KV7_YV88X_PL - 第11页
2 4 Y -axis (FNC/SF) Moving-axis KV7-080617 No. Part No. Part Name Q'ty Remarks Date of change Revised No. Compati. 1 KV7-M261 1-01X FRAME R,Y AXIS 1 1-1 KV7-M261 1-02X FRAME R,Y AXIS 1 (2003/2/17) M320070 OK 1-2 De…
1
4
X-axis
Moving-axis
KV7-080617
19
47
34
33
15
66
10
64
4
14
72
28
28
54
27
26
11
63
45
36
44
16
17
25
58
60
18
29
22
23
56
5
5
1
68
68
44
45
43
13
59
65
9
9
6
5
31
35
30
24
24
38
37
42
40
41
40
12
41
46
29
66
23
56
50
55
48
51
49
66
50
48
49
51
53
8
7
39
62
61
67
59
56
21
20
59
35
32
67
52
43
OLD
70
71
69
3
2
14
27
26
OLD
18
9
9
7
OLD
No. Part No. Part Name Q'ty Remarks Date of change Revised No. Compati.
1 KV7-M2211-02X FRAME X AXIS 1
2 KV7-M2213-02X PLATE A,X AXIS 1
2-1 Delete (2000/2/3) M020009
3 KV7-M2214-02X PLATE B,X AXIS 1
3-1 Delete (2000/2/3) M020009
4 KM0-M2220-00X COUPLING, X-AXIS 1
5 KV7-M2231-00X SPACER R.NUT 3
6 KM0-M2233-00X SPACER R2 NUT 1
6-1 KV7-M2233-00X SPACER R2,NUT 1 (2003/2/11) M320049 OK
7 KV7-M2236-00X PLATE A 1
7-1 KV7-M2236-01X PLATE A 1 (2008/3/27) ME30100 SET
8 KV7-M2237-00X SUB PLATE 1
9 KV7-M2239-00X BRACKET 1 2
9-1 KV7-M2239-01X BRACKET 1 2 (2008/3/27) ME30100 SET
10 KM0-M2241-00X HOLDER, MOTOR 1
11 KV7-M2242-00X HOLDER, BRG. X AXIS 1
12 KV7-M2645-00X BRG.,ANGULAR 1
12-1 90990-25J005 BEARING 1 (2007/12/4) MDX0031 OK
13 KV7-M2261-00X HOLDER, HEAD 1
13-1 KV7-M2261-01X HOLDER, HEAD 1 (2002/4/25) M240093 OK
14 KV7-M2271-00X SCREW BALL X AXIS 1
14-1 KV7-M2271-01X SCREW BALL X AXIS 1 1999/11/3 M9X0010 Set
14-2 KV7-M2271-02X SCREW BALL X AXIS 1 with/K1 seal (2002/6/6) M250068 Set
15 90K52-87174X AC SERVO MOTOR 1
15-1 90K56-87174X AC SERVO MOTOR 1 (2000/8/28) M080110 OK
15-2 90K56-8717EX AC SERVO MOTOR 1 (2003/4/18) M340073 OK
16 KV7-M653A-00X SENSOR, 1 ASSY 1 L=600
16-1 KGA-M220A-00X SENSOR , ORG 1 L=600 (2002/11/12) M2X0034 OK
17 KV7-M653E-00X SENSOR, 2 ASSY 1 L=600
17-1 KGA-M220B-00X SENSOR , OT(L=600) 1 L=600 (2002/11/12) M2X0034 OK
18 K47-M2276-S0X X-AXIS GUIDE SET 1
18-1 KV7-M2276-S0X X-AXIS GUIDE SET 1 with/K1 seal (2002/6/6) M250068 Set
19 KV7-M2267-01X CABLE. DUCT 1
19-1 KV7-M2267-A1X CABLE DUCT 1 (2004/7/12) MA70035 OK
20 K94-M220A-00X TAPE X-AXIS 1
21 K94-M220A-10X TAPE X-AXIS 1
22 KV7-M2282-00X DOG. ORG 1
23 KV7-M2283-00X DOG. 2ND LIMIT 2
24 KV7-M226B-00X PLATE 2
25 KV7-M2291-00X BRACKET, SENSOR 1
26 KGA-M2651-10X DAMPER 14 ASSY 1
26-1 KGA-M2651-11X DAMPER 14 ASSY 1 (2002/6/6) M250068 Set
27 KGA-M2651-60X DAMPER 120 ASSY 1
27-1 KGA-M2651-61X DAMPER 105 ASSY 1 (2002/6/6) M250068 Set
28 KGA-M2649-00X NYLOCK BOLT 12 M2.6
