Track and Process Error: Error Messages Concerning One or Both Feeder Module Tracks Messages for 2x8 mm Feeder Modules

User Manual X Feeder Modules SIPLACE Family 81

5.1.2 Track and Process Error: Error Messages Concerning One or Both Feeder Module

Tracks

NOTICE

If an error simultaneously occurred on both feeder module tracks, the display patterns de-

scribed are active for the left and the right track. In contrast to a module error of the feeder mod-

ule control unit, however, all 8 pitch LEDs never flash simultaneously.

Status Dis-

play

Pitch display Cause Solution

Lights up or-

ange

All LEDs

flash fast

Warning: You have selected a

function which is invalid in the

current feeder module state:

▪ Tape conveyor backwards

when the foil is tensioned

▪ Tensioning foil when foil is

already tensioned

This status is displayed when a

button has been pressed and

vanishes when the button has

been released.

If you want to perform this function,

remove the foil from the pair of toothed

wheels and cut it, to relax the foil

rocker.

Messages

Messages for 2x8 mm Feeder Modules Track and Process Error: Error Messages Concerning One or Both Feeder Mod-

82 User Manual X Feeder Modules SIPLACE Family

Lights up red LED 8 flash-

es slowly

Conveyor error: Tape feeding cy-

cle was not correctly completed

within the prescribed time.

▪ Is the tape reel trapped in the

container?

▪ Is the component trapped in

the pickup area, between the

tape and the component win-

dow?

Once the obstacle has been elimi-

nated, use the FORWARDS and

BACKWARDS buttons to restart the

conveyor.

The feeder module will finish the faulty

feed run and will return to its correct

position.

LED 2 flash-

es slowly

Foil torn: Foil was not tensioned

within the specified time:

▪ The foil is torn.

▪ The foil container is full.

▪ Contaminants or foil residues

prevent pressure of the foil

disposal rolls.

▪ Insert and tighten foil again.

▪ Empty the foil container.

▪ Check the foil disposal rolls for

contamination and clean them, if

necessary.

LED 1 flash-

es slowly

Foil stripper: Foil not pulled off

while tape gets transported. The

cover foil has probably been

trapped under the pickup window

and therefore not stripped off

properly.

Check if the cover foil is jammed under

the pickup window.

One LED

lights up

(current

pitch)

Process error: The station com-

puter sent an error message to

this feeder module track. The

error source is therefore not in the

feeder module but usually in the

placement machine.

The graphical user interface (GUI) of

the placement machine displays a de-

tailed description of the error source.

Status Dis-

play

Pitch display Cause Solution

Messages

Flow Chart: Error Display on the Operator Panel Messages for 2x8 mm Feeder Modules

User Manual X Feeder Modules SIPLACE Family 83

5.1.3 Flow Chart: Error Display on the Operator Panel

The flow chart shows the logic according to which the errors are divided into the individual types. It

should help to identify an error.
