SIPLACE GEM for S25HM, S27HM, HS50 , HS60 SW Version GEM 503.02
HOST Interface Manual
Page 156 of 243 ©Siemens AG, all rights reserved
VID Class Format Name and Description
612003 SV U1 OUTPUTCONVEYORSTATE.
The state of output conveyor.
0 = Empty
1 = Full
2 = Error
612004 SV U1 TWININPUTCONVEYORSTATE.
The state of the input conveyor on twin side
0 = Empty
1 = Full
2 = Error
612022 SV U1 TWINFIRSTPROCESSINGCONVEYORSTATE
The state of the first processing conveyor on twin side
0 = Empty
1 = Full
2 = Error
612023 SV U1 TWININTERMEDIATECONVEYORSTATE
The state of the intermediate conveyor on twin side
0 = Empty
1 = Full
2 = Error
612024 SV U1 SECONDPROCESSINGCONVEYORSTATE
The state of the second processing conveyor on twin
side
0 = Empty
1 = Full
2 = Error
612006 SV U1 TWINOUTPUTCONVEYORSTATE.
The state of output conveyor on twin side.
0 = Empty
1 = Full
2 = Error
612007 SV I4 TRANSPORTWIDTH
transport width [1/1000 mm]
A value of -1 indicates an error
Only valid after width has been measured or adjusted
by line computer
612008 SV I4 TWINTRANSPORTWIDTH
transport width [1/1000 mm] on twin side
A value of -1 indicates an error
SIPLACE GEM for S25HM, S27HM, HS50, HS60 SW Version GEM 503.02
HOST Interface Manual
©Siemens AG, all rights reserved page 157 of 243
VID Class Format Name and Description
Only valid after width has been measured or adjusted
by line computer
Matrix Tray Changer (MTC)
812002 SV L MTCINFO
<L
<U1 MTC_number>
valid for all MTC Events
<I2 tower>
<I2 carrier_modul>
<I2 level>
<I2 division>
<I4 Filling_level>
>
If you have several MTCs you can identify a MTC by
MTC_number. A MTC has 2 towers (1,2) and on every
tower there are several carrier modules. A carrier
module contains several tray carriers. Each tray carrier
can be identified by a level number. A tray carrier
consists of many divisions, wich can be identified by
the division number.
Filling_level is only valid with the Event
MTCfillLevelChanged.
In case of the Event MTCfillLevelChanged
carrier_modul will be -1.
Barcode
912002 SV A BCININPUTCONVEYOR
Barcode read from PCB in input conveyor. If no
barcode reader is installed in SIPLACE this variable
will contain an empty text
An empty text indicates an error.
912003 DV A COMPONENTBARCODE
Component barcode is read by the GUI.
An empty text indicates an error or barcode is read by
Mobile Verifier
912004 DV U2 WAYOFINPUTCOMPONENTBARCODE
Way of reading the component barcode:
1: with keyboard
2: with barcode reader
3: no barcode read
Is not valid for Mobile Verifier
912005 SV U2 PCBSIDEININPUTCONVEYOR
Side of the PCB showing the barcode (only valid in
case of two barcode reader per conveyor)
SIPLACE GEM for S25HM, S27HM, HS50 , HS60 SW Version GEM 503.02
HOST Interface Manual
Page 158 of 243 ©Siemens AG, all rights reserved
VID Class Format Name and Description
1: above
2: down
3: barcode reader manufctured by LEUTZE in use
or
the barcode could not be read
912012 SV A BCINTWININPUTCONVEYOR
Barcode read from PCB in twin input conveyor. If no
barcode reader is installed in SIPLACE this variable
will contain an empty text.
An empty text indicates an error.
912015 SV U2 PCBSIDEINTWININPUTCONVEYOR
Side of the PCB showing the barcode (only valid in
case of two barcode reader per conveyor)
1: above
2: down
3: barcode reader manufctured by LEUTZE in use
or
the barcode could not be read
912017 EC U1 BCREADEREXIST
Unables/Enables the event messages of the BCread
and BCTwinRead events.
0: No BCread and BCTwinRead events send
1: BCread and BCTwinRead events send (default)
GEM-Kernel
1002001 DV A GEMEVENTTEXT.
The equipment will set this string to contain a
description of the most recent event. The Host can
include this variable in any event report it defines.
Communication Model
1002002 EC U1 INITCOMMSTATE.
Initial (power-up) Communications State.
0 = Disabled
1 = Enabled
1002003 EC U2 ESTABLISHCOMMUNICATIONSTIMER.
Time in seconds of how long the equipment will pause
after an unsuccessful Connect Request before
sending another. Valid values are 0-32000.s
1002004 EC U1 CONFIGCONNECT.
An EC which controls which SECS message this
Equipment will use for Connect Request.
0 = S1F1
1 = S1F65
2 = S1F13