28-1 KGA-M2649-00X NYLOCK BOLT 24 M2.6X10 (2001/2/27) M120136 OK
28-2 90990-01J023 BOLT,HEX.SOCKET HEAD 24 (2007/10/29) MD00030 OK
29 KM0-M2251-00X NYLOCK BOLT 16 M8X22L
29-1 90990-01J024 BOLT,HEX.SOCKET HEAD 16 (2007/10/29) MD00030 OK
29-2 90990-01J179 BOLT,HEX.SOCKET HEAD 16 (2020/1/24) MT10096 OK
30 KV7-M226A-00X COVER CABLE 1
31 KV7-M2268-00X BRACKET 1, TAPE 1
32 KV7-M2269-00X BRACKET 2, TAPE 1
33 KV7-M220A-01X TAPE, X DUCT 1
34 KV7-M220B-00X TAPE 2, X DUCT 1
35 KV7-M2266-00X PLATE.NUT 2
36 KV7-M2240-00X SLEEVE.BRG. 1
37 KV7-M2243-00X HOUSING, BRG. X 1
38 KV7-M2244-00X COVER, BRG. HOUSING 1
39 KV7-M2246-00X COIL SPRING M 6
40 KV7-M2647-00X OIL SEAL 2
41 KV7-M2648-00X SPACER 3
42 KG2-M9173-00X LOCK NUT 1
43 KV7-M2663-00X NYLOCK BOLT(M5X16) 16
43-1 90990-01J030 BOLT,HEX.SOCKET HEAD 16 (2007/10/29) MD00030 OK
44 KV7-M2256-00X GRIP 2
45 KV7-M2257-00X SPACER GRIP 2
46 KV7-M220C-00X TAPE 3, X DUCT 1
47 KV7-M221A-A0X COVER, DUCT ASSY 1
48 KV7-M2295-01X BRACKET, PIN 2
48-1 Delete (2002/7/19) M270057
49 KV7-M2296-00X BRACKET, SCREW 2
49-1 Delete (2002/7/19) M270057
50 KV7-M2297-00X TAPER PIN 4
50-1 Delete (2002/7/19) M270057
51 KV7-M2298-00X NYLOCK SET SCREW 6
51-1 Delete (2002/7/19) M270057
52 KM0-M2252-00X STOPPER 1
53 99480-06014 PIN, PARALLEL 2
54 KV7-M2604-00X SUPPORT UNIT 1 1999/11/3 M9X0010 SET
55 KV7-M2253-00X WASHER, SPRING 16
56 91317-03006 BOLT HEX. SOCKET HEAD 6
57
58 91317-04008 BOLT HEX. SOCKET HEAD 12
59 91317-04010 BOLT HEX.SOCKET HEAD 26
59-1 91317-04010 BOLT HEX.SOCKET HEAD 4 (2002/2/28) M220145 OK
60 KV7-M2251-00X NYLOCK BOLT(M4X16) 30
60-1 91317-04016 BOLT HEX.SOCKET HEAD 30 (2005/2/7) MB20025 OK
61 91317-04030 BOLT HEX. SOCKET HEAD 6
62 91317-05014 BOLT HEX. SOCKET HEAD 4
63 91317-05020 BOLT HEX. SOCKET HEAD 4
64 91317-05035 BOLT HEX. SOCKET HEAD 4
65 91317-06012 BOLT HEX. SOCKET HEAD 8
66 91317-06018 BOLT HEX.SOCKET HEAD 8
66-1 91317-06018 BOLT HEX.SOCKET HEAD 26 (1999/5/20) M950078 OK
66-2 91317-06018 BOLT HEX.SOCKET HEAD 4 (2002/3/25) M230122 OK
66-3 91317-06018 BOLT HEX.SOCKET HEAD 8 (2002/7/19) M270057 OK
67 98907-03005 SCREW BINDING HEAD 4
67-1 98902-03006 SCREW BINDING HEAD 4 (2007/7/9) MD60168 OK
68 KV7-M2213-S0X PLATE X AXIS SET 1 (2000/2/3) M020009
69 KV7-M2247-00X BLOCK,STOPPER X 1
70 KV7-M2248-00X DAMPER 2 1
70-1 1 Delete (2002/7/19) M270057
71 KV7-M2248-00X DAMPER 1 1
71-1 1 Delete (2002/7/19) M270057
72 KV7-M2271-A0X X AXIS B.S.SUB ASSY 1 (2005/8/2) MB30076
2
4
Y-axis (FNC/SF)
Moving-axis
KV7-080617
No. Part No. Part Name Q'ty Remarks Date of change Revised No. Compati.
