4022 593 52701/1 × 1 08.01 AX-301/501 AX-3/5 D.71 D06.fm D6 第 D6 章 测量、调节和校准 D6.1 嵌入式处理控制器，检查 BIOS 设定 1. 前提 • • VGA • • Del BI OS • …
4022 593 52701/1
×
1
08.01 AX-301/501 AX-3/5 D.71
D06.fm
D6
第 D6 章 测量、调节和校准
D6.1 嵌入式处理控制器，检查 BIOS 设定
1. 前提
•
• VGA
•
• Del BIOS
•
■ 用于嵌入式处理控制器 4022-594-1232X 和 4022-594-1331X
主要设置 （MAIN）
1
Legacy Diskette 1
[ Disabled ]
2
Legacy Diskette 2
[ Disabled ]
Primary Master
[ Auto ]
Primary Slave
[ None ]
Secondary Master
[ None CDROM ]
Secondary Slave
[ None ]
Keyboard Features
[ 30 1/2 Auto, Disabled, 30/sec, 1/2 sec ]
高级设置 （ADVANCED）
Advanced Boot Options
Summary screen [ Disabled ]
Boot-time Diagnostics screen
[ Enabled ]
Quickboot mode
[ Enabled ]
POST POST Errors
[ Disabled ]
Enter Setup
[ Enabled ]
Serial Console
[ Disabled ]
Advanced HDD Options
Large disk access mode
[ Other ]
IDE
Local Bus IDE adapter
[ Both ]
SMART
SMART device monitoring
[ Enabled ]
IDE
Primary IDE cable type
[ Auto ]
IDE
Secondary IDE cable type
[ Auto ]
Advanced Chipset Control
Video boot type [ Onboard Video 1MB]
Primary Video
[AGP]
Graphics Aperture
[64 MB]
Enable memory gap
[ Disabled ]
AC97 audio AC97 [ Disabled ]
USB
Embedded USB Device
[ Disabled ]
USB 2
Embedded USB Device 2
[ Disabled ]
EMI Reduction [ Enabled ]
OS Advanced OS Options
OS Installed OS
[ Other ]
[ Enabled ] ACPI [ Yes ]
Secure Setup Configuration
[ No ]
System Monitoring
Hardware monitor controls
D6
4022 593 52701/1
×
1
D.72 AX-301/501 AX-3/5 08.01
D06.fm
Shut down temperature
[100 C/ 212 F]
Chassis intrusion
[ Disabled ]
Variable fan speed control
[ Enabled ]
Enclosure fan tacho
[1]
Processor fan tacho
[2]
Intelligent System Monitoring
[ Enabled ]
Cache Control
BIOS
Cache System BIOS Area
[ Write Protect ]
BIOS
Cache Video Bios Area
[ Write Protect ]
0-512K
Cache Base 0-512K
[ Write Back ]
512-650K
Cache Base 0-512K
[ Write Back ]
d
Cache Extended Memory Area
[ Write Back ]
Cache A000 - AFFF
[ Disabled ]
Cache B000 - BFFF
[ Disabled ]
Cache C800 - CBFF
[ Disabled ]
Cache CC00 - CFFF
[ Disabled ]
Cache D000 - D3FF
[ Disabled ]
Cache D400 - D7FF
[ Disabled ]
Cache D800 - DBFF
[ Disabled ]
Cache DC00 - DFFF
[ Disabled ]
Cache E000 - E3FF
[ Disabled ]
Cache E400 - E7FF
[ Disabled ]
Cache E800 - EBFF
[ Disabled ]
Cache EC00 - EFFF
[ Disabled ]
PCI PCI Configuration
PCI
# 2
PCI Device, Slote # 2
[ Enabled, Enabled, Default ]
PCI
# 3
PCI Device, Slote # 3
[ Enabled, Enabled, Default ]
PCI
# 4
PCI Device, Slote # 4
[ Enabled, Enabled, Default ]
PCI
# 5
PCI Device, Slote # 5
[ Enabled, Enabled, Default ]
PCI
# 6
PCI Device, Slote # 6
[ Enabled, Enabled, Default ]
Embedded Ethernet Controller
[ Enabled ]
Embedded Ethernet Options
[ Enabled, Enabled, Default ]
ISA
ISA graphics device installed
[ No ]
PCI I/O
PCI I/O Allocation Scheme
[ Bottom - Up ]
PCI IRQ Shared PCI IRQs [ Auto ]
PCI/PNP ISA UMB
PCI/PNP ISA UMB Region Exclusion
CC00 - CFFF
[ Available ]
D000 - D3FF
[ Available ]
D400 - D7FF
[ Available ]
D800 - DBFF
[ Available ]
DC00 - DFFF
[ Available ]
PCI/PNP ISA IRQ PCI/PNP ISA IRQ Resource Exclusion
IRQ 3
[ Available ]
IRQ 4
[ Available ]
IRQ 5
[ Available ]
IRQ 7
[ Available ]
IRQ 9
[ Available ]
IRQ 10
[ Available ]
IRQ 11
[ Available ]
PCI/PNP ISA DMA PCI/PNP ISA DMA Resource Exclusion
DMA 0
[ Available ]
DMA 1
[ Available ]
DMA 2
[ Available ]
DMA 3
[ Available ]
DMA 5
[ Available ]
DMA 6
[ Available ]
高级设置 （ADVANCED）
