Installation Manual SIPLACE Setup Center 2.2
1 Introduction
Please read chapters 2 through 6 before you install SIPLACE Setup Center. Chapter 5 describes
the installation sequence for SIPLACE Setup Center as well as the related setup types and
important information regarding the installation.
5 of 90
1.1 Explanation of symbols
Various symbols and notes are used for making this document easier to read.
11
Words in bold/italics
These are dialog boxes and menu commands.
Step …
An installation step includes all the actions relating to a specific dialog
box. An installation step may be composed of several actions.
→
Requires an action (e.g. mouse click, open file)
Corresponds to a warning. The information is critical to the success
of the installation process. The installation will be cancelled if you do
not comply with the warning.
Explanatory information about the installation sequence.
-
Installation Manual SIPLACE Setup Center 2.2
2 Scope of Delivery
2.1 Setup Center Basic Package
2.1.1 Software package:
The basic software package SIPLACE Setup Center (Item No. 116920-01) contains the
following components:
1) 1 CD-ROM “SIPLACE Setup Center 2.2”, which contains:
• SIPLACE Setup Center Setup
• Microsoft MSDE SP3a and higher
• Sontheim PCI CAN Driver V3.038
2) 1 CD-ROM “Activation CD Forced Setup Control and CLI” (Item No. 00382442-01)
Activate the forced setup verification and component level indicator for the station software
versions:
• 407.04 SP1 and higher
• 503.04 SP2 and higher
• 505.03 SP1 and higher
• 601.03 SP1 and higher
3) 1 CD-ROM “Mobi Patch SMV 1.3” (Item No. 00382370-01) for the station software versions
407, 503, 505. The patch is also included in the following packages:
00116941-01 Retrofitting Kit SMV to Setup Center
00355970-11 Software SIPLACE Station 407.04SP1A
00361986-11 Software SIPL Station Update 407.04SP1A
00368292-10 Software SIPLACE Station 503.04SP2A
00368293-10 Software SIPL Station Update 503.04SP2A
00375294-05 Software SIPL Station 505.03SP1A Update
00375295-07 Software SIPLACE Station505/6-505.03SP1A
6 of 90
Installation Manual SIPLACE Setup Center 2.2
4) Basic documents
• "Getting Started with SIPLACE Setup Center 2.2"
(Item No. 00195469-01 [German], 00195468-01[English])
• "Software Version Description SIPLACE Setup Center 2.2"
(Item No. 0095466-01 [English, German])
• "Installation Manual SIPLACE Setup Center 2.2"
(Item No. 00195467-01 [English])
• “Installation Manual SIPLACE Setup Center 2.1 SIPLACE Setup Selection Assistant"
(Item No. 00194703-01 [English])
• “Installation Manual SIPLACE Setup Center 2.1 SIPLACE Trace Config Assistant"
(Item No. 00194702-01 [English])
2.1.2 Hardware package:
• 1 DATALOGIC DRAGON™ M101/D 433MHz Barcode Scanner
• 1 DATALOGIC OM-DRAGON™ Radio Cradle
• 1 Serial Cable
• 1 Power Supply
7 of 90
2.2 Optional: Docking Station
Hardware package:
• CAN BUS – PCI card:
CAN BUS card for Setup Center PC Item No.: 00116931-01
– 1 Power CAN PCI card for SC
– 1 CAN BUS cable for up to 4 docking stations
• X docking station:
Docking station for SIPLACE X component trolley Item No.: 00116933-01
– 1 docking station for X-series
– 1 power supply cable 230 V AC (EU)
– 1 power supply cable 125 V AC (US)
– 1 pneumatic connection coupling
-
