MPS
MPS version control
[1.4]
高级芯片组功能设置
DRAM timing selectable
[ SPD By SPD ]
Memory frequency for Auto
BIOS
System BIOS cacheable
[ Enabled ]
BIOS
Video BIOS cacheable
[ Disabled ]
Delay transaction [ Enabled ]
Delay prior to thermal [16 16 min ]
AGP aperture size
[64]
VGA On chip VGA [ Enabled ]
On chip frame buffer size
[8MB]
Boot display [ Auto ]
集成外围设备的设置 （INTERGRATED PERIPHERALS）
PCI IDE
On chip primary PCI IDE
[ Enabled ]
IDE PIO
IDE primary master PIO
[ Auto ]
IDE PIO
IDE primary slave PIO
[ Auto ]
IDE UDMA
IDE primary master UDMA
[ Auto ]
IDE UDMA
IDE primary slave UDMA
[ Auto ]
PCI IDE
On chip secondary PCI IDE
[ Enabled ]
IDE PIO
IDE primary master PIO
[ Auto ]
IDE PIO
IDE primary slave PIO
[ Auto ]
IDE UDMA
IDE primary master UDMA
[ Auto ]
IDE UDMA
IDE primary slave UDMA
[ Auto ]
USB USB controller [ Enabled ]
USB 2.0 USB 2.0 controller [ Enabled ]
USB
USB keyboard support
[ Disabled ]
USB USB mouse support [ Disabled ]
AC97 audio AC97 [ Auto ]
Init display first
[PCL PCI slot ]
LAN1
Onboard LAN1 control
[ Enabled ]
LAN2
Onboard LAN2 control
[ Enabled ]
IDE
IDE HDD block mode
[ Enabled ]
FDC
Onboard FDC controller
[ Enabled ]
1
Onboard serial port 1
[3F8/IRQ4]
2
Onboard serial port 2
[2F8/IRQ3]
Uart Uart mode select [ Normal ]
Onboard parallel port
[378/IRQ7]
Parallel port mode
[SPP]
电源管理设置 （POWER MANAGEMENT SETUP）
Power supply type
[AT]
Power management
[ User define ]
Video off method
[DPMS]
Video off in suspend
[ Yes ]
Suspend type [ Stop grant ]
Modem use IRQ
[3]
Suspend mode [ Disabled ]
HDD power down
[ Disabled ]
Soft off by pwr button
[ Instant off ]
CPU
CPU thrm throttling
[50%]
LAN
Power On by LAN
[ Enabled ]
高级 BIOS 功能设置 （ADVANCED BIOS FEATURES）
B6
4022 593 52701/1
×
1
B.100 AX-301/501 AX-3/5 08.01
B06.fm
■ 4022-594-1226X
Power On by Modem
[ Enabled ]
Power On by alarm
[ Disabled ]
IDE 0
Primary IDE 0
[ Disabled ]
IDE 1
Primary IDE 1
[ Disabled ]
IDE 0
Secondary IDE 0
[ Disabled ]
IDE 1
Secondary IDE 1
[ Disabled ]
FDD COM LPT
FDD,COM,LPT port
[ Disabled ]
PCI PIRQ[A-D]#
[ Disabled ]
[ On ]
PNP/PCI 配置 （PNP/PCI CONFIGURATIONS）
PNP OS
PNP OS Installed
[ No ]
Reset Configuration data
[ Disabled ]
[ ESCD Auto (ESCD) ]
PCI VGA
PCI/VGA palette snoop
[ Disabled ]
PCI 健康状态 （PCI HEALTH STATUS）
CPU
CPU Warning temperature
[50/122]
Shutdown temperature
[ Disabled ]
频率／电压控制 （FREQUENCY/VOLTAGE C[ON]TROL）
Spread spectrum [ Disabled ]
主要设置 （MAIN）
System Time
System Date
CPU CPU Type
CPU CPU Speed
System Memory
Extended Memory
1 Legacy Diskette 1 [1.44/1.25 MB 3 ]
2 Legacy Diskette 2 [ Disabled ]
Primary Master
[40021MB]
Primary Slave
[ None ]
Secondary Master
[CD-Rom]
Secondary Slave
[ None ]
高级设置 （ADVANCED）
BIOS Main Bios
Boot Block
Baseboard Data
ID
System/Enclosure Data ID
S/N Baseboard S/N
Mac Mac Address
Microcode Update in use
1 Microcode Update1
2 Microcode Update2
3 Microcode Update3
4 Microcode Update4
高级引导选项 （ADVANCED BOOT OPTIONS）
Summary screen [ Disabled ]
电源管理设置 （POWER MANAGEMENT SETUP）
4022 593 52701/1
×
1
08.01 AX-301/501 AX-3/5 B.101
B06.fm
B6
Boot-time Diagnostics screen
[ Disabled ]
Quick Boot Mode [ Enabled ]
Floppy Check [ Disabled ]
POST Errors [ Enabled ]
Enter Setup [ Enabled ]
Serial Console [ Disabled ]
高级硬盘选项 （ADVANCED HDD OPTIONS）
Large Disk Access Mode
[DOS]
IDE
[ Both ]
SMART
SMART Device Monitoring
[ Enabled ]
IDE
Primary IDE Cable Type
[ Auto ]
IDE
Secondary IDE Cable Type
[ Auto ]
高级系统监控 （ADVANCED SYSTEM MONITORING）
Intelligent System Monitoring
[ Enabled ]
高级缓存控制 （ADVANCED CACHE CONTROL）
BIOS
Cache System BIOS Area
[ Write Protect ]
BIOS
Cache Video Bios Area
[ Write Protect ]
Cache Base 0-512k
[Write Back]
Cache Base 512k-640k
[Write Back]
Cache Extended Memory Area
[Write Back]
Cache A000 – AFFF [ Disabled ]
Cache B000 - BFFF [ Disabled ]
Cache C000 - CFFF [ Disabled ]
Cache D000 – D3FF [ Disabled ]
Cache D400 – D7FF [ Disabled ]
Cache D800 - DBFF [ Disabled ]
Cache DC00 - DFFF [ Disabled ]
Cache E000 – E3FF [ Disabled ]
Cache E400 - EFFF
[ Disabled ]
高级 PCI 配置 （ADVANCED PCI CONFIGURATION）
PCI # 2PCI Device, Slot # 2
PCI # 3PCI Device, Slot # 3
PCI # 4PCI Device, Slot # 4
PCI # 5PCI Device, Slot # 5
PCI # 6PCI Device, Slot # 6
Embedded Ethernet Controller
[ Enabled ]
Embedded Ethernet Options
ISA
ISA graphics device installed
[ No ]
PCI I/O
PCI I/O Allocation Scheme
[ Bottom Up ]
PCI IRQ Shared PCI IRQs
[ Auto ]
高级 I/O 设备配置 （ADVANCED I/O DEVICE CONFIGURATION）
A Serial port A [ Auto ]
B Serial port B [ Auto ]
Mode [ Normal ]
Parallel port [ Auto ]
Mode
[ECP]
Floppy disk controller
[ Enabled ]
I/O
Base I/O address
[ Primary ]
PS/2 PS/2 Mouse
[ Auto Detect ]
高级引导选项 （ADVANCED BOOT OPTIONS）
