1 1 Base Base KV6-080617 47 16 7 25 29 5 45 3 7 33 37 34 30 49 51 50 10 1 1 9 14 26 6 46 28 41 48 33 34 37 24 44 19 8 21 21 1 43 22 20 4 31 36 15 17 32 2 24 13 12 40 39 25 23 35 18 52 53 54 38 42 OLD OLD 46 No. Part No. …
Contents
KV6-0807
1 Base Section
Base ................................................................1-1
2 Cover Section
Top Cover ........................................................2-1
Base Cover ......................................................2-2
3 Moving-axis Section
X-axis ..............................................................3-1
Y-axis ..............................................................3-2
4 Head Section
Body Head ......................................................4-1
Head Holder ...................................................4-2
5 Nozzle Section
Nozzle Selection .............................................5-1
6 Attachment Section
Attachment 10cc .............................................6-1
Attachment 30cc .............................................6-2
7 Conveyor Unit Section
Push-In ............................................................ 7-1
Push-Up ..........................................................7-2
Locate-Pin .......................................................7-3
Main stopper / Sub stopper .............................. 7-4
Board Clamp ...................................................7-5
Edge Clamp ..................................................... 7-6
Main Conveyor ...............................................7-7
8 Thermo Control Box Section
Thermo Control Box ........................................8-1
9 Spare Parts Kit Section
Spare Parts Kit .................................................9-1
10 Mainte Accessory Section
Mainte Accessory ..........................................10-1
11 Control Section
Main Box ......................................................11-1
12 Dot Station Section
Dot Station ....................................................12-1
13 Exterior, etc
Monitor, etc ...................................................13-1
1
1
Base
Base
KV6-080617
47
16
7
25
29
5
45
3
7
33
37
34
30
49
51
50
10
11
9
14
26
6
46
28
41
48
33
34
37
24
44
19
8
21
21
1
43
22
20
4
31
36
15
17
32
2
24
13
12
40
39
25
23
35
18
52
53
54
38
42
OLD
OLD
46
No. Part No. Part Name Q'ty Remarks Date of change Revised No. Compati.
1 KV7-M1101-00X BASE 1
1-1 KV7-M1101-01X BASE 1 (1999/11/30) M9X0107 OK
1-2 KV7-M1101-02X BASE 1 (2000/1/19) M010047 OK
1-3 KV7-M1101-03X BASE 1 (2000/2/17) M020073 OK
1-4 KV7-M1101-04X BASE 1 (2000/5/9) M040198 OK
2 KV7-M1120-00X PLATE 10 1 CONNECTER