1 KV7-M2611-01X FRAME R,Y AXIS 1
1-1 KV7-M2611-02X FRAME R,Y AXIS 1 (2003/2/17) M320070 OK
1-2 Delete (2007/2/8) MD10036
2 KV7-M2612-01X FRAME L,Y AXIS 1
2-1 KV7-M2612-02X FRAME L,Y AXIS 1 (2006/7/25) MC70028 OK
2-2 Delete (2007/2/8) MD10036
3 KV7-M2671-00X SCREW BALL 2
3-1 KV7-M2671-01X SCREW BALL Y AXIS 2 2000/5/20 M9X0010 Set
3-2 KV7-M2671-02X SCREW BALL Y AXIS 2 2001/12/26 M160183 OK
3-3 KV7-M2671-03X SCREW BALL Y AXIS 2 with K1 seal 2002/11/28 M250068 NG
4 KG2-M9173-00X LOCK NUT 2
5 KV7-M264A-01X HOLDER SET, Y AXIS 2
6
7 KV7-M2243-00X HOUSING BRG. X 2
8 KV7-M2244-00X COVER BRB. HOUSING 2
9 KV7-M2645-00X BRG.,ANGULAR 2
9-1 90990-25J005 BEARING 2 (2007/12/4) MDX0031 OK
10 KV7-M2646-00X COIL SPRING M 12
11 KV7-M2647-00X OIL SEAL 4
12 KV7-M2648-00X SPACER 6
13 KV7-M2651-40X DAMPER 43 ASSY 2
13-1 KGA-M2651-41X DAMPER 24 ASSY 2 (2002/7/16) M270039 Set
14 KV7-M2651-30X DAMPER 35 ASSY 2
14-1 KGA-M2651-31X DAMPER 16 ASSY 2 (2002/7/23) M270069 Set
15 KV7-M2666-01X HOLDER NUT Y AXIS 2
16 KV7-M2682-01X DOG ORG 1
17 KV7-M2683-01X DOG 2ND LIMIT 2
18 KV7-M2691-01X BRACKET,SENSOR 1
18-1 KV7-M2691-02X BRACKET,SENSOR 1 (2004/9/1) MA90006 OK
19 KV7-M2694-00X BRACKET A GUIDE 1
20 KV7-M2695-01X BRACKET B GUIDE 1
21 KGA-M26F1-00X FRAME 1 1
22 KGA-M26F2-00X FRAME 2 1
23 KV7-M26F3-00X FRAME 3 1
24 KV7-M26F4-00X DUCT HARNESS 1
25 KV7-M26F5-01X BRACKET HARNESS 1
26 KV7-M653A-20X SENSOR 1 ASSY 1 L=300
26-1 KGA-M260A-00X SENSOR ORG 1 SQ01 (2002/11/12) M2X0034 OK
27 KV7-M653E-10X SENSOR 2 ASSY 1 L=300
27-1 KGA-M260B-00X SENSOR OT 1 SQ05 (2002/11/12) M2X0034 OK
28 KV7-M260A-00X TAPE. Y AXIS 1
29 KV7-M260B-00X TAPE. Y DUCT 1
30 KV7-M260C-00X TAPE 2. Y DUCT 1
31 KV7-M2667-00X PLATE 2
32 KV7-M2668-00X BRACKET 1. TAPE Y 1
33 KV7-M2669-00X BRACKET 2. TAPE Y 1
34 KV7-M2678-00X GUIDE.CABLE Y 1
35 90K52-8A174Y AC SERVO MOTOR 2
35-1 90K56-8A174Y AC SERVO MOTOR 2 M02,M11; Y1,Y2 (2000/8/28) M080110 OK
