Messages

Messages Sent by the Feeder Module Messages for 8 - 88 mm Feeder Modules

User Manual X Feeder Modules SIPLACE Family 85

5.2.1.6 Handle

5.2.1.7 Logging Off

5.2.1.8 Waiting for Log Off

5.2.1.9 Voltage Too Low 1

5.2.1.10 Voltage Too Low 2

LCD, de:

LCD, en:

Griff --->>

Handle --->>

Status display: Red

Cause: The feeder module has been logged in but the removal handle has not yet been

engaged (pushed in).

Solution: Push in the handle until it engages.

Comments: If the handle does not engage properly, send the feeder module to ASM Assembly

Systems for repair.

LCD, de:

LCD, en:

Abmelden

Logging Off

Status display: lights up red briefly

Cause: The feeder module is logging off at the FCU. This display will normally only appear

briefly and you usually won't see it. If it is clearly visible, there is probably a mal-

function.

Solution: Error in the FCU, on fibre optic cable, CAN bus

LCD, de:

LCD, en:

Wait Log Off

Status display: orange

Cause: The feeder module is logging off at the FCU. This display will normally only appear

briefly and you usually won't see it. If it is clearly visible, there is probably a mal-

function.

Solution: Error in the FCU, on fibre optic cable, CAN bus

LCD, de:

LCD, en:

Spg. niedrig

Low Voltage

Status display: orange

Cause: 24 V supply voltage has not reached the switching on threshold after being

switched on.

Solution: Check voltage supply of the component table, check EDIF

LCD, de:

LCD, en:

Spg. niedrig

Low Voltage

Status display: red

Cause: 24 V supply voltage has exceeded the switching on threshold and has then

collapsed.

Solution: Check voltage supply of the component table, check EDIF

Messages

Messages for 8 - 88 mm Feeder Modules Messages Sent by the Feeder Module

86 User Manual X Feeder Modules SIPLACE Family

5.2.1.11 Feed Error 1

5.2.1.12 Feed Error 2

5.2.1.13 Feed Time Exceeded

5.2.1.14 Torn Foil

5.2.1.15 Foil Stripper

LCD, de:

LCD, en:

Transp.Fehl.

Feed Error

Status display: red

Cause: Tape feeding cycle was not correctly completed within the prescribed time. Is the

tape reel jammed in the container? Is the component trapped in the pickup area,

between the tape and the component window?

Solution: Once the obstacle has been eliminated, use the arrow keys to restart the conveyor.

The feeder module will finish the faulty feed run and will return to its correct posi-

tion.

LCD, de:

LCD, en:

Feed Timeout

Status display: red

Comments: From software version 1.14 on the error text Feed Timeout was replaced

by Feed Error, making it clearer that the last positioning attempt was un-

successful and that the component is not in its correct position.

See Feed Error or Transp. Fehl.

LCD, de:

LCD, en:

TransTimeout

Status display: red

Cause: The tape drive does not issue a reply signal in the prescribed time. Is the tape reel

jammed in the container? Is the component trapped in the pickup area, between

the tape and the component window?

Solution: Once the obstacle has been eliminated, use the arrow keys to restart the conveyor.

The feeder module will finish the faulty feed run and will return to its correct posi-

tion.

LCD, de:

LCD, en:

Folienriss

Foil Torn

Status display: red

Cause: Foil was not tensioned within the prescribed time. It has probably been torn.

Solution: Reinsert the foil and re-tension it.

LCD, de:

LCD, en:

Folienabzug

Foil PeelErr

Status display: red

Cause: Foil has not been correctly stripped off, although the tape is being fed in. The cover

foil has probably been trapped under the pickup window and therefore not stripped

off properly.

Solution: Reinsert the foil and re-tension it. Empty the foil container.

Messages

Messages Sent by the Feeder Module Messages for 8 - 88 mm Feeder Modules

User Manual X Feeder Modules SIPLACE Family 87

5.2.1.16 Foil Jam

5.2.1.17 Remove the Foil

5.2.1.18 CAN Bus Error

5.2.1.19 Boot Error

5.2.1.20 Data Flash Error

LCD, de:

LCD, en:

Folienstau

Foil Jam

Status display: red

Cause: The foil motor is blocked because the foil disposal rolls are unable to move easily.

They are probably being blocked by the trapped foil

Solution: Remove the foil, empty the foil container and clean the foil disposal rolls.

LCD, de:

LCD, en:

Folie entf.

Remove Foil

Status display: orange

Cause: You have selected a function which is invalid while the cover foil is tensioned. The

foil rocker has been pushed down.

Solution: If you want to perform this function, remove the foil from the pair of toothed wheels

and cut it, to relax the foil rocker.

LCD, de:

LCD, en:

CANBusFehler

CANBusError

Status display: Red

Cause: CAN bus error, the feeder module is unable to communicate with the machine

(FCU).

Solution: Log out and on again, check the fibre optic cable interface.

If a reset does not help, please send the feeder module to ASM Assembly

Systems.

Comments: Clean the fibre optic cable interface

The fibre optic cable is a transparent plastic cable for transmitting light

Note: Include the component table in your error search!

LCD, de:

LCD, en:

BootFlashErr

Status display: red

Cause: Unable to correctly write data in boot or application memory.

Solution: Repeat the download of the boot software.

If the error persists: Download the application software first and then the boot soft-

ware.

If the error persists: Replace the control board of the feeder module.

Comments: This error will only appear during of after a boot software download.

LCD, de:

LCD, en:

DataFlashErr

Status display: red

Cause: Unable to write data in the data memory

Solution: Log the feeder module out and on.

If the error persists: Replace the control board of the feeder module.

Comments: The display text may also be FlashDataErr.
