19 6-monthly CPP Finish the head maintenance 1 min 1 / 1 CAUTION!Refer to safety instructions in user manual before commencing Mainten- ance NOTICE! ESD guidelines are to be followed Tool: T3, T7, T8, T9, T21, T42, T58 …
18 6-monthly CPP Clean the component sensor 1 min 2 / 2
CAUTION!Refer to safety instructions in user manual before commencing Mainten-
ance
NOTICE! ESD guidelines are to be followed Tool:
T14, T21
Wear Part: Consumables:
C5, C22
7 Mount the component sensor protection.
19 6-monthly CPP Finish the head maintenance 1 min 1 / 1
CAUTION!Refer to safety instructions in user manual before commencing Mainten-
ance
NOTICE! ESD guidelines are to be followed Tool:
T3, T7, T8, T9, T21, T42, T58
Wear Part: Consumables:
C3, C5, C21
1 Remove the maintenance label. 2 Clean the area of the label. 3 Write the maintenance date onto a new la-
bel and attach it to the head.
4 Remove the 2 screws to take the head
from the head stand.
5 Place the head into the transport con-
tainer.
