5 6-monthly CPP Lubricate the Z-axis support roller 1 min 1 / 2 CAUTION!Refer to safety instructions in user manual before commencing Mainten- ance NOTICE! ESD guidelines are to be followed Tool: T22, T25 Wear Part: Con…
4 6-monthly CPP Exchange / maintain the PRV 2 min 2 / 2
CAUTION!Refer to safety instructions in user manual before commencing Mainten-
ance
NOTICE! ESD guidelines are to be followed Tool:
T12, T47, T79
Wear Part: Consumables:
7 Place the mounting plate and fasten both
screws.
8 Press the two clips at the side and con-
nect the ribbon cable properly.
9 Mount the cable clamp.
10 Put the completed PRV to the side until
you are prompted to take it up again in a
later task.
5 6-monthly CPP Lubricate the Z-axis support roller 1 min 1 / 2
CAUTION!Refer to safety instructions in user manual before commencing Mainten-
ance
NOTICE! ESD guidelines are to be followed Tool:
T22, T25
Wear Part: Consumables:
C12
1 Put the front plate flat on the table with the
race way pointing up.
2 Only required for heads with a service
hole at the inside of the front plate. For all
other heads skip this task.
3 Prepare the multipette. See appendix
"Prepare the multipette.
4 Turn the wheel and adjust 1 µl. 5 For proper lubrication press the Z-Axis to
the upper stop to move the bearing below
the service hole.
6 Insert the combitip into the service hole
and apply 1 x 1 μl.
5 6-monthly CPP Lubricate the Z-axis support roller 1 min 2 / 2
CAUTION!Refer to safety instructions in user manual before commencing Mainten-
ance
NOTICE! ESD guidelines are to be followed Tool:
T22, T25
Wear Part: Consumables:
C12
7 Move the Z-axis 5 times up and down. 8 Clean up the multipette. See appendix
"Clean-up the multipette".