2-1 KV7-M1120-01X PLATE 10 1 CONNECTER (1999/11/30) M9X0107 OK
3 KV7-M1112-00X PLATE 2 1
3-1 KV7-M1112-01X PLATE 2 1 (2007/12/3) MDX0013 OK
4 KV7-M1113-00X PLATE 3 1 VALVE
4-1 KGA-M1113-00X PLATE 3 1 VALVE (2003/5/10) M350060 OK
5 KV7-M1114-00X PLATE 4 1 I/O
5-1 KV7-M1114-01X PLATE 4 1 I/O (2007/12/3) MDX0013 OK
6 KV7-M1115-00X PLATE 5 1 AIR
6-1 Delete (2001/5/28) M150099
7 KM0-M1141-00X MANUFOLD 2
8 KG7-M1342-01X BRACKET,F/D 1
9 KG7-M8501-00X AIR FILTER 1
10 KG7-M8502-00X MIST FILTER 1
11 KG7-M8503-00X MODULE ADAPTER 1
12 KG7-M8504-00X REGULATOR 1 R300-03
13 KG7-M8512-00X JOINT 1
14 KG7-M8513-00X JOINT 1
15 KM0-M8582-00X VALVE 1 040M12AJ1-7
16 KG7-M8596-00X PRESSURE GAUGE 1
17 KV7-M1118-00X PLATE 8 1
18 KV7-M1125-00X PLATE CLAMP 1
19 KG2-M1128-00X BRACKET SPEED CONT. 1
20 KM0-M1142-00X CASTER 6
20-1 Delete (Option) (2001/9/28) M190104
21 KM0-M1151-01X PLATE SIDE 1 1
21-1 KM0-M1151-02X PLATE,SIDE 1 1 (2007/6/6) MD50118 NG
22 KM0-M1152-01X PLATE SIDE 2 1
23 KM0-M1153-01X PLATE SIDE 3 1
24 KM0-M1154-01X PLATE BOTOM 1 2
25 $SL12-03 JOINT 2
26 $SLY10-03 JOINT 1
27 $TSH4-M5 JOINT 1
28 $TL4-02 JOINT 1
29 $UEDW10-8 JOINT 1
30 $USD10-8 JOINT 1
31 $SL8-01 JOINT 1
32 $KM-11 MUFFLER 1
33 $TSS4-01 JOINT 12
34 $TSH8-01 JOINT 2
35 KM5-M4184-00X COVER NOISE FILTER 1
35-1 Delete (2001/2/7) M120037
36 KV7-M1180-00X LEVELING BOLT ASSY. 6
36-1 KV7-M1180-01X LEVELING BOLT ASSY 6 (2000/2/4) M020021 OK
37 K40-M8598-00X PLUG 1 2
38 91C00-03210 SPACER 28 M3X10L
38-1 90563-03J100 SPACER BOLT 28 (2001/9/1) M180147 OK
38-2 90563-03J100 SPACER BOLT 10 (2007/12/3) MDX0013 OK
39 KH5-M8501-00X EXHAUST VALVE 1
40 KH5-M8531-00X FITTING 1 1
40-1 Delete (2000/5/11) M050024
41 $KM-23 MUFFLER 1
42 91C00-03220 SPACER 4 M3X20L
42-1 90563-03J200 SPACER BOLT 4 (2001/9/4) M180149 OK
43 KV7-M6561-A0X POWER SUPPLY ASSY 1
44 KV7-M1116-01X PLATE6 1
44-1 Delete (2001/6/21) M160124
45 KV7-M1161-00X PLATE 11 1 TRANS
46 KV7-M1113-10X PLATE 3-1 1 REG
46-1 KV7-M1113-11X PLATE 3-1 1 REG 2000/8/10 M050024 NG
47 KV7-M1153-00X PLATE,SIDE 3 1
47-1 KGS-M1153-50X PLATE,SIDE 3 1 (2005/11/17) MBX0075 OK
48 KV7-M111A-00X BRACKET,GAUGE 1
49 $UED8-4 JOINT 1
50 $UP8 JOINT 1
51 $UP4 JOINT 2
52 KG7-M8502-40X MIST FILTER ELEMENT 1 SPARE
53 KG7-8501-40X AIR FILTER ELEMENT 1 SPARE
54 KG2-M8582-40X VALVE 1 SPARE
1
2
Top Cover
Cover
KV6-080617
31
21
9
28
22
28
22
20
3
30
28
28
30
11
22
26
29
11
23
25
11
10
27
19
9
22
16
20
25
34
23
14
31
32
2
33
31
32
6
21
31
32
23
7
15
10
5
1
25
5
29
8
10
13
10
23
12
25
17
19
30
16
25
4
21
20
18
32
18
21
30
35
25
20
17
25
11
25
37
36
38
36
38
24
40
40
39
39
24
OLD
OLD
No. Part No. Part Name Q'ty Remarks Date of change Revised No. Compati.
