Contents
KV7-0807
1
Base Section
Base
...............................................................1-1
2
Cover Section
Top Cover
.......................................................2-1
Base Cover.....................................................2-2
3
Feeder Section
Feeder Holder E
.............................................3-1
Feeder Holder H
............................................. 3-2
Feeder Holder B
.............................................3-3
Feeder Floating Detection(20)........................3-4
4
Moving-axis Section
X-axis
.............................................................4-1
Y-axis (SF/FNC)
.............................................4-2
5
Head Section
Head (SF)
....................................................... 5-1
Body Head (FNC)
........................................... 5-2
Head (FNC)
....................................................5-3
6
Nozzle Section
Body ANC (SF)
...............................................6-1
Body ANC (FNC)
............................................6-2
Nozzle Selection (ANC)..................................6-3
Nozzle Selection (FNC)
.................................. 6-4
7
Conveyor Unit Section
Push-In
...........................................................7-1
Push-Up
.........................................................7-2
Locate-Pin
......................................................7-3
Main stopper / Sub stopper
............................7-4
Clamp board Positioning
................................7-5
Edge Clamp....................................................7-6
Main Conveyor
...............................................7-7
8
Light Section
Front Light
......................................................8-1
Front Light (Option)
........................................8-2
9
Control Section
Main Box
........................................................9-1
Main Box (YTF.ATS)
.......................................9-2
10
Exterior,etc. Section
Monitor, etc
................................................... 10-1
I/O Board, etc.
..............................................10-2
1
1
Base
Base
KV7-080221
25
56
28
56
57
55
54
63
63
52
53
16
7
25
29
5
45
3
7
33
37
34
30
49
51
50
10
11
9
14
26
6
46
28
41
48
33
34
37
24
44
19
8
21
21
1
22
20
4
31
36
15
17
32
2
24
13
12
40
42
38
39
25
23
35
18
60
46
44
OLD
OLD
62
61
47
SF
FNC
No. Part No. Part Name Q'ty Remarks Date of change Revised No. Compati.
1 KV7-M1101-00X BASE 1
1-1 KV7-M1101-01X BASE 1 (1999/11/30) M9X0107 OK
1-2 KV7-M1101-02X BASE 1 (2000/1/19) M010047 OK
1-3 KV7-M1101-03X BASE 1 (2000/2/17) M020073 OK
1-4 KV7-M1101-04X BASE 1 (2000/5/9) M040198 OK
2 KV7-M1120-00X PLATE 10 1 CONNECTOR
2-1 KV7-M1120-01X PLATE 10 1 CONNECTOR (1999/11/30) M9X0107 OK
3 KV7-M1112-00X PLATE 2 1
