KV6_HSDX_PL - 第6页
1 3 X-Axis Moving-axis KV6-080617 19 33 35 34 15 10 4 14 69 54 11 46 37 45 16 17 25 18 29 22 23 5 5 1 56 56 45 46 13 9 9 6 5 32 36 31 24 24 36 32 39 38 43 41 42 41 12 42 47 29 23 51 49 52 50 51 49 50 52 53 30 8 7 48 40 5…
2
2
Base Cover
Cover
KV6-080424
8
8
8
8
9
8
13
8
8
8
14
16
14
9
14
8
8
15
14
11
14
13
10
11
5
6
6
4
7
3
12
11
9
2
9
11
14
9
18
8
16
10
8
10
11
9
11
1
17
6
6
7
4
1
(
Fig.A
)
OLD
No. Part No. Part Name Q'ty Remarks Date of change Revised No. Compati.
1 KV7-M1310-00X COVER 10 1 Fig.A
1-1 KV7-M1310-01X COVER 10 1 Fig.A (1999/3/18) M930087 OK
1-2 KV7-M1310-02X COVER 10 1 2000/3/20 M9X0107 NG
1-3 KGA-M1310-00X COVER 10 1 (2005/6/2) MB60004 OK
2 KV7-M1311-00X COVER 11 1
3 KV7-M1313-00X COVER 13 1
3-1
KV7-M1313-00X COVER 13 1 S.T.D (2004/4/1) M440001 OK
KV7-M1313-10X COVER 13 1 with Power Indicator (2004/4/1) M440001
4 KV7-M1314-00X COVER,14 2
4-1 KV7-M1314-00X COVER,14 1 (1999/11/30) M9X0107 OK
5 KV7-M1315-00X COVER 15 1
6 KV7-M1317-01X COVER 17 4
7 KV7-M1325-01X BRACKET 5 2
7-1 Delete (2003/11/27) M3X0078
8 KG2-M1370-00X HINGE ASSY 12
9 K44-M1354-00X MG.CATCH 6 TL-152-2
10 KV7-M1326-00X BRACKET 1-1 3
11 KV7-M1370-00X BRACKET MAGNET 6
12 KV7-M1327-00X BRACKET 1-2 1
13 KV7-M1328-00X BRACKET 2 2
14 KV7-M1347-00X PLATE BRACKET 6
15 KJ0-M4187-00X FAN GUARD 2
16 KV7-M1371-00X BRACKET,FIX 2
17 KV7-M1372-00X HANDLE 1
18 KV7-M1312-00X COVER,12 1 (1999/11/30) M9X0107
1
3
X-Axis
Moving-axis
KV6-080617
19
33
35
34
15
10
4
14
69
54
11
46
37
45
16
17
25
18
29
22
23
5
5
1
56
56
45
46
13
9
9
6
5
32
36
31
24
24
36
32
39
38
43
41
42
41
12
42
47
29
23
51
49
52
50
51
49
50
52
53
30
8
7
48
40
55
28
27
55
57
66
68
61
61
67
65
60
64
63
62
67
58
58
59
OLD
28
27
26
2
3
20
21
No. Part No. Part Name Q'ty Remarks Date of change Revised No. Compati.
