4 3 Feeder Floating Detection 20 Feeder KV7-1 107 8 5 3 4 1 2 2 3 6 7 8 8 4 1 2 2 8 FES Left FES Right No. Part No. Part Name Q'ty Remarks Date of change Revised No. Compati. 1 KV7-M3901-00X BRACKET SENSOR2 2 2 KG7-…
3
3
Feeder Holder B (16)
Feeder
KV7-080410
No. Part No. Part Name Q'ty Remarks Date of change Revised No. Compati.
1
KG2-M3401-B2X PLATE B,FEEDER
1
1-1
KG2-M3401-B3X PLATE B,FEEDER
1
(2005/2/14) MB20042 NG
2
KM0-M3402-B0X GUIDE B-1.TAPE
1
3
KG2-M3403-B1X GUIDE B-2,TAPE
1
4
KM0-M3405-01X STAND,1
1
Fig D
4-1
KM0-M3405-02X STAND,1
1
Fig E (2004/4/20) M440062 OK
4-2
KM0-M3405-03X STAND,1
1
Fig F (2004/11/1) MA00129 NG
5
KM0-M3406-01X STAND,2
1
Fig G
5-1
KM0-M3406-02X STAND,2
1
Fig H (2004/11/1) MA00129 NG
6
KM0-M3408-B0X BRACKET B.VALVE
1
7
KL0-M3409-B1X COVER B VALVE
1
8
KM5-M3410-20X VALVE ASSY.R
1
8-1
KGA-M3410-30X VALVE ASSY.16-R
1
(2003/2/5) M320011 OK
10
$BF4BU JOINT
16
14
91317-06020 BOLT HEX.SOCKET HEAD
4
15
91317-04010 BOLT HEX.SOCKET HEAD
12
16
90990-12J005 SCREW BINDING HEAD
8
17
KG2-M3407-A0X AIR JOINT
16
18
KM0-M3416-00X GASKET
16
18-1
Delete (2005/2/14) MB20042
19
98907-03004 SCREW.BINDING HEAD
16
19-1
Delete (2005/2/14) MB20042
20
91317-08020 BOLT.HEX SOCKET HEAD
4
21
91317-03006 BOLT.HEX SOCKET HEAD
4
22
KM0-M3417-00X GUIDE4
2
24
KGA-M37P0-00X VALVE KIT 1 SPARE PARTS
25
KM8-M34B0-00X FEEDER PLATE ASSY.
1
25-1
KM8-M34B0-01X FEEDER PLATE ASSY.16
1
(2004/4/20) M440062 NG
Fig D Fig E Fig F
16mm
16mm
20mm
Fig G Fig H
16mm
20mm
50mm
38mm
22
15
3
15
21
20
20
6
2
15
22
16
15
24
4
5
16
16
16
7
15
1
14
14
10
25
17
8
19
18
OLD
10
17
25
1
OLD
4
3
Feeder Floating Detection 20
Feeder
KV7-1107
8
5
3
4
1
2
2
3
6
7
8
8
4
1
2
2
8
FES Left
FES Right
No. Part No. Part Name Q'ty Remarks Date of change Revised No. Compati.
1 KV7-M3901-00X BRACKET SENSOR2 2
2 KG7-M3906-00X BRACKET 6 4
3 KV7-M3910-01X BRACKET SENSOR,1 2
4 KG9-M3455-30X SENSOR S 2
5 KG2-M3903-00X SEAL, CAUTION 1
6 KM5-M3941-00X BRACKET 4-1, SENSOR R 1
7 KM9-M3941-00X BRACKET 4-2, SENSOR R 1
8 KM5-M3456-30X SENSOR R(L=800) 2
1
4
X-axis
Moving-axis
KV7-080617
19
47
34
33
15
66
10
64
4
14
72
28
28
54
27
26
11
63
45
36
44
16
17
25
58
60
18
29
22
23
56
5
5
1
68
68
44
45
43
13
59
65
9
9
6
5
31
35
30
24
24
38
37
42
40
41
40
12
41
46
29
66
23
56
50
55
48
51
49
66
50
48
49
51
53
8
7
39
62
61
67
59
56
21
20
59
35
32
67
52
43
OLD
70
71
69
3
2
14
27
26
OLD
18
9
9
7
OLD
No. Part No. Part Name Q'ty Remarks Date of change Revised No. Compati.
