4022 593 52701/1 × 1 08.01 AX-301/501 AX-3/5 C.97 C06.fm C6 ■ 使用嵌入式过程控制 器 4022-594-1445X 和 4022-594-1381X 时 D800 - DBFF [Available] DC00 - DFFF [Available] PCI/PNP ISA IRQ Resou rce Exclu…
C6
4022 593 52701/1 × 1
C.96 AX-301/501 AX-3/5 08.01
C06.fm
Primary IDE cable type
IDE
[Auto]
Secondary IDE cable type
IDE
[Auto]
Advanced Chipset Control
Video boot type [Onboard Video 1MB] 1MB
Primary video
[AGP]
Graphics Aperture
[64 MB]
Enable memory gab
[Disabled]
AC97 audio AC97 [Disabled]
Embedded USB device
USB
[Disabled]
Embedded USB device 2
USB 2
[Disabled]
EMI Reduction [Enabled]
Advanced OS Options OS
Installed OS OS [Other]
[Enabled] ACPI ACPI [Yes]
Secure setup configuration
[No]
System Monitoring
Hardware monitor controls
Shut down temperature
[100 C/ 212 F]
Chassis intrusion [Disabled]
Variable fan speed control
[Enabled]
Enclosure fan tacho
[1]
Processor fan tacho
[2]
Intelligent System Monitoring
[Enabled]
Cache Control
Cache System BIOS area
BIOS
[Write Protect]
Cache Video BIOS area
BIOS
[Write Protect]
Cache Base 0-512K 0-512K
[Write Back]
Cache Base 512-650K
512-650K
[Write Back]
Cache Extended Memory Area
[Write Back]
Cache A000 - AFFF
A000 - AFFF
[Disabled]
Cache B000 - BFFF
B000 - BFFF
[Disabled]
Cache C800 - CBFF
C800 - CBFF
[Disabled]
Cache CC00 - CFFF
CC00 - CFFF
[Disabled]
Cache D000 - D3FF
D000 - D3FF
[Disabled]
Cache D400 - D7FF
D400 - D7FF
[Disabled]
Cache D800 - DBFF
D800 - DBFF
[Disabled]
Cache DC00 - DFFF
DC00 - DFFF
[Disabled]
Cache E000 - E3FF
E000 - E3FF
[Disabled]
Cache E400 - E7FF
E400 - E7FF
[Disabled]
Cache E800 - EBFF
E800 - EBFF
[Disabled]
Cache EC00 - EFFF
EC00 - EFFF
[Disabled]
PCI Configuration PCI
PCI Device, Slote #2
PCI 2
[Enabled, Enabled, Default]
PCI Device, Slote #3
PCI 3
[Enabled, Enabled, Default]
PCI Device, Slote #4
PCI 4
[Enabled, Enabled, Default]
PCI Device, Slote #5
PCI 5
[Enabled, Enabled, Default]
PCI Device, Slote #6
PCI 6
[Enabled, Enabled, Default]
Embedded Ethernet Controller
[Enabled]
Embedded Ethernet Options
[Enabled, Enabled, Default]
ISA graphics device installed
ISA
[No]
PCI I/O allocation Scheme
PCI I/O
[Bottom-Up]
Shared PCI IRQs PCI IRQ [Auto]
PCI/PNP ISA UMB Region Exclusion
PCI/PNP ISA UMB
CC00 - CFFF
[Available]
D000 - D3FF
[Available]
D400 - D7FF
[Available]
ADVANCED （高级设置）
4022 593 52701/1 × 1
08.01 AX-301/501 AX-3/5 C.97
C06.fm
C6
■ 使用嵌入式过程控制器 4022-594-1445X 和 4022-594-1381X 时
D800 - DBFF
[Available]
DC00 - DFFF
[Available]
PCI/PNP ISA IRQ Resource Exclusion PCI/PNP ISA IRQ
IRQ 3
[Available]
IRQ 4
[Available]
IRQ 5
[Available]
IRQ 7
[Available]
IRQ 9
[Available]
IRQ 10
[Available]
IRQ 11
[Available]