1 KV7-M2211-02X FRAME X AXIS 1
2 KV7-M2213-02X PLATE A,X AXIS 1
2-1 Delete (2000/2/3) M020009
3 KV7-M2214-02X PLATE B,X AXIS 1
3-1 Delete (2000/2/3) M020009
4 KM0-M2220-00X COUPLING, X-AXIS 1
5 KV7-M2231-00X SPACER R, NUT 3
6 KM0-M2233-00X SPACER R2 NUT 1
6-1 KV7-M2233-00X SPACER R2,NUT 1 (2003/2/11) M320049 OK
7 KV6-M2236-01X PLATE A 1
8 KV7-M2237-00X SUB PLATE 1
9 KV6-M2239-00X BRACKET 1 2
10 KM0-M2241-00X HOLDER,MOTOR X AXIS 1
10-1 KM0-M2241-01X HOLDER,MOTOR X AXIS 1 (2008/4/16) ME30234 OK
11 KV7-M2242-00X HOLDER,BRG X AXIS 1
11-1 KV7-M2242-01X HOLDER,BRG X AXIS 1 (2008/4/16) ME30234 OK
12 KV7-M2645-00X BRG.,ANGULAR 1
12-1 90990-25J005 BEARING 1 (2007/12/4) MDX0031 OK
12-2 90990-26J014 BEARING 1 (2008/4/24) ME40191 OK
13 KV7-M2261-00X HOLDER, HEAD 1
13-1 KV7-M2261-01X HOLDER, HEAD 1 (2002/4/25) M240093 OK
14 KV7-M2271-00X SCREW BALL X AXIS 1
14-1 KV7-M2271-01X SCREW BALL X AXIS 1 (1999/11/3) M9X0010 SET
14-2 KV7-M2271-02X SCREW BALL X AXIS 1 (2002/6/6) M250068 NG
15 90K52-87174X AC SERVO MOTOR 1
15-1 90K56-87174X AC SERVO MOTOR 1 (2000/8/28) M080110 OK
15-2 90K56-8717EX AC SERVO MOTOR 1 (2003/4/18) M340073 OK
16 KV7-M653A-00X SENSOR, 1 ASSY 1 L=600
16-1 KGA-M220A-00X SENSOR , ORG 1 L=600 (2002/11/12) M2X0034 OK
17 KV7-M653E-00X SENSOR, 2 ASSY 2 L=600
17-1 KGA-M220B-00X SENSOR , OT 1 L=600 (2002/11/12) M2X0034 OK
18 K47-M2276-S0X X-AXIS GUIDE SET 1
18-1 KV7-M2276-S0X X-AXIS GUIDE SET 1 (2002/6/6) M250068 OK
18-2 KV7-M2276-A0X X-AXIS GUIDE SET 1 (2007/5/14) MD50039 OK
19 KV6-M2267-00X GUIDE,CABLE X 1
20 K94-M220A-00X TAPE X-AXIS 1
21 K94-M220A-10X TAPE X-AXIS 1
22 KV7-M2282-00X DOG, ORG 1
23 KV7-M2283-00X DOG, 2ND LIMIT 2
24 KV7-M226B-00X PLATE 2
25 KV7-M2291-00X BRACKET, SENSOR 1
26 KV7-M2247-00X BLOCK,STOPPER X 1
26-1 Delete (2002/9/13) M290054
27 KV7-M2248-00X DAMPER 1 1
27-1 KGA-M2651-11X DAMPER 14 ASSY 1 (2002/9/13) M290054 NG
28 KV7-M2249-00X DAMPER 2 1
28-1 KGA-M2651-71X DAMPER 110 ASSY 1 (2002/9/13) M290054 NG
29 KM0-M2251-00X NYLOCK BOLT 16 M8X22L
29-1 90990-01J024 BOLT,HEX.SOCKET HEAD 16 (2007/10/29) MD00030 OK
29-2 90990-01J179 BOLT,HEX.SOCKET HEAD 16 (2020/1/24) MT10096 OK
30 KV6-M2252-00X STOPPER 1
31 KV7-M226A-00X COVER CABLE 1
31-1 KV6-M226A-00X COVER,CABLE 1 (2005/9/2) MB90009 OK
32 KV6-M2268-00X BRACKET 1, TAPE 2
33 KV6-M2269-00X COVER,RUNNER FLEX 1