1 KV7-M1301-A0X COVER 1 ASSY 1
2 KV7-M1302-A0X COVER 2 ASSY 1
3 KV7-M1303-A0X COVER 3 ASSY 1
4 KV7-M1304-A0X COVER 4 ASSY 1
5 KV7-M1305-00X COVER 5 2
6 KV7-M1306-A0X COVER 6 ASSY 1
6-1 KV7-M1306-A1X COVER 6 ASSY 1 (2000/10/2) M070225 OK
7 KV7-M1307-A0X COVER 7 ASSY 1
8 KV7-M1308-A0X COVER 8 ASSY 1
9 KV7-M1309-00X COVER 9 2
9-1 KV7-M1309-01X COVER,9 2 (2000/10/2) M070225 OK
10 KM0-M1322-00X PLATE PLUG 4
10-1 Delete (2001/8/1) M180003
11 KM0-M1331-01X BRACKET ,GAS DAMPER 4
12 KM8-M1338-01X BRACKET MAIN SWITCH 1
13 KV7-M1336-00X BKT CORNER L,BACK 1
14 KV7-M1337-00X BKT CORNER L,FRONT 1
15 KV7-M1339-00X BKT CORNER R,BACK 1
16 KV7-M1340-00X BRACKET 1 COVER 9 2
16-1 KV7-M1340-01X BRACKET 1,COVER 9 2 (2000/10/2) M070225 OK
17 KV7-M1341-00X BRACKET 2 COVER 9 2
17-1 KV7-M1341-01X BRACKET 2,COVER 9 2 (2000/10/2) M070225 OK
17-2 KV7-M1341-02X BRACKET 2,COVER 9 2 (2001/3/28) M130152 OK
18 KV7-M1342-00X BRACKET 3,COVER 9 2
19 KV7-M1343-00X BRACKET 4,COVER 9 2
19-1 KV7-M1343-01X BRACKET 4,COVER 9 2 (2000/10/20) M000027 OK
20 KV7-M1349-00X PLATE 2 NUT 4
21 K46-M1374-10X HINGE 2 4
21-1 K46-M1374-12X HINGE 2 4 (2013/2/13) MK20039 OK
22 KH2-M1324-00X GRIP 4
23 KL3-M1348-10X GAS SPRING 4
24 KH5-M13B1-10X BRACKET KEYBOARD 1
24-1 KGA-M13B1-00X BRACKET,KEYBOARD 1 2002/12/4 M250065 NG
25 KM0-M1346-00X SHOULDER,BOLT 8
26 KL0-M1318-00X COVER 18 1
27 KH1-M13A9-00X BUSH 1
28 K93-M1392-00X SPACER 4 TM-180-303
29 KV7-M1329-00X COVER 29 2
30 KM0-M1335-00X BKT 1 GATE COVER 4
31 KM0-M1332-00X BRACKET MAGNET 4
31-1 KM0-M1332-01X BRACKET MAGNET 4 (2001/9/18) M190064 OK
32 K93-M1388-00X MG.CATCH 4 TL-77S
32-1 KV5-M1130-00X CATCH MG. 4 (2001/9/18) M190064 OK
33 KV6-M13D6-00X SEAL 1 1
33-1 KV6-M13D6-01X SEAL 1 1 HSD-X (2004/7/26) MA70105 OK
34 KV7-M13D7-00X SEAL 2 1
34-1 KW7-M13D7-01X SEAL 2 1 YAMAHA (2004/7/28) MA70116 OK
35 KV7-M1350-00X CAP,PATLIGHT 1
36 KV6-M1333-00X BRKT.1.COVER REAR 2
36-1 KV6-M1333-01X BRKT.1,COVER REAR 2 (2001/3/28) M130162 NG
37 KV6-M1332-00X COVER.REAR 1
38 KV7-M1344-00X BRACKET 5.COVER 9 2
39 KL3-M1382-00X PLATE 2 KEY BOARD 1
39-1 KL3-M1382-01X PLATE 2 KEY BOARD 1 2001/9/11 M130152 NG
40 KL3-M1381-01X PLATE 1 KEY BOARD 1
40-1 KL3-M1381-02X PLATE 1 KEY BOARD 1 2001/9/11 M130152 NG
