Main- and sector distributor
Page 16 / 18 24.11.2021
Pos. Item no. Description Part marking
94 00336774-01 GROUND TERMINAL 3-WIRE
281-687
SPARE
95 00823309-01 END CLAMP E/UK UNIVERSAL 9.5MM
96 00337774-02 COPPER RAIL MAIN DISTRIBUTOR
HS50
00343859-01 GROUND STRAND (MAIN
GROUNDING POINT - MAIN
DISTRIBUTOR)
00337851-02 CABLE TREE SECTOR
DISTRIBUTORS HS50
Spare Part
99 00335232-02 CABLE HS50: POWER RING
100 00335235-02 CABLE HS50: POWER TAPE CUTTER
1
101 00335236-02 CABLE HS50: POWER TAPE CUTTER
2
102 00335237-02 CABLE HS50: POWER TAPE CUTTER
3
103 00335238-02 CABLE HS50: POWER TAPE CUTTER
4
104 00335240-02 CABLE HS50: POWER SUPPLY FAN
105 00335244-02 CABLE HS50: POWER PERIPHERY
BUSH 1
106 00335245-02 CABLE HS50: POWER PERIPHERY
BUSH 2
107 00335246-02 CABLE HS50: POWER PERIPHERY
BUSH 3
108 00335247-02 CABLE HS50: POWER PERIPHERY
BUSH 4
109 00335248-02 CABLE HS50: TRACK SIGNALS
SECTOR 4
110 00335258-02 CABLE HS50: LOOP VOLTAGE
111 00335259-02 CABLE HS50: LOOP
112 00335260-02 CABLE HS50: LOOP
113 00335261-02 CABLE HS50: LOOP VOLTAGE
114 00335264-02 CABLE HS50: LOOP
115 00335265-02 CABLE HS50: LOOP VOLTAGE
116 00335268-02 CABLE HS50: LOOP
117 00335269-02 CABLE HS50: LOOP VOLTAGE
118 00335281-02 CABLE S50: KEY-OP.SW./ON-OFF-
BUTT./COMP.
Main- and sector distributor
Page 17 / 18 24.11.2021
Pos. Item no. Description Part marking
119 00335284-02 CABLE S50: CONTROL PANEL AIR
SUPPLY
120 00335286-01 CABLE S50: EXTENSION MAIN
ERROR DISPLAY
Spare Part
121 00335293-02 CABLE HS50: NOZZLE CHANGER 1A
(SEC4)
122 00335294-02 CABLE HS50: NOZZLE CHANGER 2A
(SEC4)
123 00335295-02 CABLE HS50: NOZZLE CHANGER 3A
(SEC4)
124 00335296-02 CABLE HS50: NOZZLE CHANGER 4A
(SEC4)
125 00336807-02 CABLE HS50: NOZZLE CHANGER 1B
(SEC1)
126 00336808-02 CABLE HS50: NOZZLE CHANGER 2B
(SEC1)
127 00336809-02 CABLE HS50: NOZZLE CHANGER 3B
(SEC1)
128 00336810-02 CABLE HS50: NOZZLE CHANGER 4B
(SEC1)
129 00335288-03 CABLE HS50: PNEUMATIC SYSTEM
MAIN AIR VALVE
130 00337809-02 CABLE HS50: EXTENSION
131 00337988-02 CABLE HS50: EXTENSION
132 00337989-02 CABLE HS50: EXTENSION
133 00335262-02 CABLE HS50: SECTOR DISTRIBUTOR
1 - PCB-INPUT RIGHT
134 00335266-02 CABLE HS50: SECTOR DISTRIBUTOR
2 - PCB OUTPUT LEFT
135 00335271-02 CABLE HS50: SECTOR DISTRIBUTOR
3 - PCB OUTPUT RIGHT
136 00335275-02 CABLE HS50: SECTOR DISTRIBUTOR
4 - PCB-INPUT LEFT
137 00335228-02 CABLE HS50: POWER GANTRY
DISTRIBUTOR 1
138 00335229-02 CABLE HS50: POWER GANTRY
DISTRIBUTOR 2
139 00335230-02 CABLE HS50: POWER GANTRY
DISTRIBUTOR 3
140 00335231-02 CABLE HS50: POWER GANTRY
DISTRIBUTOR 4
141 00335241-01 CABLE S50: REGULATED DC-
Main- and sector distributor
Page 18 / 18 24.11.2021
Pos. Item no. Description Part marking
VOLTAGE
142 00335242-01 CABLE S50: POWER DC/DC (48V)
CONVERTER
143 00335219-01 CABLE HS50: UNREGULATED DC-
VOLTAGE
144 00335221-02 CABLE HS50: TRACK SIGNALS
POWER SUPPLY
145 00335223-01 CABLE HS50: SSK PERIPHERY
146 00335263-02 SWITCH FOR COVER SECTOR 1 TO 4 SPARE PART
147 00337052-01 CABLE HS50: COMP.FLAP SECTOR 1
TO 4
