SIPLACE GEM for S25HM, S27HM, HS50, HS60 SW Version GEM 503.02
HOST Interface Manual
©Siemens AG, all rights reserved page 135 of 243
5.2 Data Collection
5.2.1 Host Initializes Event
Step SECS Message Description
1. H -> E S2F37 W Disable Event Reports. The Host disables
reporting for all Collection Events.
S2F37 W
<L [2]
<BOOLEAN F>
<L>
> .
2. H <- E S2F38 The Equipment acknowledges. Temporarily,
the Equipment will make no event reports.
3. H ->E S2F33 W Define Report. The Host erases all previous
Report definitions and Links:
S2F33 W
<L [2]
<U4 DATAID>
<L>
> .
4. H <- E S2F34 The Equipment acknowledges.
5. H -> E S2F33 W Define Report. The Host sends Report
Definitions.
6. H <-E S2F34 The Equipment Acknowledges.
7. H -> E S2F35 W Link Events/Reports. The Host links reports to
the desired Collection Events. Linked Reports
are initially „disabled“.
8. H <- E S2F36 The Equipment acknowledges
9. H -> E S2F15 W Equipment Constant Send. The Host sets
Equipment constant RpType to indicate
whether Event Reports should be in Normal or
Annotated format.
10. H <- E S2F16 The Equipment acknowledges
11. H -> E S2F37 W Enable Event Reports. The Host enables
reporting for desired Collection Events.
12. H <- E S2F38 The Equipment acknowledges. From this point
on, the Equipment will report events as they
occur.
SIPLACE GEM for S25HM, S27HM, HS50 , HS60 SW Version GEM 503.02
HOST Interface Manual
Page 136 of 243 ©Siemens AG, all rights reserved
5.2.2 Equipment Reports Event
Step SECS Message Description
1. The Equipment recognizes that an event has
occurred. The Host has enabled reporting for
the CEID, and possibly has defined one or more
Reports and linked them to the CEID. The
Equipment Constant RpType is set to „False“,
requesting normal reports.
2. H <- E S6F5 W Inquire. If S6F13 will be multi-block, the
Equipment first sends this Inquire to request
permission. If S6F11 is single-block, skip this
and the next step.
3. H -> E S6F6 Grant. The Host grants permission to send
multi-block event report. If GRANT6 is non-zero,
this scenario fails here, and the event data is
discarded.
4. H <- E S6F11 W The Equipment sends Event reports for the
CEID that occurred
5. H -> E S6F12 The Host acknowledges the report.
SIPLACE GEM for S25HM, S27HM, HS50, HS60 SW Version GEM 503.02
HOST Interface Manual
©Siemens AG, all rights reserved page 137 of 243
5.2.3 Equipment Reports Annotated
Step SECS Message Description
1. The Equipment recognizes that an event has
occurred. The Host has enabled reporting for
the CEID, and possibly has defined one or more
Reports and linked them to the CEID. The
Equipment Constant RpType is set to „True“,
requesting Annotated reports.
2. H <- E S6F5 W Inquire. If S6F13 will be multi-block, the
Equipment first sends this Inquire to request
permission. If S6F13 is single-block, skip this
and the next step.
3. H -> E S6F6 Grant. The Host grants permission to send
multi-block event report. If GRANT6 is non-zero,
this scenario fails here, and the event data is
discarded.
4. H <- E S6F13 W The Equipment sends annotated event reports
for the CEID that occurred.
5. H -> E S6F14 The Host acknowledges the report.
Note: In all other scenarios in which event reports occur, the Events or Annotated Events
are shown in abbreviated form (S6F11/S6F12 only). The complete Event Report
Scenarios are shown here.