34 KV6-M220A-00X TAPE1 , X DUCT 1
35 KV6-M220B-00X TAPE 2, X DUCT 1
36 KV6-M2266-00X PLATE, NUT 2
37 KV7-M2240-00X SLEEVE, BRG. 1
38 KV7-M2243-00X HOUSING, BRG. X 1
39 KV7-M2244-00X COVER, BRB. HOUSING 1
40 KV7-M2246-00X COIL SPRING M 6
41 KV7-M2647-00X OIL SEAL 2
42 KV7-M2648-00X SPACER 3
42-1 90990-41J100 COLLAR 3 (2008/4/11) ME30019 OK
43 KG2-M9173-00X LOCK NUT 1
44
45 KV7-M2256-00X GRIP 2
46 KV7-M2257-00X SPACER GRIP 2
47 KV6-M220C-00X TAPE 3, X DUCT 1
48 KV7-M2251-00X NYLOCK BOLT 30 M4X16
48-1 91317-04016 BOLT HEX.SOCKET HEAD 30 (2005/2/7) MB20025 OK
49 KV7-M2295-01X BRACKET, PIN 2
49-1 Delete (2002/7/19) M270057
50 KV7-M2296-00X BRACKET, SCREW 2
50-1 Delete (2002/7/19) M270057
51 KV7-M2297-00X TAPER PIN 4 8X30
51-1 Delete (2002/7/19) M270057
52 KV7-M2298-00X NYLOCK SET, SCREW 6
52-1 Delete (2002/7/19) M270057
53 99480-06014 PIN, PARALLEL 2
54 KV7-M2604-00X SUPPORT UNIT 1 (1999/11/3) M9X0010 SET
55 KGA-M2649-00X NYLOCK BOLT 12 M2.6X10
55-1 90990-01J023 BOLT,HEX.SOCKET HEAD 12 (2007/10/29) MD00030 OK
56-1 KV7-M2213-S1X PLATE X AXIS SET 1 (2008/4/16) ME30234 OK
57 KV7-M2253-00X WASHER,SPRING 16
57-1 90990-38J001 WASHER,SPRING 16 (2008/4/15) ME20075 OK
58 KV7-M2663-00X NYLOCK BOLT 16 M5X16
58-1 90990-01J030 BOLT,HEX.SOCKET HEAD 16 (2007/10/29) MD00030 OK
59 91317-03006 BOLT HEX.SOCKET HEAD 10
60 91317-04008 BOLT HEX.SOCKET HEAD 12
61 91317-04010 BOLT HEX.SOCKET HEAD 26
62 91317-04030 BOLT HEX.SOCKET HEAD 6
63 91317-05014 BOLT HEX.SOCKET HEAD 4
64 91317-05020 BOLT HEX.SOCKET HEAD 4
65 91317-05035 BOLT HEX.SOCKET HEAD 4
66 91317-06012 BOLT HEX.SOCKET HEAD 8
67 91317-06018 BOLT HEX.SOCKET HEAD 4
68 98907-03005 SCREW BINDING HEAD 4
68-1 98902-03006 SCREW BINDING HEAD 4 (2007/7/9) MD60168 OK
69 KV7-M2271-A0X X AXIS B.S.SUB ASSY 1 SI 1001001 (2005/8/2) MB30076
2
3
Y-axis
Moving-axis
KV6-080424
31
37
45
35
60
5
3
15
58
28
21
36
36
23
51
51
38
39
55
20
40
32
2
50
41
42
29
44
30
34
59
10
9
54
11
4
56
56
72
22
18
31
48
33
41
26
27
53
38
39
1
25
57
16
49
17
49
19
11
12
12
7
8
24
50
5
43
43
40
37
47
45
13
35
5
3
15
40
10
72
9
11
14
4
11
12
12
7
8
46
5
40
56
52
60
55
58
60
54
72
56
13
46
46
14
46
76
76
61
62
64
63
72
73
74
59
73
74
59
2
1
OLD
36
36
3
14
13
71
3
14
13
71
62
61
63
64
OLD
OLD
OLD
OLD
No. Part No. Part Name Q'ty Remarks Date of change Revised No. Compati.
