2 Operational safety Instruction manual SIPLACE X-Series S 2.2 Warning labels From software version 713.0 Edition 11/2019 44 2.2.3 Meaning and description of warning labels (default labeling) 2.2.3.1 Information sign M00…
Instruction manual SIPLACE X-Series S 2 Operational safety
From software version 713.0 Edition 11/2019 2.2 Warning labels
43
2.2.2 Warning labels in the placement machine (default label)
Fig. 2.2 - 3 Warning labels in the placement machine (example of SIPLACE X4i S shown) default labeling
Item W 024, item no. 03155346-01
Item W 006, item no. 03155812-01
(1) Warning strips
(T) Direction of travel
The warning labels are attached to the inside of the metal cover panels.
1
1
W 024
W 024
W 024
W 024
W 006
W 006
2 Operational safety Instruction manual SIPLACE X-Series S
2.2 Warning labels From software version 713.0 Edition 11/2019
44
2.2.3 Meaning and description of warning labels (default labeling)
2.2.3.1 Information sign M002
2
Item M 002 in fig. 2.2 - 1, page 41, item no. 3155798-01 or
Item M 002 in fig. 2.2 - 4
, page 48, item no. 3155798-01
(Quantity per placement machine: 1)
2.2.3.2 Warning label laser class 2
2
Item W Laser class 2 in fig. 2.2 - 1, page 41, item no. 03155298-01
(Quantity per placement machine: 1)
2.2.3.3 Warning label W 024
2
W 024 in fig. 2.2 - 1, page 41 and 2.2 - 2, page 42, item no. 03155346-01
(Quantity per placement machine: 16)
2
2
2
2
2
2
2
2
Safe operation of placement machine
Safe operation of the placement machine depends absolutely on
the operator being familiar with the instruction manual and safety
instructions and putting them into effect.
2
2
2
LASER RADIATION
Laser class 2
Acc. to IEC 60825-1:2014
Do not look into beam!
2
2
2
Warning about hand injuries
Reaching in here can lead to injuries to the arms and hands.
Do not reach into the running placement machine.
Do not reach into the inside of the adjacent placement ma-
chine
Instruction manual SIPLACE X-Series S 2 Operational safety
From software version 713.0 Edition 11/2019 2.2 Warning labels
45
2.2.3.4 Warning label W 012
2
W 012 in fig. 2.2 - 1, page 41, item no. 03155378-01 or
W 012 in fig. 2.2 - 4
, page 48, item no. 03155378-01
(Quantity per placement machine: 1)
2.2.3.5 Warning label W 210
2
W 210 in fig. 2.2 - 1, page 41 and 2.2 - 2, page 42, item no. 03009350-01
(Quantity per placement machine: 2)
2.2.3.6 Warning label W 209
2
W 209 in fig. 2.2 - 1, page 41 and 2.2 - 2, page 42, item no. 03009349-01
(Quantity per placement machine: 2)
Dangerous voltages
Marked parts are initially still live when the main power switch is off
and the mains plug has been disconnected.
Disconnect the placement machine from the mains before opening
the cover.
NAFTA region: RISK OF ELECTRIC SHOCK OR BURN!
2
2
2
2
2
2
Warning label on the EMERGENCY STOP button
2
2
2
2
2
2
2
2
2
2
For Australia, Canada, Mexico and USA, warning label
W209 is affixed to the extension kit instead of the yellow
ring on the EMERGENCY STOP buttons.