36 KV7-M2676-S1X Y-AXIS GUIDE SET 1
36-1 KV7-M2676-S2X Y-AXIS GUIDE SET 1 with K1 seal 2002/11/28 M250068 NG
37 KM5-M2611-00X COUPLING,Y-AXIS 1 LCD
37-1 KM5-M2611-00X COUPLING,Y-AXIS 2 LCD (2003/2/11) M320042 OK
38 KV7-M2661-00X NYLOCK BOLT 20 M12X50
38-1 90990-01J028 BOLT,HEX.SOCKET HEAD 20 M12X50 (2007/10/29) MD00030 OK
39 92907-12600 WASHER PLAIN 20
39-1 90201-124G9 WASHER PLAIN 20 (1999/9/28) M990079 OK
40 KV7-M2662-01X NYLOCK BOLT 16 M6X30
40-1 90990-01J029 BOLT,HEX.SOCKET HEAD 16 M6X30 (2007/10/29) MD00030 OK
41 KV7-M2698-00X PLATE 1. CLAMP 2
42 KV7-M2699-00X PLATE 2. CLAMP 1
43 KV7-M2663-00X NYLOCK BOLT 40 M5X16
43-1 90990-01J030 BOLT,HEX.SOCKET HEAD 40 M5X16 (2007/10/29) MD00030 OK
44 KV7-M260D-00X TAPE 3. Y DUCT 1
45 KV7-M2604-00X SUPPORT UNIT 2
46 KGA-M2649-00X NYLOCK BOLT 20 M2.6X10
46-1 KGA-M2649-00X NYLOCK BOLT 24 M2.6X10 (2001/2/27) M120136 OK
46-2 90990-01J023 BOLT,HEX.SOCKET HEAD 24 M2.6X10 (2007/10/29) MD00030 OK
47 KV8-M2611-00X COUPLING. Y-AXIS 1 LCD
47-1 Delete (2003/2/11) M320042
48 98903-03004 SCREW BINDING HEAD 4
49 98903-04006 SCREW BINDING HEAD 6
49-1 98904-04006 SCREW BINDING HEAD 6 (2001/12/6) M1X0135 OK
49-2 98902-04006 SCREW BINDING HEAD 6 (2006/1/9) MBY0166 OK
50 90159-04J01 SCREW, W/WASHER 6
50-1 90990-12J001 SCREW BIN.HEAD W/W 6 (2002/9/11) M290029 OK
51 98903-05010 SCREW BINDING HEAD 4
51-1 98904-05010 SCREW BINDING HEAD 4 (2001/12/6) M1X0135 OK
51-2 98902-05010 SCREW BINDING HEAD 4 (2006/1/9) MBY0166 OK
52 91314-04008 BOLT HEX, SOCKET HEAD 10
52-1 91312-04008 BOLT HEX, SOCKET HEAD 10 (2006/1/16) MBY0158 OK
53 91317-04008 BOLT HEX, SOCKET HEAD 2
54 91314-04010 BOLT HEX, SOCKET HEAD 12
54-1 91312-04010 BOLT HEX, SOCKET HEAD 12 (2006/1/16) MBY0158 OK
55 91317-04014 BOLT HEX, SOCKET HEAD 8
56 91317-04030 BOLT HEX, SOCKET HEAD 12
57 91317-05010 BOLT HEX, SOCKET HEAD 2
58 91317-05018 BOLT HEX, SOCKET HEAD 8
