AX501维修手册 - 第466页
C6 4022 593 52701/1 × 1 C.96 AX-301 /501 AX-3/5 08.01 C06.fm Primary IDE cable type IDE [Auto] Secondary IDE cable type IDE [Auto] Advanced Chipset Control …
4022 593 52701/1 × 1
08.01 AX-301/501 AX-3/5 C.95
C06.fm
C6
o. Y
p.
q. 下一个
r. Y
s.
t.
11. 完成
• Z 88 C6.1.3Z
C6.6 嵌入式过程控制器，检查 BIOS 设置
1. 前提
•
• VGA
•
• Del BIOS
•
■ 使用嵌入式过程控制器 4022-594-1232X 和 4022-594-1331X 时
MAIN （主要设置）
Legacy Diskette 1
1
[Disabled]
Legacy Diskette 2
2
[Disabled]
Primary Master
[Auto]
Primary Slave
[None]
Secondary Master
[None(or CDROM when connected)]
CD-ROM CDROM
Secondary Slave
[None]
Keyboard Features
[Auto, Disabled, 30/sec, 1/2 sec] 30/sec 1/2 sec
ADVANCED （高级设置）
Advanced Boot Options
Summary Screen [Disabled]
Boot-time diagnostic screen
[Enabled]
Quickboot mode [Enabled]
POST errors POST [Disabled]
Enter setup [Enabled]
Serial Console [Disabled]
Advanced HDD Options
Large disk access mode
[Other]
Local Bus IDE adapter
IDE
[Both]
SMART device monitoring
SMART
[Enabled]
C6
4022 593 52701/1 × 1
C.96 AX-301/501 AX-3/5 08.01
C06.fm
Primary IDE cable type
IDE
[Auto]
Secondary IDE cable type
IDE
[Auto]
Advanced Chipset Control
Video boot type [Onboard Video 1MB] 1MB
Primary video
[AGP]
Graphics Aperture
[64 MB]
Enable memory gab
[Disabled]
AC97 audio AC97 [Disabled]
Embedded USB device
USB
[Disabled]
Embedded USB device 2
USB 2
[Disabled]
EMI Reduction [Enabled]
Advanced OS Options OS
Installed OS OS [Other]
[Enabled] ACPI ACPI [Yes]
Secure setup configuration
[No]
System Monitoring
Hardware monitor controls
Shut down temperature
[100 C/ 212 F]
Chassis intrusion [Disabled]
Variable fan speed control
[Enabled]
Enclosure fan tacho
[1]
Processor fan tacho
[2]
Intelligent System Monitoring
[Enabled]
Cache Control
Cache System BIOS area
BIOS
[Write Protect]
Cache Video BIOS area
BIOS
[Write Protect]
Cache Base 0-512K 0-512K
[Write Back]
Cache Base 512-650K
512-650K
[Write Back]
Cache Extended Memory Area
[Write Back]
Cache A000 - AFFF
A000 - AFFF
[Disabled]
Cache B000 - BFFF
B000 - BFFF
[Disabled]
Cache C800 - CBFF
C800 - CBFF
[Disabled]
Cache CC00 - CFFF
CC00 - CFFF
[Disabled]
Cache D000 - D3FF
D000 - D3FF
[Disabled]
Cache D400 - D7FF
D400 - D7FF
[Disabled]
Cache D800 - DBFF
D800 - DBFF
[Disabled]
Cache DC00 - DFFF
DC00 - DFFF
[Disabled]
Cache E000 - E3FF
E000 - E3FF
[Disabled]
Cache E400 - E7FF
E400 - E7FF
[Disabled]
Cache E800 - EBFF
E800 - EBFF
[Disabled]
Cache EC00 - EFFF
EC00 - EFFF
[Disabled]
PCI Configuration PCI
PCI Device, Slote #2
PCI 2
[Enabled, Enabled, Default]
PCI Device, Slote #3
PCI 3
[Enabled, Enabled, Default]
PCI Device, Slote #4
PCI 4
[Enabled, Enabled, Default]
PCI Device, Slote #5
PCI 5
[Enabled, Enabled, Default]
PCI Device, Slote #6
PCI 6
[Enabled, Enabled, Default]
Embedded Ethernet Controller
[Enabled]
Embedded Ethernet Options
[Enabled, Enabled, Default]
ISA graphics device installed
ISA
[No]
PCI I/O allocation Scheme
PCI I/O
[Bottom-Up]
Shared PCI IRQs PCI IRQ [Auto]
PCI/PNP ISA UMB Region Exclusion
PCI/PNP ISA UMB
CC00 - CFFF
[Available]
D000 - D3FF
[Available]
D400 - D7FF
[Available]
ADVANCED （高级设置）
4022 593 52701/1 × 1
08.01 AX-301/501 AX-3/5 C.97
C06.fm
C6
■ 使用嵌入式过程控制器 4022-594-1445X 和 4022-594-1381X 时
D800 - DBFF
[Available]
DC00 - DFFF
[Available]
PCI/PNP ISA IRQ Resource Exclusion PCI/PNP ISA IRQ
IRQ 3
[Available]
IRQ 4
[Available]
IRQ 5
[Available]
IRQ 7
[Available]
IRQ 9
[Available]
IRQ 10
[Available]
IRQ 11
[Available]
PCI/PNP ISA DMA Resource Exclusion PCI/PNP ISA DMA
DMA 0
[Available]
DMA 1
[Available]
DMA 2
[Available]
DMA 3
[Available]
DMA 5
[Available]
DMA 6
[Available]
DMA 7
[Available]
PCI/PNP IRQ Overrides PCI/PNP IRQ
PCI IRQ line 1 (INTA)
[5]
PCI IRQ line 2 (INTB)
[7]
PCI IRQ line 3 (INTC)
[9]
PCI IRQ line 4 (INTD)
[Auto Select]
PCI IRQ line 5 (INTE)
[Auto Select]
PCI IRQ line 8 (INTH)
[Auto Select]
I/O Device Configuration I/O
Serial port A A [Auto]
Serial port B B [Auto]
Parallel port [Auto]
Mode
[ECP]
Floppy disk controller [Disabled]
PS/2 Mouse PS/2 [Auto Detect]
POWER （电源设置）
After Power Failure
[Power On]
Power Button Function
[Power Off]
Power Savings
[Disabled]
BOOT （启动设置）
LAN
ATAPI CD-ROM Drive
ATAPI CD-ROM
Hard Drive
STI Flash Drive (SM)
STI SM
Bootable Add-in Cards
Removable Devices
Network Boot ! =
STANDARD BIOS SETTINGS （标准 BIOS 设置）
IDE Primary Master
IDE
[PQI IDE DiskOnModule]
ADVANCED （高级设置）