3-1 KV7-M1112-01X PLATE 2 1 (2007/12/3) MDX0013 OK
4 KV7-M1113-00X PLATE 3 1 VALVE
4-1 KGA-M1113-00X PLATE 3 1 VALVE (2003/5/10) M350060 OK
5 KV7-M1114-00X PLATE 4 1 I/O
5-1 KV7-M1114-01X PLATE 4 1 I/O (2007/12/3) MDX0013 OK
6 KV7-M1115-00X PLATE 5 1 AIR
6-1 Delete (2001/5/28) M150099
7 KM0-M1141-00X MANUFOLD 2
8 KG7-M1342-01X BRACKET,F/D 1
9 KG7-M8501-00X AIR FILTER 1
10 KG7-M8502-00X MIST FILTER 1
11 KG7-M8503-00X MODULE ADAPTER 1
12 KG7-M8504-00X REGULATOR 1 R300-03
13 KG7-M8512-00X JOINT 1
14 KG7-M8513-00X JOINT 1
15 KM0-M8582-00X VALVE 1 040M12AJ1-7
16 KG7-M8596-00X PRESSURE GAUGE 1
17 KV7-M1118-00X PLATE 8 1
18 KV7-M1125-00X PLATE CLAMP 1
19 KG2-M1128-00X BRACKET SPEED CONT. 1
20 KM0-M1142-00X CASTER 6
20-1 Delete (Option) (2001/9/28) M190104
21 KM0-M1151-01X PLATE SIDE 1 1
21-1 KM0-M1151-02X PLATE,SIDE 1 1 (2007/6/6) MD50118 Set
22 KM0-M1152-01X PLATE SIDE 2 1
23 KM0-M1153-01X PLATE SIDE 3 1
24 KM0-M1154-01X PLATE BOTOM 1 2
25 $SL12-03 JOINT 3
26 $SLY10-03 JOINT 1
27 $TSH4-M5 JOINT 1
27-1 Delete (2006/8/8) MC80027
28 $TL4-02 JOINT 1
29 $UEDW10-8 JOINT 1
30 $USD10-8 JOINT 1
31 $SL8-01 JOINT 1
32 $KM-11 MUFFLER 1
33 $TSS4-01 JOINT 12
34 $TSH8-01 JOINT 2
35 KM5-M4184-00X COVER,NOISE FILTER 1
35-1 Delete (2001/2/7) M120037
36
KU0-M1180-00X LEVELING BOLT ASSY. 6
36-1 KV7-M1180-00X LEVELING BOLT ASSY. 6 (1999/4/28) M940123 OK
36-2 KV7-M1180-01X LEVELING BOLT ASSY 6 (2000/2/4) M020021 OK
37 K40-M8598-00X PLUG 1 2
38 91C00-03210 SPACER 28 M3X10L
38-1 90563-03J100 SPACER BOLT 28 (2001/9/1) M180147 OK
39 KH5-M8501-00X EXHAUST VALVE 1
40 KH5-M8531-00X FITTING 1 1
40-1 Delete (2000/5/11) M050024
41 $KM-23 MUFFLER 1
42 91C00-03220 SPACER 4 M3X20L
42-1 90563-03J200 SPACER BOLT 4 (2001/9/4) M180149 OK
43
44 KV7-M1116-00X PLATE 6 1
44-1 KV7-M1116-01X PLATE 6 1 1999/5/7 M930044 NG
45 KV7-M1161-00X PLATE 11 1 TRANS
46 KV7-M1113-10X PLATE 3-1 1 REG
46-1 KV7-M1113-11X PLATE 3-1 1 REG 2000/12/8 M050024 NG
47 KV7-M1153-00X PLATE,SIDE 3 1
47-1 KGS-M1153-50X PLATE,SIDE 3 1 (2005/11/17) MBX0075 OK
48 KV7-M111A-00X BRACKET,GAUGE 1
49 $UED8-4 JOINT 1
50 $UP8 JOINT 1
51 $UP4 JOINT 3
52 KG7-M8502-40X MIST FILTER ELEMENT 1 SPARE
53 KG7-M8501-40X AIR FILTER ELEMENT 1 SPARE
54 KG7-M8504-00X REGULATOR 1 R300-03
55 KM4-M8589-00X GAUGE 1 GP1-40
56 $UY4 JOINT 1
57 $UY12 JOINT 1
58 $SL10-03 JOINT 1
59 $UC4 JOINT 1
60 KG2-M8582-40X VALVE 1 SPARE
61 KV7-M1153-A0X PLATE SIDE3 ASSY. 1
62 KV7-M1153-10X PLATE,SIDE 3 1
63 KV7-M1325-01X BRACKET 5 1 (2002/4/2) M230160
1
2
Top Cover
Cover
KV7-090928
31
21
9
28
22
28
22
20
3
30
28
28
30
11
22
26
29
11
23
25
11
10
27
19
9
22
16
20
25
34
23
14
31
32
2
33
31
32
6
21
31
32
23
7
15
10
5
1
25
5
29
8
10
13
10
23
12
25
17
19
30
16
25
4
21
20
18
32
18
21
30
35
25
20
17
25
11
24
25
36
37
No. Part No. Part Name Q'ty Remarks Date of change Revised No. Compati.
