SIPLACE GEM for S25HM, S27HM, HS50, HS60 SW Version GEM 503.02
HOST Interface Manual
©Siemens AG, all rights reserved page 105 of 243
4.6 Stream 4
not used
SIPLACE GEM for S25HM, S27HM, HS50 , HS60 SW Version GEM 503.02
HOST Interface Manual
Page 106 of 243 ©Siemens AG, all rights reserved
4.7 Stream 5
4.7.1 S5F1 - Alarm Report
S5F1 [W] * H<-E
<L [3]
<B [1] ALCD> * ALCD - Alarm On/Off and Severity
<U4 ALID> * ALID - Alarm ID
<A [40] ALTX> * ALTX - Alarm Text
> .
This message is the "normal" message that the Equipment uses to report alarms. In
order for this message to be used, the Equipment Constant "ConfigAlarms" must be set to
"0".
If the Equipment Constant "ConfigAlarms" is set to "0", the Equipment sends S5F1
instead of the normal S5F73 Alarm Notification Send.
The equipment reports that an alarm condition has changed.
ALID identifies the Alarm.
The high-order bit of ALCD will be "1" if this alarm is currently On (Unsafe), or "0" if it is
currently Off (Safe). The low-order seven bits of ALCD contain the severity code for this
alarm.
ALTX contains up to 40 bytes of Alarm Text. See "Appendix C" for a table of possible
Alarms which can occur.
Equipment Constant "WBitS5" controls whether the Equipment sends S5F1 with W-Bit "1"
(Reply Expected) or "0" (No Reply Expected).
4.7.2 S5F2 - Alarm Acknowledge
S5F2 * H->E
<B [1] 00>. * ACK5 - Alarm Acknowledge
The Host acknowledges the Alarm Report. This Equipment ignores the ACKC5.
4.7.3 S5F3 - Enable/Disable Alarm
S5F3 [W] * H->E
<L [2]
<B [1] ALED> * ALED - Alarm Enable/Disable Code
<U4 ALID> * ALID - Alarm ID
> .
The Host commands the Equipment to enable or disable (depending on ALED) reporting
for the specified Alarm ID in S5F1, S5F8, S5F71, and S5F73.
ALED Description
0x80 Enable sending alarm.
0x00 Disable sending alarm.
SIPLACE GEM for S25HM, S27HM, HS50, HS60 SW Version GEM 503.02
HOST Interface Manual
©Siemens AG, all rights reserved page 107 of 243
The following special format can be used to enable or disable all ALIDs.
S5F3 [W] * H->E
<L [2]
<B [1] ALED> * ALED - Alarm Enable/Disable Code
<U4> * ALID - Alarm ID
> .
The Host may optionally set the W-Bit to "1" in S5F3. If so, the SIPLACE replies with
S5F4.
4.7.4 S5F4 - Enable/Disable Alarm
S5F4 * H<-E
<B [1] ACKC5> . * ACKC5 - Acknowledge Code
ACKC5 Description
0x00 Normal. Everything Correct
0x01 Invalid ALID.
4.7.5 S5F5 - List Alarms Request
S5F5 W * H->E
<U4 ALID ...> . * Alarm ID Array
The Host requests the Equipment to send the current status of the specified Alarm IDs.
The Host can use the following special format to request the status of all Alarm IDs:
S5F5 W
<U4>. * ALID
4.7.6 S5F6 - List Alarm Data
S5F6 * H<-E, Multiblock
<L
<L [3]
<B [1] ALCD> * ALCD - Alarm On/Off and Severity
Code
<U4 ALID> * Alarm ID
<A ALTX> * ALTX - Alarm Text
>
...
> .