59 91314-06010 BOLT HEX, SOCKET HEAD 28
59-1 91312-06010 BOLT HEX, SOCKET HEAD 28 (2006/1/26) MBY0159 OK
60 91317-06018 BOLT HEX, SOCKET HEAD 16
61 KV7-M2651-00X DAMPER,STOPPER 2 SF head
62 KV7-M2651-10X DAMPER,STOPPER 2 SF head
63 KV7-M2652-00X BRACKET,STOPPER Y 2 SF head
64 KV7-M2652-10X BRACKET,STOPPER Y 2 SF head
65 KV7-M2653-00X PIN,PARALLEL 2 SF head
66 97704-40012 SRW TRUSS HEAD TAP'G 4 SF head
67 KV7-M2651-10X DAMPER,STOPPER 4 FNC head
68 KV7-M2652-00X BRACKET,STOPPER Y 4 FNC head
69 KV7-M2653-00X PIN,PARALLEL 4 FNC head
70 97704-40012 SRW TRUSS HEAD TAP'G 4 FNC head
61~70 Delete (2002/9/13) M290054
71 KM8-M2647-00X GREASE NIPPLE 2
71-1 Delete (2001/6/28) M160183
72 92907-04200 WASHER PLAIN 12
73 92903-06200 WASHER PLAIN 20
74 92990-06400 WASHER EXTL.TOOTHED 20
75 KV7-M2611-S0X FRAME,Y AXIS SET 1 (2007/2/8) MD10036
76 KV7-M2671-C0X Y AXIS B.S.SUB ASSY 2
76-1 KV7-M2671-A0X Y AXIS B.S.SUB ASSY 2 with K1 seal 2002/11/28 M250068 NG
31
37
45
35
60
5
3
15
58
28
21
36
36
23
51
51
38
39
55
20
40
32
2
50
41
42
29
44
30
34
59
10
9
54
11
4
56
56
72
22
18
31
48
33
41
26
27
53
38
39
1
25
57
16
49
17
49
19
11
12
12
7
8
24
50
5
43
43
40
37
47
45
13
35
5
3
15
40
10
72
9
11
14
4
11
12
12
7
8
46
5
40
56
52
60
55
58
60
54
72
56
13
46
46
14
46
76
76
61
63
66
65
64
62
72
73
74
59
73
74
59
2
1
OLD
36
36
3
14
13
71
3
14
13
71
67
68
70
69
OLD FNC
68
67
69
70
OLD FNC
OLD SF
OLD SF
OLD
OLD
1
5
Head (SF)
Head
KV7-1108
51
30
59
27
102
106
8
43
55
7
5
12
50
57
56
6
40
26
44
4
68
64
65
62
61
107
54
67
60
66
103
64
75
71
77
69
73
97
63
70
72
84
104
81
82
79
85
28
46
45
13
15
14
11
20
20
11
31
80
22
89
93
83
92
93
91
88
90
24
48
29
58
58
47
23
37
92
38
17
19
32
86
3
25
1
10
16
52
19
25
38
3
18
32
108
53
21
31
87
39
9
41
36
42
99
49
78
100
101
94
35
34
33
76
96
96
95
95
74
78
76
2
98
110
109
105
111
No. Part No. Part Name Q'ty Remarks Date of change Revised No. Compati.
