D6 4022 593 52701/1 × 1 D.74 AX-301 /501 AX-3/5 08.01 D06.fm Quick power on self test [ Enabled ] First boot device [LAN] Second boot device [ �…
4022 593 52701/1
×
1
08.01 AX-301/501 AX-3/5 D.73
D06.fm
D6
■ 用于嵌入式处理控制器 4022-594-1445X 和 4022-594-1381X
DMA 7
[ Available ]
PCI/PNP IRQ PCI/PNP IRQ Overrides
PCI IRQ 1 INTA
PCI IRQ line 1 (INTA)
[5]
PCI IRQ 2 INTB
PCI IRQ line 2 (INTB)
[7]
PCI IRQ 3 INTC
PCI IRQ line 3 (INTC)
[9]
PCI IRQ 4 INTD
PCI IRQ line 4 (INTD)
[ Auto Select ]
PCI IRQ 5 INTE
PCI IRQ line 5 (INTE)
[ Auto Select ]
PCI IRQ 8 INTH
PCI IRQ line 8 (INTH)
[ Auto Select ]
I/O I/O Device Configuration
A Serial port A
[ Auto ]
B Serial port B
[ Auto ]
Parallel port
[ Auto ]
Mode
[ECP]
Floppy disk controller
[ Disabled ]
PS/2 PS/2 Mouse
[ Auto Detect ]
电源 （POWER）
After Power Failure
[ Power On ]
Power Button Function
[ Power Off ]
Power Savings
[ Disabled ]
启动设置 （BOOT）
LAN
ATAPI CD-ROM
ATAPI CD-ROM Drive
Hard Drive
STI - SM
STI Flash Drive-(SM)
Bootable Add-in Cards
Removable Devices
Network Boot ! =
标准 BIOS 设定 （STANDARD BIOS SETTINGS）
IDE
IDE Primary Master
[PQI IDE PQI IDE DiskOnModule ]
IDE
IDE Primary Slave
[ None ]
IDE
IDE Secondary Master
[ None ]
IDE
IDE Secondary Slave
[ None ]
A Drive A [ None ]
B Drive B
[ None ]
Video
[EGA/VGA]
Halt on [ No Errors ]
Base Memory
[640K]
Extended Memory
[252,928K]
Total Memory
[253,952K]
高级 BIOS 功能设置 （ADVANCED BIOS FEATURES）
Virus warning [ Disabled ]
CPU
CPU Internal Cache
[ Enabled ]
External Cache [ Enabled ]
CPU L2 ECC
CPU L2 Cache ECC Checking
[ Enabled ]
高级设置 （ADVANCED）
D6
4022 593 52701/1
×
1
D.74 AX-301/501 AX-3/5 08.01
D06.fm
Quick power on self test
[ Enabled ]
First boot device
[LAN]
Second boot device
[ Disabled ]
Third boot device
[ Disabled ]
Boot other device
[ Disabled ]
Swap floppy drive
[ Disabled ]
Boot up floppy seek
[ Disabled ]
Numlock
Boot up numlock status
[ On ]
A20 Gate A20 Option
[ Normal ]
Typematic rate setting
[ Disabled ]
Typematic Rate (Chars/Sec)
[6]
Typematic Delay (Msec)
[250]
Security option
[ Setup ]
DRAM OS
OS Select For DRAM > 64MB
[ OS2 Non-OS2 ]
Bios
Video Bios Shadow
[ Enabled ]
C8000-CBFFF
C8000-CBFFF Shadow
[ Disabled ]
CC000-CFFFF
CC000-CFFFF Shadow
[ Disabled ]
D0000-D3FFF
D0000-D3FFF Shadow
[ Disabled ]
D4000-D7FFF
D4000-D7FFF Shadow
[ Disabled ]
D8000-DBFFF
D8000-DBFFF Shadow
[ Disabled ]
DC000-DFFFF
DC000-DFFFF Shadow
[ Disabled ]
VIA C3
[ Default ]
高级芯片组功能设置 （ADVANCED CHIPSET FEATURES）
DRAM DRAM Clock [ Host CLK ]
SPD DRAM
DRAM Timing By SPD
[ Disabled ]