1 KV7-M2211-02X FRAME X AXIS 1
2 KV7-M2213-02X PLATE A,X AXIS 1
2-1 Delete (2000/2/3) M020009
3 KV7-M2214-02X PLATE B,X AXIS 1
3-1 Delete (2000/2/3) M020009
4 KM0-M2220-00X COUPLING, X-AXIS 1
5 KV7-M2231-00X SPACER R.NUT 3
6 KM0-M2233-00X SPACER R2 NUT 1
6-1 KV7-M2233-00X SPACER R2,NUT 1 (2003/2/11) M320049 OK
7 KV7-M2236-00X PLATE A 1
7-1 KV7-M2236-01X PLATE A 1 (2008/3/27) ME30100 SET
8 KV7-M2237-00X SUB PLATE 1
9 KV7-M2239-00X BRACKET 1 2
9-1 KV7-M2239-01X BRACKET 1 2 (2008/3/27) ME30100 SET
10 KM0-M2241-00X HOLDER, MOTOR 1
11 KV7-M2242-00X HOLDER, BRG. X AXIS 1
12 KV7-M2645-00X BRG.,ANGULAR 1
12-1 90990-25J005 BEARING 1 (2007/12/4) MDX0031 OK
13 KV7-M2261-00X HOLDER, HEAD 1
13-1 KV7-M2261-01X HOLDER, HEAD 1 (2002/4/25) M240093 OK
14 KV7-M2271-00X SCREW BALL X AXIS 1
14-1 KV7-M2271-01X SCREW BALL X AXIS 1 1999/11/3 M9X0010 Set
14-2 KV7-M2271-02X SCREW BALL X AXIS 1 with/K1 seal (2002/6/6) M250068 Set
15 90K52-87174X AC SERVO MOTOR 1
15-1 90K56-87174X AC SERVO MOTOR 1 (2000/8/28) M080110 OK
15-2 90K56-8717EX AC SERVO MOTOR 1 (2003/4/18) M340073 OK
16 KV7-M653A-00X SENSOR, 1 ASSY 1 L=600
16-1 KGA-M220A-00X SENSOR , ORG 1 L=600 (2002/11/12) M2X0034 OK
17 KV7-M653E-00X SENSOR, 2 ASSY 1 L=600
17-1 KGA-M220B-00X SENSOR , OT(L=600) 1 L=600 (2002/11/12) M2X0034 OK
18 K47-M2276-S0X X-AXIS GUIDE SET 1
18-1 KV7-M2276-S0X X-AXIS GUIDE SET 1 with/K1 seal (2002/6/6) M250068 Set
19 KV7-M2267-01X CABLE. DUCT 1
19-1 KV7-M2267-A1X CABLE DUCT 1 (2004/7/12) MA70035 OK
20 K94-M220A-00X TAPE X-AXIS 1
21 K94-M220A-10X TAPE X-AXIS 1
22 KV7-M2282-00X DOG. ORG 1
23 KV7-M2283-00X DOG. 2ND LIMIT 2
24 KV7-M226B-00X PLATE 2
25 KV7-M2291-00X BRACKET, SENSOR 1
26 KGA-M2651-10X DAMPER 14 ASSY 1
26-1 KGA-M2651-11X DAMPER 14 ASSY 1 (2002/6/6) M250068 Set
27 KGA-M2651-60X DAMPER 120 ASSY 1
27-1 KGA-M2651-61X DAMPER 105 ASSY 1 (2002/6/6) M250068 Set
28 KGA-M2649-00X NYLOCK BOLT 12 M2.6
28-1 KGA-M2649-00X NYLOCK BOLT 24 M2.6X10 (2001/2/27) M120136 OK
28-2 90990-01J023 BOLT,HEX.SOCKET HEAD 24 (2007/10/29) MD00030 OK
29 KM0-M2251-00X NYLOCK BOLT 16 M8X22L
29-1 90990-01J024 BOLT,HEX.SOCKET HEAD 16 (2007/10/29) MD00030 OK
29-2 90990-01J179 BOLT,HEX.SOCKET HEAD 16 (2020/1/24) MT10096 OK