1 KV7-M2611-01X FRAME R,Y AXIS 1
1-1 KV7-M2611-02X FRAME R,Y AXIS 1 (2003/2/17) M320070 OK
1-2 Delete (2007/2/8) MD10036
2 KV7-M2612-01X FRAME L,Y AXIS 1
2-1 KV7-M2612-02X FRAME L,Y AXIS 1 (2006/7/25) MC70028 OK
2-2 Delete (2007/2/8) MD10036
3 KV7-M2671-00X SCREW BALL 2
3-1 KV7-M2671-01X SCREW BALL Y AXIS 2 2000/3/15 M9X0010 Set
3-2 KV7-M2671-02X SCREW BALL Y AXIS 2 2001/9/21 M160183 OK
3-3 KV7-M2671-03X SCREW BALL Y AXIS 2 with K1 seal 2002/12/5 M250068 NG
4 KG2-M9173-00X LOCK NUT 2
5 KV7-M264A-01X HOLDER SET, Y AXIS 2
6
7 KV7-M2243-00X HOUSING BRG. X 2
8 KV7-M2244-00X COVER BRB. HOUSING 2
9 KV7-M2645-00X BRG.,ANGULAR 2
9-1 90990-25J005 BEARING 2 (2007/12/4) MDX0031 OK
9-2 90990-26J014 BEARING 2 (2008/4/24) ME40191 OK
10 KV7-M2646-00X COIL SPRING M 12
11 KV7-M2647-00X OIL SEAL 4
12 KV7-M2648-00X SPACER 6
12-1 90990-41J100 COLLAR 6 (2008/4/11) ME30019 OK
13 KV7-M2651-40X DAMPER 43 ASSY 2
13-1 KGA-M2651-41X DAMPER 24 ASSY 2 (2002/7/16) M270039 Set
14 KV7-M2651-30X DAMPER 35 ASSY 2
14-1 KGA-M2651-31X DAMPER 16 ASSY 2 (2002/7/23) M270069 Set
15 KV7-M2666-01X HOLDER NUT Y AXIS 2
16 KV7-M2682-01X DOG ORG 1
17 KV7-M2683-01X DOG 2ND LIMIT 2
18 KV7-M2691-01X BRACKET,SENSOR 1
18-1 KV7-M2691-02X BRACKET,SENSOR 1 (2004/9/1) MA90006 OK
19 KV7-M2694-00X BRACKET A GUIDE 1
20 KV7-M2695-01X BRACKET B GUIDE 1
21 KGA-M26F1-00X FRAME 1 1
22 KGA-M26F2-00X FRAME 2 1
23 KV7-M26F3-00X FRAME 3 1
24 KV7-M26F4-00X DUCT HARNESS 1
25 KV7-M26F5-01X BRACKET HARNESS 1
26 KV7-M653A-20X SENSOR 1 ASSY 1 L=300
26-1 KGA-M260A-00X SENSOR ORG 1 SQ01 (2002/11/12) M2X0034 OK
27 KV7-M653E-10X SENSOR 2 ASSY 1 L=300
27-1 KGA-M260B-00X SENSOR OT 1 SQ05 (2002/11/12) M2X0034 OK
28 KV7-M260A-00X TAPE. Y AXIS 1
29 KV7-M260B-00X TAPE. Y DUCT 1
30 KV7-M260C-00X TAPE 2. Y DUCT 1
31 KV7-M2667-00X PLATE 2
32 KV7-M2668-00X BRACKET 1. TAPE Y 1
33 KV7-M2669-00X BRACKET 2. TAPE Y 1
34 KV7-M2678-00X GUIDE.CABLE Y 1
35 90K52-8A174Y AC SERVO MOTOR 2
35-1 90K56-8A174Y AC SERVO MOTOR 2 M02,M11; Y1,Y2 (2000/8/28) M080110 OK
36 KV7-M2676-S1X Y-AXIS GUIDE SET 1
36-1 KV7-M2676-S2X Y-AXIS GUIDE SET 1 with K1 seal 2002/12/5 M250068 NG
37 KM5-M2611-00X COUPLING,Y-AXIS 1 LCD
37-1 KM5-M2611-00X COUPLING,Y-AXIS 2 LCD (2003/2/11) M320042 OK
38 KV7-M2661-00X NYLOCK BOLT 20 M12X50
38-1 90990-01J028 BOLT,HEX.SOCKET HEAD 20 M12X50 (2007/10/29) MD00030 OK