1 KV7-M8101-00X BLOCK,HEAD 1
2 KV7-M8102-00X PLATE,HEAD 1
3 KV7-M8103-00X Z AXIS ASSY. 2 NSK
4 KV7-M8113-00X COUPLING,SHAFT 2
5 KV7-M8114-00X SHAFT,R AXIS 2
6 KV7-M8115-00X DOG,R AXIS 2
7 KV7-M8116-00X SHAFT,ENCODER 2
8 KV7-M8117-00X PULLEY,SHAFT HEAD 2
9 KV7-M8121-00X PLATE L,HEAD FIX 1
10 KV7-M8122-00X PLATE R,HEAD FIX 1
11 KV7-M8123-00X COUPLING,MOTOR 2
12 KV7-M8124-00X NUT,PLUG 2
13 KV7-M8127-00X STAY,STOPPER 1
14 KV7-M8128-00X STOPPER Z 1
15 KV7-M8129-00X COLLAR,STOPPER 2
16 KV7-M8131-00X STAY,EJECTOR 1
17 KV7-M8132-00X PULLEY,MOTOR R 2
18 KV7-M8133-00X PLATE,STOPPER 1
19 KV7-M8134-00X POST 2,SPG Z 2
20 KV7-M8135-00X POST 1,SPG Z 2
21 KV7-M8136-00X PLATE1,SENSOR Z 1
22 KV7-M8137-00X PLATE2,SENSOR Z 1
23 KV7-M8138-00X PLATE 1, R SENSOR 1
24 KV7-M8139-00X PLATE 2,R SENSOR 1
25 KV7-M8142-00X SPRING,RETURN 2
26 KV7-M8143-00X SPACER,ENCORDER 4
27 KV7-M8144-00X PLATE,ENCODER 2
28 KV7-M8145-00X BELT,R MOTOR 2
29 KV7-M8146-00X PLATE,BRG FIX 2
30 KV7-M8148-00X O-RING S9 2
30-1 90200-01J090 O-RING 2 (2001/11/27) M1X0094 OK
31 KV7-M8155-00X BLOCK,SENSOR Z 2
32 KV7-M8156-00X STAY,SPG POST 2
33 KV7-M8158-00X STAY,HANDLE 1
34 KV7-M8159-00X SHAFT,HANDLE 1
35 KV7-M8166-00X STAY,VACUUM SENSOR 1
36 KV7-M8167-00X JOINT,VACUUM SENSOR 2
37 KV7-M653A-30X SENSOR,1 ASSY. 2 L=450
38 KV7-M653A-40X SENSOR,1 ASSY. 2 L=300
39 KV7-M2256-00X GRIP 1
40 KG2-M7181-00X PACKIN MYA 4 2
40-1 90990-22J001 PACKING 2 (2002/1/21) M210051 OK
41 KM0-M7182-00X EJECTOR 1 ME072M2A-16W
42 KG2-M7198-01X O-RING 1-B 1 P3
42-1 90200-10J030 O-RING 1 (2001/11/22) M1X0060 OK
43 K67-M256J-00X BEARING 5 2 6904ZZ
43-1 90933-01J904 BEARING 2 (2001/7/6) M170033 OK
44 KM0-M9194-00X BEARING 2 6902ZZ
44-1 90933-01J902 BEARING 2 6902ZZ (2001/7/6) M170033 OK
45 90K50-4107GA AC SERVO MOTOR 1
45-1 90K55-4107GA AC SERVO MOTOR 1 (1999/6/14) M960053 OK
46 90K50-4107GB AC SERVO MOTOR 1
46-1 90K55-4107GB AC SERVO MOTOR 1 (1999/6/14) M960053 OK
47 90K50-4W073C AC SERVO MOTOR 1
47-1 90K55-4W073C AC SERVO MOTOR 1 (1999/6/14) M960053 OK
48 90K50-4W073D AC SERVO MOTOR 1
48-1 90K55-4W073D AC SERVO MOTOR 1 (1999/6/14) M960053 OK
49 91C00-03210 SPACER 2 M3X10L
49-1 90563-03J100 SPACER BOLT 2 (2001/9/1) M180147 OK
50 90185-00J00 NUT U 2 FU00SS(M10)
51 $TSR4-M5 JOINT 2
52 $TB4-01 JOINT 2
53 $SL8-01 JOINT 1
54 99080-05600 CIRCLIP 2
54-1 90440-10J050 CIRCLIP 2 (2001/12/28) M1Y0129 OK
55 99009-28800 CIRCLIP 2
56 99009-20800 CIRCLIP 2
57 KV7-M81C0-00X ENCODER ASSY. 2
58 KV8-M7125-00X FLANGE,MOTOR 2
59 KV7-M8169-00X SPACER COLLAR 2
60 KV7-M8104-00X HOUSING,SHAFT 1