1 KV7-M1301-A0X COVER 1 ASSY 1
2 KV7-M1302-A0X COVER 2 ASSY 1
3 KV7-M1303-A0X COVER 3 ASSY 1
4 KV7-M1304-A0X COVER 4 ASSY 1
5 KV7-M1305-00X COVER 5 2
6 KV7-M1306-A0X COVER 6 ASSY 1
6-1 KV7-M1306-A1X COVER 6 ASSY 1 (2000/10/2) M070225 OK
7 KV7-M1307-A0X COVER 7 ASSY 1
8 KV7-M1308-A0X COVER 8 ASSY 1
9 KV7-M1309-00X
COVER 9
2
9-1 KV7-M1309-01X COVER 9 2 (2000/10/2) M070225 OK
10 KM0-M1322-00X PLATE PLUG 4
11 KM0-M1331-01X BRACKET ,GAS DAMPER 4
12 KM8-M1338-01X BRACKET MAIN SWITCH 1
13 KV7-M1336-00X BKT CORNER L,BACK 1
14 KV7-M1337-00X BKT CORNER L,FRONT 1
15 KV7-M1339-00X BKT CORNER R,BACK 1
16 KV7-M1340-00X BRACKET 1 COVER 9 2
16-1 KV7-M1340-01X BRACKET 1,COVER 9 2 (2000/10/2) M070225 OK
17 KV7-M1341-00X BRACKET 2 COVER 9 2
17-1 KV7-M1341-01X BRACKET 2,COVER 9 2 (2000/10/2) M070225 OK
17-2 KV7-M1341-02X BRACKET 2,COVER 9 2 (2001/3/28) M130152 OK
18 KV7-M1342-00X BRACKET 3,COVER 9 2
19 KV7-M1343-00X BRACKET 4,COVER 9 2
19-1 KV7-M1343-01X BRACKET 4,COVER 9 1 (2000/10/20) M000027 OK
20 KV7-M1349-00X PLATE 2 NUT 4
21 K46-M1374-10X HINGE 2 4
21-1 K46-M1374-11X HINGE 2 4 (2009/7/13) MF70096 OK
22 KH2-M1324-00X GRIP 4
23 KL3-M1348-10X GAS SPRING 4
24 KH5-M13B1-10X BRACKET KEYBOARD 1
24-1 KGA-M13B1-00X BRACKET,KEYBOARD 1 2002/9/11 M250065 NG
24-2 KGA-M13B1-10X STAY KEYBOARD 1 (2005/12/5) MBX0153 NG
25 KM0-M1346-00X SHOULDER,BOLT 8
26 KL0-M1318-00X COVER 18 1
27 KH1-M13A9-00X BUSH 1
28 K93-M1392-00X SPACER 4 TM-180-303
29 KV7-M1329-00X COVER 29 2
30 KM0-M1335-00X BKT 1 GATE COVER 4
31 KM0-M1332-00X BRACKET MAGNET 4
31-1 KM0-M1332-01X BRACKET MAGNET 4 (2001/9/18) M190064 OK
32 K93-M1388-00X MG.CATCH 4 TL-77S
32-1 KV5-M1130-00X CATCH MG. 4 (2001/9/18) M190064 OK
33 KV7-M13D6-00X SEAL 1 1
33-1 KV7-M13D6-01X SEAL 1 1 YV88X (2004/7/26) MA70105 OK
34 KV7-M13D7-00X SEAL 2 1
34-1 KW7-M13D7-01X SEAL 2 1 YAMAHA (2004/7/28) MA70116 OK
35 KV7-M1350-00X CAP,PATLIGHT 1
36 KL3-M1381-01X PLATE 1 KEY BOARD 1
36-1 KL3-M1381-02X PLATE 1 KEY BOARD 1 (2001/3/28) M130152 OK
37 KL3-M1382-00X PLATE 2 KEY BOARD 1
37-1 KL3-M1382-01X PLATE 2 KEY BOARD 1 (2001/3/28) M130152 OK