39 92907-12600 WASHER PLAIN 20
39-1 90201-124G9 WASHER PLAIN 20 (1999/9/28) M990079 OK
40 KV7-M2662-01X NYLOCK BOLT 16 M6X30
40-1 90990-01J029 BOLT,HEX.SOCKET HEAD 16 M6X30 (2007/10/29) MD00030 OK
41 KV7-M2698-00X PLATE 1. CLAMP 2
42 KV7-M2699-00X PLATE 2. CLAMP 1
43 KV7-M2663-00X NYLOCK BOLT 40 M5X16
43-1 90990-01J030 BOLT,HEX.SOCKET HEAD 40 M5X16 (2007/10/29) MD00030 OK
44 KV7-M260D-00X TAPE 3. Y DUCT 1
45 KV7-M2604-00X SUPPORT UNIT 2
46 KGA-M2649-00X NYLOCK BOLT 20 M2.6X10
46-1 KGA-M2649-00X NYLOCK BOLT 24 M2.6X10 (2001/2/27) M120136 OK
46-2 90990-01J023 BOLT,HEX.SOCKET HEAD 24 M2.6X10 (2007/10/29) MD00030 OK
47 KV8-M2611-00X COUPLING. Y-AXIS 1 LCD
47-1 Delete (2003/2/11) M320042
48 98903-03004 SCREW BINDING HEAD 4
49 98903-04006 SCREW BINDING HEAD 6
49-1 98904-04006 SCREW BINDING HEAD 6 (2001/12/6) M1X0135 OK
49-2 98902-04006 SCREW BINDING HEAD 6 (2006/1/9) MBY0166 OK
50 90159-04J01 SCREW, W/WASHER 6
50-1 90990-12J001 SCREW BIN.HEAD W/W 6 (2002/9/11) M290029 OK
51 98903-05010 SCREW BINDING HEAD 4
51-1 98904-05010 SCREW BINDING HEAD 4 (2001/12/6) M1X0135 OK
51-2 98902-05010 SCREW BINDING HEAD 4 (2006/1/9) MBY0166 OK
52 91314-04008 BOLT HEX, SOCKET HEAD 10
52-1 91312-04008 BOLT HEX, SOCKET HEAD 10 (2006/1/16) MBY0158 OK
53 91317-04008 BOLT HEX, SOCKET HEAD 2
54 91314-04010 BOLT HEX, SOCKET HEAD 12
54-1 91312-04010 BOLT HEX, SOCKET HEAD 12 (2006/1/16) MBY0158 OK
55 91317-04014 BOLT HEX, SOCKET HEAD 8
56 91317-04030 BOLT HEX, SOCKET HEAD 12
57 91317-05010 BOLT HEX, SOCKET HEAD 2
58 91317-05018 BOLT HEX, SOCKET HEAD 8
59 91314-06010 BOLT HEX, SOCKET HEAD 28
59-1 91312-06010 BOLT HEX, SOCKET HEAD 28 (2006/1/26) MBY0159 OK
60 91317-06018 BOLT HEX, SOCKET HEAD 16
61 KV7-M2651-10X DAMPER,STOPPER 4
62 KV7-M2652-00X BRACKET,STOPPER Y 4
63 KV7-M2653-00X PIN,PARALLEL 4
64 97704-40012 SRW TRUSS HEAD TAP'G 4
61~64 Delete 2002/9/13 M290054
71 KM8-M2647-00X GREASE NIPPLE 2
71-1 Delete (2001/6/28) M160183
72 92907-04200 WASHER PLAIN 12
73 92903-06200 WASHER PLAIN 20
74 92990-06400 WASHER EXTL.TOOTHED 20
74-1 90172-00J060 WASHER,EXTL.TOOTHED 20 (2008/4/15) ME40115 OK
75 KV7-M2611-S0X FRAME,Y AXIS SET 1 (2007/2/8) MD10036
76 KV7-M2671-C0X Y AXIS B.S.SUB ASSY 2
76-1 KV7-M2671-A0X Y AXIS B.S.SUB ASSY 2 with K1 seal 2002/12/5 M250068 NG
