2 Operational safety Instruction manual SIPLACE X-Series S
2.2 Warning labels From software version 713.0 Edition 11/2019
52
2.2.7 Warning label W 205 on tape cutter
2
Fig. 2.2 - 7 Warning label W 205 on the top of the tape cutter
Item W 205, item no. 03009344-01
2
2
WARNING
Risk of cuts!
Risk of cuts from sharp blades when working on the tape cutter!
Wear robust protective gloves when working on the tape cutter.
WARNING
Risk of injuries!
Risk of injuries from pressurized compressed-air lines when working on the tape cutter.
Disconnect the placement machine from the mains supply and the compressed air
supply, before you start work on the tape cutter.
Wait until the operating pressure has dropped to 0 MPa.
W 205
Instruction manual SIPLACE X-Series S 2 Operational safety
From software version 713.0 Edition 11/2019 2.2 Warning labels
53
2.2.7.1 Warn label W 205 on the used tape chute
2
Fig. 2.2 - 8 Warn label W 205 on the used tape chute
Item W 205, item no. 03009344-01
2.2.7.2 Warning label W 205
Warning labels on tape cutter and used tape chute
2
W 205 in fig. 2.2 - 7, page 52 and 2.2 - 8, page 53, item no. 03009344-01 (quantity per placement
machine: 8)
W 205
2
2
2
2
2
2
2
2
RISK OF CUTTING!
There is still a risk of getting cut when the placement machine is
switched off
2 Operational safety Instruction manual SIPLACE X-Series S
2.2 Warning labels From software version 713.0 Edition 11/2019
54
2.2.8 Warning labels on the power supply unit
2
W 220 in fig. 2.2 - 9, page 54, item no. 03114591-01 (quantity per placement machine: 4).
Fig. 2.2 - 9 Warning label W 220 on the power supply
– W 220 on the capacitor battery PCS417
– W 220 on the power supply AC/DC converters (160 V DC /300 V DC).
– W 220 on the cover of the safety cutoff (CSB)
2
2
MAIN POWER VOLTAGE!
Switch off the main power switch, unplug the power supply and
wait 5 minutes until the capacitors have discharged.
NAFTA region: RISK OF ELECTRIC SHOCK OR BURN!
W 220
W 220