SDRAM
SDRAM Cycle Length
[3]
Bank Interleave [ Disabled ]
Memory Hole
[ Disabled ]
P2C/C2P
P2C/C2P Concurrency
[ Enabled ]
Fast R-W Turn Around
[ Enabled ]
BIOS
System BIOS cacheable
[ Disabled ]
RAM
Video RAM Cacheable
[ Disabled ]
Frame Buffer Size
[8M]
AGP
AGP aperture size
[64M]
Power - supply type
[ATX]
USB OnChip USB [ Disabled ]
USB
USB keyboard support
[ Disabled ]
USB
USB mouse support
[ Disabled ]
OnChip Sound [ Disabled ]
CPU PCI
CPU To PCI Write Buffer
[ Enabled ]
PCI
PCI Dynamic Bursting
[ Enabled ]
PCI 0
PCI Master 0 WS Write
[ Enabled ]
PCI
PCI Delay Transaction
[ Enabled ]
PCI#2 #1
PCI#2 Access #1 Retry
[ Disabled ]
AGP 1
AGP Master 1 WS Write
[ Disabled ]
AGP 1
AGP Master 1 WS Read
[ Disabled ]
集成外围设备的设置 （INTERGRATED PERIPHERALS）
IDE 0
OnChip IDE Channel0
[ Enabled ]
IDE 1
OnChip IDE Channel1
[ Disabled ]
IDE
IDE Prefetch Mode
[ Disabled ]
PIO
Primary Master PIO
[ Auto ]
PIO
Primary Slave PIO
[ Auto ]
高级 BIOS 功能设置 （ADVANCED BIOS FEATURES）
4022 593 52701/1
×
1
08.01 AX-301/501 AX-3/5 D.75
D06.fm
D6
PIO
Secondary Master PIO
[ Auto ]
PIO
Secondary Slave PIO
[ Auto ]
UDMA
Primary Master UDMA
[ Auto ]
UDMA
Primary Slave UDMA
[ Auto ]
UDMA
Secondary Master UDMA
[ Auto ]
UDMA
Secondary Slave UDMA
[ Auto ]
Init display first
[PCL PCI slot ]
IDE
IDE HDD block mode
[ Enabled ]
LAN Onboard LAN
[ Enabled ]
LAN ROM
Onboard Lan Boot ROM
[ Enabled ]
FDD
Onboard FDD controller
[ Disabled ]
1
Onboard serial port 1
[3F8/IRQ4]
2
Onboard serial port 2
[2F8/IRQ3
UART 2 UART 2 Mode
[ Standard ]
IR
IR Function Duplex
[ Half ]
TX, RX Inverting enable
[ No, Yes ]
Onboard parallel port
[378/IRQ7]
Onboard Parallel Mode
[ECP/EPP]
ECP DMA
ECP Mode Use DMA
[3]
Epp
Parallel Port Epp Type
[Eppl.9]
电源管理设置 （POWER MANAGEMENT SETUP）
ACPI ACPI function
[ Enabled ]
Power management
[ Press Enter ]
APM
PM Control by APM
[ Yes ]
Video Off Option
[ Suspend -> Off]
Video off method
[V/H SYNC+ Blanc]
IRQ
Modem use IRQ
[NA]
Soft-Off by PWRBTN
[ Instant-Off ]
State After Power Failure
[ On ]
Wake Up Events
[ Press Enter ]
电源管理 （POWER MANAGEMENT）
Power management [ User define ]
HDD power down [ Disabled ]
Doze Mode [ Disabled ]
Suspend mode
[ Disabled ]
恢复事件 （WAKE UP EVENTS）
VGA
[ OFF ]
LPT & COM [LPT/COM]
HDD & FDD
[ ON ]
PCI PCI Master [ OFF ]
LAN
PowerOn by LAN
[ Disabled ]
Modem Ring Resume
[ Disabled ]
RTC
RTC Alarm Resume
[ Disabled ]
Date (of Month)
[0]
Resume Time (hh:mm:ss)
[0:0:0]
IRQ
IRQs Activity Monitoring
[ Press Enter ]
集成外围设备的设置 （INTERGRATED PERIPHERALS）
