SIPLACE GEM for S25HM, S27HM, HS50, HS60 SW Version GEM 503.02
HOST Interface Manual
©Siemens AG, all rights reserved page 163 of 243
VID Class Format Name and Description
changed by the Operator.
Spooling
1002037 EC U4 MAXSPOOLTRANSMIT.
The maximum number of spooled messages the
equipment will send each time the Host reads the
spool. A setting of zero indicates that all spooled
messages should be sent. Refer to the description of
S6F23 in the "SECS Message Detail" section for
further information.
1002038 SV U4 SPOOLCOUNTACTUAL.
A count of the number of messages actually present
on the spool disk, adjusted for any messages which
have been overwritten or otherwise discarded.
1002039 SV U4 SPOOLCOUNTTOTAL.
A count of the number of messages the equipment
attempted to write to the spool disk. This number
includes messages actually present on the spool disk,
and also any messages which may have been
overwritten or otherwise discarded.
1002040 SV A[16] SPOOLFULLTIME.
The date and time at which the spool file became full.
Format is: YYYYMMDDhhmmsscc. See description
of CLOCK variable above for format details.
1002041 SV U1 SPOOLLOADSUBSTATE.
The current state within the SPOOL LOAD super-
state.
6 = Spool Not Full
7 = Spool Full
1002042 SV A[16] SPOOLSTARTTIME.
The date and time at which the first message was
written to the current spool file. Format is:
YYYYMMDDhhmmsscc.
See description of CLOCK variable above for format
details.
1002043 SV U1 SPOOLSTATE.
The current spool state within the POWER ON super-
state.
1 = Spool Inactive
2 = Spool Active
1002044 SV U1 SPOOLUNLOADSUBSTATE.
The current spool state within the SPOOL UNLOAD
super-state.
3 = Purge Spool
4 = Transmit Spool
5 = No Spool
SIPLACE GEM for S25HM, S27HM, HS50 , HS60 SW Version GEM 503.02
HOST Interface Manual
Page 164 of 243 ©Siemens AG, all rights reserved
VID Class Format Name and Description
1002045 EC U1 CONFIGSPOOL.
This EC determines whether spooling is enabled or
disabled for this Equipment.
0 = Disabled
1 = Enabled
1002046 EC BOOL OVERWRITESPOOL.
This EC determines the action to be taken by the
Equipment when the Spool file reaches its capacity.
TRUE = Overwrite Spool
FALSE = Do Not Overwrite Spool
Limit Monitoring
1002047 DV U4 GEMLIMITSVID.
The VID relating to the most recent Limits Monitoring
transition event which occurred.
1002048 DV B[1] GEMEVENTLIMIT.
The LIMITID relating to the most recent Limits
Monitoring transition event which occurred.
1002049 DV B[1] GEMTRANSTYPE.
Transition type relating to the most recent Limits
Monitoring transition which occurred.
0x00 = Lower -> Upper
0x01 = Upper -> Lower
1002050 EC U2 GEMLIMITSTIMER.
The time in seconds this equipment will pauses
between checking for Limits Monitoring transitions
On-Line Identification
1002051 SV A[6] MDLN.
Model number.
„HS50„ , „HS5r„ or „S25„ , „S25HM„
“S27HM”, “HS60”
1002052 SV A[6] SOFTREV.
Software revision number.
"503.xx"
Miscellaneous
1002054 SV A SOFTWAREREVTABLE
Revision of feeder table software - After startup this is
the revision number of the first table. Will be updated
with every event TableDownload (2010008).
1002055 EC U2 HEARTBEAT.
The time in seconds that the Equipment will pause
before sending S1F1 to test the link. Units are
seconds. Valid values are 0-3200 (a setting of zero
will disable the heartbeat).
1002065 EC U1 GEMTIMEFORMAT
SIPLACE GEM for S25HM, S27HM, HS50, HS60 SW Version GEM 503.02
HOST Interface Manual
©Siemens AG, all rights reserved page 165 of 243
VID Class Format Name and Description
Format of TIME (VID 1002023)
0: 12 digits
1: 16 digits (Year 2000 compliant)
1002067 SV A[30] SOFTWAREREVGEM
GEM Software revision number.
"503.xx"
1002068 EC A[10] NICKNAME
Default value is "SIPLACE"
Can be overwritten with an individual name for each
machine.
1002069 SV I8 LASTERRORCODE
If the General Error Event FM_GENERAL is used, this
Variable contains the Error Code. The Error Code is
identical to the CEID of the specific Error Event.
Example:
A barcode reading error can be reported with the
Event
CEID 920001 FM_LP_BC_NOK
or with the General Error Event
CEID 1001024 FM_GENERAL and the Variables
VID 1002069 LASTERRORCODE = 920001 and
VID 1002070 LASTFMTEXT = "FM_LP_BC_NOK"
1002070 SV A LASTFMTEXT
Error Text of the last specific Error Event. For a
detailed description see LASTERRORCODE
1002071 SV A SOFTWAREREVMTC
Software revision of the Matrix Tray Changer
Only valid after a download of the MTC firmware.
Process Program Management
1002080 SV A CURRENTSETUP
Name of current setup loaded in machine
An empty text indicates an error.
1002081 SV A FIRSTCURRENTPLACEPROGRAM
Name of current placement program loaded in
machine for Processing 1 Area.
This data item will be set when a new Process
Program is downloaded to a SIPLACE machine for the
corresponding processing area and a PCB reaches
the corresponding processing conveyor:
An empty text indicates an error.