PCI/PNP ISA DMA Resource Exclusion PCI/PNP ISA DMA
DMA 0
[Available]
DMA 1
[Available]
DMA 2
[Available]
DMA 3
[Available]
DMA 5
[Available]
DMA 6
[Available]
DMA 7
[Available]
PCI/PNP IRQ Overrides PCI/PNP IRQ
PCI IRQ line 1 (INTA)
[5]
PCI IRQ line 2 (INTB)
[7]
PCI IRQ line 3 (INTC)
[9]
PCI IRQ line 4 (INTD)
[Auto Select]
PCI IRQ line 5 (INTE)
[Auto Select]
PCI IRQ line 8 (INTH)
[Auto Select]
I/O Device Configuration I/O
Serial port A A [Auto]
Serial port B B [Auto]
Parallel port [Auto]
Mode
[ECP]
Floppy disk controller [Disabled]
PS/2 Mouse PS/2 [Auto Detect]
POWER （电源设置）
After Power Failure
[Power On]
Power Button Function
[Power Off]
Power Savings
[Disabled]
BOOT （启动设置）
LAN
ATAPI CD-ROM Drive
ATAPI CD-ROM
Hard Drive
STI Flash Drive (SM)
STI SM
Bootable Add-in Cards
Removable Devices
Network Boot ! =
STANDARD BIOS SETTINGS （标准 BIOS 设置）
IDE Primary Master
IDE
[PQI IDE DiskOnModule]
ADVANCED （高级设置）
C6
4022 593 52701/1 × 1
C.98 AX-301/501 AX-3/5 08.01
C06.fm
IDE Primary Slave
IDE
[None]
IDE Secondary Master
IDE
[None]
IDE Secondary Slave
IDE
[None]
Drive A A [None]
Drive B B [None]
Video
[EGA/VGA]
Halt On [No Errors]
Base Memory
[640K]
Extended Memory
[252928K]
Total Memory
[253952K]
ADVANCED BIOS FEATURES （高级 BIOS 功能）
Virus Warning [Disabled]
CPU Internal Cache
CPU
[Enabled]
External Cache [Enabled]
CPU L2 Cache ECC Checking
CPU L2 ECC
[Enabled]
Quick Power On Self Test
[Enabled]
First Boot Device
[LAN]
Second Boot Device
[Disabled]
Third Boot Device
[Disabled]
Boot Other Device
[Disabled]
Swap Floppy Drive
[Disabled]
Boot Up Floppy Seek
[Disabled]
Boot Up Numlock Status
Numlock
[On]
Gate A20 Option
Gate A20
[Normal]
Typematic Rate Setting
[Disabled]
Typematic Rate (Chars/Sec)
[6]
Typematic Delay (Msec)
Msec
[250]
Security Option [Setup]
OS Select For DRAM > 64MB
DRAM
64MB
OS
[Non-OS2] OS2
Video Bios Shadow
BIOS
[Enabled]
C8000-CBFFF Shadow
C8000-CBFFF
[Disabled]
CC000-CFFFF Shadow
CC000-CFFFF
[Disabled]
D0000-D3FFF Shadow
D0000-D3FFF
[Disabled]
D0000-D3FFF Shadow
D0000-D3FFF
[Disabled]
D8000-DBFFF Shadow
D8000-DBFFF
[Disabled]
D8000-DBFFF Shadow
D8000-DBFFF
[Disabled]
VIA C3
[Default]
ADVANCED CHIPSET FEATURES （高级芯片组功能）
DRAM Clock DRAM [Host CLK]
DRAM Timing By SPD
SPD
DRAM
[Disabled]
SDRAM Cycle Length
SDRAM
[3]
Bank Interleave [Disabled]
Memory Hole [Disabled]
P2C/C2P Concurrency
P2C/C2P
[Enabled]
Fast R-W Turn Around
[Enabled]
System Bios Cacheable
BIOS
[Disabled]
Video RAM Cacheable
RAM
[Disabled]
Frame Buffer Size
[8M]
AGP Aperture Size
AGP
[64M]
Power-Supply Type
[ATX]
OnChip USB USB [Disabled]
USB Keyboard Support
USB
[Disabled]
USB Mouse Support
USB
[Disabled]
STANDARD BIOS SETTINGS （标准 BIOS 设置）
