manual SIPLACE X-Series S 2 Operational safety From software version 713.0 Edition 11/2019 2.3 Classification of camera systems 65 2.3.2 Classification of the camera systems 2.3.2.1 Camera types with bright L…
2 Operational safety Instruction manual SIPLACE X-Series S
2.3 Classification of camera systems From software version 713.0 Edition 11/2019
64
2.3 Classification of camera systems
2.3.1 Classification of the whole machine
2
2.3.1.1 Laser classification
The following modules are assigned to risk class 2:
2
The following modules are assigned to laser class 3B:
2
The ready-for-operation placement machine is assigned to risk class 2.
The risk classes are determined according to IEC 60825-1:2014.
Assembly Data
Component sensor on SpeedStar Maximum optical output power: < 1 mW
Wavelength: 635 nm
Component sensor on the SIPLACE Multis-
tar CPP
Maximum optical output power: < 1 mW
Wavelength: 635 nm
Laser light barrier on PCB conveyor Maximum optical output power: < 1 mW
Wavelength: 650 nm
1D board barcode reader
(Datalogic DS1500)
Maximum optical output power: --
Wavelength: 658
Assembly Data
3D coplanarity laser module Maximum optical output power: 60 mW
Wavelength: 670 nm
See also section 6.8
3D coplanarity laser module,
page 330
.
Instruction manual SIPLACE X-Series S 2 Operational safety
From software version 713.0 Edition 11/2019 2.3 Classification of camera systems
65
2.3.2 Classification of the camera systems
2.3.2.1 Camera types with bright LEDs - risk group 1
The bright LEDs are fitted in the following cameras. These are classified as risk group 1, according
to IEC 62741:.
– Component camera type 23, 30, 41 and 45
– Stationary component camera type 25 and 33
– PCB camera, type 28
2
2.3.2.2 Camera types with blue LEDs - risk group 2
The ultra-bright blue LEDs are fitted in the following cameras. These are classified as risk group
2, according to IEC 62741:.
– Component camera, type 48
2
PLEASE NOTE
Risk group 1
Do not look into the beam of the ready-for-operation camera!
2
Risk group 2
The beam from cameras with ultra-bright blue LEDs can be a haz-
ard.
Do not look into the beam of the ready-for-operation camera!
2 Operational safety Instruction manual SIPLACE X-Series S
2.4 Safety instructions for transporting the placement machine From software version 713.0 Edition 11/2019
66
2.4 Safety instructions for transporting the placement
machine
2
Use a fork-lift truck with the following specification to carry the placement machine:
Fork length: Min. 1800 mm
Carrying power: Min. 6,000 kg
Clear width between forks: Min. 350 mm 2
2
WARNING
Risk of tilting!
Risk of tilting, if the required specifications for the fork-lift truck are not observed.
Only use the specified fork-lift for transportation.
Transportation of the placement machine is described in chapter 4
, section 4.1, page
183
.