61 KV7-M8105-00X SHAFT,MAIN 1
62 KV7-M8107-00X PLATE,BRG. 1
63 KV7-M8111-00X SPRING,SHAFT 1
64 KG9-M7143-00X BEARING 1 7904A5DB
64-1 90990-26J003 BEARING 1 (2007/12/6) MDX0068 OK
65 KV7-M8125-00X SPACER,BRG OUTER 1
66 KV7-M8126-00X SPACER,BRG INNNER 1
67 KG2-M7198-01X O-RING 1-B 1 P3
67-1 90200-10J030 O-RING 1 2001/11/27 M1X0094
68 90185-04J02 NUT U 1
69 KV7-M8106-00X SHAFT 1.SPLINE 1
70 KV7-M8108-00X GUIDE,SPRING 1
71 KV7-M8109-01X STOPPER,SHAFT 1 1
72 KV7-M8110-00X STOPPER,SHAFT 2 1
73 KV7-M8149-00X PLATE,WASHER 1
74 KV7-M8157-01X COLLAR,NOZZLE 1
75 KG5-M7166-00X PACKING 1 MYA-3
75-1 90990-22J014 PACKING 1 (2002/1/21) M210053 OK
76 KV7-M8171-00X PLATE,SPRING 4
77 99080-04600 CIRCLIP 1
77-1 90440-10J040 CIRCLIP 1 (2001/12/28) M1Y0129 OK
78 KV7-M81D0-00X NOZZLE ARM ASSY. 4
79 KV7-M8140-00X STAY,FID CAMERA 1
80 KV7-M8141-01X STAY,FID LIGHT 1
81 KV7-M7210-00X CCD CAMERA 1
81-1 KV7-M7210-01X CCD CAMERA 1 (2003/2/24) M320090 OK
82 KV7-M7211-00X LENS 095 1
83 KV7-M7600-00X FIDUCIAL LIGHT ASSY. 1
84 KL0-M66F0-21X C.CABLE ASSY 1 6m
84-1 KV7-M66F4-00X C.CABLE ASSY 1 1.7m (1999/5/26) M950080
85 90250-04J12 PIN PARALLEL 2 4X12
85-1 99480-04012 PIN,PARALLEL 2 X1 (2000/10/31) M000129 OK
86 KV7-M8160-00X STAY3,HEAD COVER 1
87 KV7-M8161-00X STAY2,HEAD COVER 1
88 KV7-M8162-00X COVER,HEAD 1
89 KV7-M8163-01X COVER,FID.CAMERA 1
89-1 KV7-M8163-02X COVER,FID.CAMERA 1 X4 (1999/5/24) M930133 OK
89-2 KV7-M8163-03X COVER,FID.CAMERA 1 X3 (2001/1/1) M040060 OK
90 KV7-M8164-00X STAY1,HEAD COVER 1
91 KV7-M8165-00X STAY,CABLE 1
92 91C00-04210 SPACER 2 M4X10L
92-1 90563-04J100 SPACER BOLT 2 (2001/9/4) M180150 OK
93 91C00-04215 SPACER 1 M4X15L
93-1 90563-04J150 SPACER BOLT 1 (2001/9/4) M180150 OK
94 95306-05600 NUT,HEXAGON 2
95 92D18-02006 BOLT HEX 2 M2X0.4X6
96 KG7-M7170-00X WASHER 2
97 91317-03012 BOLT HEX.SOCKET HEAD 4
98 91317-03008 BOLT HEX.SOCKET HEAD 4
99 KM1-M4592-11X VAC SENSOR BOARD ASS 2
99-1 KM1-M4592-12X VAC SENSOR BOARD ASS 2 (2001/9/30) M190105 OK
99-2 KM1-M4592-13X VAC SENSOR BOARD ASS 2 (2005/4/19) MB40065 OK
100 KH5-M7182-C0X FILTER 2
101 KH5-M7182-D0X O-RING 4
101-1 90990-17J006 O-RING 4 (2001/11/22) M1X0064 OK
102 KV7-M8172-00X SCREW 6 M2.5X4
102-1 90990-08J011 SCREW,PAN HEAD 6 (2007/11/9) MD00082 OK
103 98780-03008 SCREW,FLAT HEAD 1
104 KV7-M66F2-00X C.CABLE ASSY 1 6mm
105 KV7-M811S-A0X SPLINE SHAFT1 SPARE 1
106 KV7-M812H-A0X ENCODER SPARE 1
107 KV7-M813H-A0X HOLDER SHAFT SPARE 1
108 KM0-M7182-C0X FILTER CAP 1
109 KM0-M7182-A0X VALVE 1
110 KM1-M7163-20X VALVE 1
111 KM0-M7182-B0X EJCTOR 2
