Messages Messages From Process Messages for 8 - 88 mm Feeder Modules User Manual X Feeder M odules SIPLACE Family 89 5.2.1.26 EEPROM Data Error 5.2.1.27 Scan Request 5.2.2 Messages From Process 5.2.2.1 Introduction The f…

Messages

Messages for 8 - 88 mm Feeder Modules Messages Sent by the Feeder Module

88 User Manual X Feeder Modules SIPLACE Family

5.2.1.21 Download Boot

5.2.1.22 Update Boot

5.2.1.23 New Parameters

5.2.1.24 EEPROM Read Error

5.2.1.25 EEPROM Write Error

LCD, de:

LCD, en:

DownloadBoot

Status display: red

Cause: Data are being written from the data memory into the cache memory.

Solution: Wait

LCD, de:

LCD, en:

Update Boot

Status display: red

Cause: Data are being written from the cache memory into the boot memory.

Solution: Wait

LCD, de:

LCD, en:

ParameterNeu

New Default

Status display: orange

Cause: The feeder module software is automatically setting default parameters. This is

performed, for example, after loading new software and takes approx. 5 seconds.

Solution: Wait

LCD, de:

LCD, en:

EEP-ReadErr

Status display: red

Cause: Data was not read from the EEPROM correctly

Solution: Remove the tape. Acknowledge the error with the SET button. Then acknowledge

the request to perform a reference run with the yellow button. If this message con-

tinues to appear, you will need to replace the control board or the drive.

Comments: Since the position of the drive is stored in the EEPROM, a reference run is

necessary in these cases.

LCD, de:

LCD, en:

EEP-WriteErr

Status display: red

Cause: Data backup has not been performed correctly in the EEPROM.

Solution: Remove the tape. Acknowledge the error with the SET button. Then acknowledge

the request to perform a reference run with the yellow button. If this message con-

tinues to appear, you will need to replace the control board or the drive.

Comments: Since the position of the drive is stored in the EEPROM, a reference run is

necessary in these cases.

Messages

Messages From Process Messages for 8 - 88 mm Feeder Modules

User Manual X Feeder Modules SIPLACE Family 89

5.2.1.26 EEPROM Data Error

5.2.1.27 Scan Request

5.2.2 Messages From Process

5.2.2.1 Introduction

The following messages are only shown by the feeder module. The display text itself is generated by the

station computer and is then transmitted via the CAN bus to the LCD display of the feeder module. The

error source is therefore not in the feeder module but usually in the placement machine state. For exam-

ple, pickup or Vision errors, which affect the component of a particular track, will be displayed on the

feeder module for that track. The following table shows the LCD display text, the color and mode of the

status display, the cause and troubleshooting measures.

5.2.2.2 Not Verified

5.2.2.3 Scan Barcode

LCD, de:

LCD, en:

EEP-DataErr

Status display: red

Cause: The data back-up in the EEPROM was not carried out completely

Solution: Remove the tape. Acknowledge the error with the SET button. Acknowledge the

prompt for a reference run with the yellow button.

If the message continues to appear, you will need to replace the control board or

the drive.

Comments: Since the position of the drive is stored in the EEPROM, a reference run is

necessary in these cases.

LCD, de:

LCD, en:

Scan Anford.

Scan Request

Status display: - - -

Cause: The request to perform scanning has been sent by the feeder module to the MC

(Machine Controller).

Solution: - - -

Comments: After the grey SET button has been pressed (1 sec.) the display shows the

Scan Anford. / Scan Request message for approx. 2 sec. to indicate that

the feeder module has sent a request for barcode scanning to the MC. If a barcode

system is active, the MC will then send the Scan Barcode display text to the

feeder module.

From version 1.24

LCD, de:

LCD, en:

NichtGeprueft

Not verified

Status display:

Cause: The tape has been inserted but the barcode has not yet been scanned.

Solution: Scan the barcode.

Comments: This message is only shown if a barcode system has been installed and is active.

LCD, de:

LCD, en:

Scan Barcode

Status display:

Cause: The barcode still needs to be scanned.

Solution: Scan the barcode.

Comments: - - -

Messages

Messages for 8 - 88 mm Feeder Modules Messages From Process

90 User Manual X Feeder Modules SIPLACE Family

5.2.2.4 Scan OK

5.2.2.5 Scan Error

5.2.2.6 Fill level Too Low

5.2.2.7 Splice Sensor

5.2.2.8 Vision Error

LCD, de:

LCD, en:

Scan OK

Status display:

Cause: Barcode scanning was successful.

Solution: - - -

Comments: - - -

LCD, de:

LCD, en:

Scan Fehler

Scan Not OK

Status display:

Cause: Barcode scanning was not successful.

Solution: Scan the barcode again.

Comments: Check the quality of the barcode label.

LCD, de:

LCD, en:

Fuell. Niedrig

Low Filling

Status display:

Cause: Warning issued when fill level is too low

Solution: Splice on new component reel and update fill level.

Comments: This message is only shown if a component level indicator has been installed and

is active.

LCD, de:

LCD, en:

SpleissSensor

SpliceSensor

Status display:

Cause: Warning issued when the splice sensor is missing.

Solution: Provide a feeder module with splice sensor or switch off the component level indi-

cator in the station software, if this is not being used.

Comments: The splice sensor in a feeder module is only required by the placement machine if

a component on this track is subject to a component level indicator or traceability

function.

LCD, de:

LCD, en:

VisionFehler

Vision Error

Status display:

Cause: The component on this track has not been correctly recognized by the image

processing tool or the component is defective.

Solution: Check the geometry of the component with the Vision data

Comments: This requires an exact analysis of the pickup process, as this error message could

have several causes.