30 KV7-M226A-00X COVER CABLE 1
31 KV7-M2268-00X BRACKET 1, TAPE 1
32 KV7-M2269-00X BRACKET 2, TAPE 1
33 KV7-M220A-01X TAPE, X DUCT 1
34 KV7-M220B-00X TAPE 2, X DUCT 1
35 KV7-M2266-00X PLATE.NUT 2
36 KV7-M2240-00X SLEEVE.BRG. 1
37 KV7-M2243-00X HOUSING, BRG. X 1
38 KV7-M2244-00X COVER, BRG. HOUSING 1
39 KV7-M2246-00X COIL SPRING M 6
40 KV7-M2647-00X OIL SEAL 2
41 KV7-M2648-00X SPACER 3
42 KG2-M9173-00X LOCK NUT 1
43 KV7-M2663-00X NYLOCK BOLT(M5X16) 16
43-1 90990-01J030 BOLT,HEX.SOCKET HEAD 16 (2007/10/29) MD00030 OK
44 KV7-M2256-00X GRIP 2
45 KV7-M2257-00X SPACER GRIP 2
46 KV7-M220C-00X TAPE 3, X DUCT 1
47 KV7-M221A-A0X COVER, DUCT ASSY 1
48 KV7-M2295-01X BRACKET, PIN 2
48-1 Delete (2002/7/19) M270057
49 KV7-M2296-00X BRACKET, SCREW 2
49-1 Delete (2002/7/19) M270057
50 KV7-M2297-00X TAPER PIN 4
50-1 Delete (2002/7/19) M270057
51 KV7-M2298-00X NYLOCK SET SCREW 6
51-1 Delete (2002/7/19) M270057
52 KM0-M2252-00X STOPPER 1
53 99480-06014 PIN, PARALLEL 2
54 KV7-M2604-00X SUPPORT UNIT 1 1999/11/3 M9X0010 SET
55 KV7-M2253-00X WASHER, SPRING 16
56 91317-03006 BOLT HEX. SOCKET HEAD 6
57
58 91317-04008 BOLT HEX. SOCKET HEAD 12
59 91317-04010 BOLT HEX.SOCKET HEAD 26
59-1 91317-04010 BOLT HEX.SOCKET HEAD 4 (2002/2/28) M220145 OK
60 KV7-M2251-00X NYLOCK BOLT(M4X16) 30
60-1 91317-04016 BOLT HEX.SOCKET HEAD 30 (2005/2/7) MB20025 OK
61 91317-04030 BOLT HEX. SOCKET HEAD 6
62 91317-05014 BOLT HEX. SOCKET HEAD 4
63 91317-05020 BOLT HEX. SOCKET HEAD 4
64 91317-05035 BOLT HEX. SOCKET HEAD 4
65 91317-06012 BOLT HEX. SOCKET HEAD 8
66 91317-06018 BOLT HEX.SOCKET HEAD 8
66-1 91317-06018 BOLT HEX.SOCKET HEAD 26 (1999/5/20) M950078 OK
66-2 91317-06018 BOLT HEX.SOCKET HEAD 4 (2002/3/25) M230122 OK
66-3 91317-06018 BOLT HEX.SOCKET HEAD 8 (2002/7/19) M270057 OK
67 98907-03005 SCREW BINDING HEAD 4
67-1 98902-03006 SCREW BINDING HEAD 4 (2007/7/9) MD60168 OK
68 KV7-M2213-S0X PLATE X AXIS SET 1 (2000/2/3) M020009
69 KV7-M2247-00X BLOCK,STOPPER X 1
70 KV7-M2248-00X DAMPER 2 1
70-1 1 Delete (2002/7/19) M270057
71 KV7-M2248-00X DAMPER 1 1
71-1 1 Delete (2002/7/19) M270057
72 KV7-M2271-A0X X AXIS B.S.SUB ASSY 1 (2005/8/2) MB30076
