SIPLACE GEM for S25HM, S27HM, HS50 , HS60 SW Version GEM 503.02
HOST Interface Manual
Page 166 of 243 ©Siemens AG, all rights reserved
VID Class Format Name and Description
1002082 SV A SECONDCURRENTPLACEPROGRAM
Name of current placement program loaded in
machine for Processing 2 Area.
An empty text indicates an error.
1002942 EC U4 MAX_TIME_TO_STOP
max. spoolingtime in minutes, if safespoolmode ist
activ
1002943 EC U1 SAFE_SPOOL_MODE
0 = inactiv
1 = aktiv
GUI
1122001 SV A GUIACTIONTEXT
Last „Action text“ sent to GUI
An empty text indicates an error
1122002 SV A GUISTATETEXT
Last „State text“ sent to GUI
An empty text indicates an error
1122007 SV U4 GUIMESSAGENUMBER
Used for General GUI Events CEID 1120300 and
1120301
Contains the CEID of the special GUI Event.
E.g. in case of GUIStart you may use either Event
1120007 GUIStart or Event MessageFromGuiGeneral
with VID 1122007 (GUIMESSAGENUMBER) which
will contain the value 1120007.
SIPLACE Revolver Head 1
1312001 SV I4 HEIGHTREV1
Height of revolver head 1. Only valid after reference
run. Units are 1/1000 mm
During the reference run the SIPLACE measures the
distance between the upper edge of the conveyor belt
and the nozzle on segment 1. The
HEIGHTREVOLVER1 is then calculated by subtracting
the length of the nozzle on segment 1 from the
measured value. The nozzle length is defined in the
machine data. So HEIGHTREVOLOR1 is a relative
not an absolute value.
A value of 0 indicates an error
1312002 SV L GANTRYINFOREV1
Gantry information for revolver head 1. The data is
automatically reseted when a PCB reaches the center
conveyor.
SIPLACE GEM for S25HM, S27HM, HS50, HS60 SW Version GEM 503.02
HOST Interface Manual
©Siemens AG, all rights reserved page 167 of 243
VID Class Format Name and Description
<L
<I2 CompPickedUp>
<I2 CompPlaced>
<I2 CompLeft2Place>
>
CompPickedUp Number of components which
were picked up successfully since
the last PCB reached the center
conveyor
CompPlaced Number of components which
were placed since the last PCB
reached the center conveyor
CompLeft2Place Number of components which
were not placed on the actual
PCB
An empty list indicates an error.
For a detailed description of the data item see „4.2
Data Item Dictionary“.
1312003 SV L PLACEINFOREV1
Placement information for revolver head 1.
<L
L <
<U4 X-position> [1/1000 mm]
<U4 Y-position> [1/1000 mm]
<F8 Angle> [1/100 degrees]
<U1 ForceIndex>
<A ReferenceDesignator>
<A ComponentName>
<U2 PackageFormNumber>
<U1 PlacementResult>
<I4 PlacementVacuum> [mbar]
<I4 Vacuum> [mbar]
<U2 DataValid>
<I4 X-deviation> [1/1000 mm]
<I4 Y-deviation> [1/1000 mm]
<F8 Angle> [1/100 degrees]
<U1 Quality> [0 - 100]
SIPLACE GEM for S25HM, S27HM, HS50 , HS60 SW Version GEM 503.02
HOST Interface Manual
Page 168 of 243 ©Siemens AG, all rights reserved
VID Class Format Name and Description
<U4 Length> [1/1000 mm]
<U4 Width> [1/1000 mm]
<L
<I4 Pitch_per_lead_group>
....
<I4 Pitch_per_lead_group>
>
<F8 MaxLeadDev>
<F8 MaxBallDev>
<F8 OrthoDev> [degrees]
<U2 LeadCount>
>
.....
>
The first element in this list refers to segment 1, the
second to segment 2 and so on. If a segment was not
in use in the last placement cycle the list for that
segment is left empty
For a detailed description of the data item see „4.2
Data Item Dictionary“.
An empty list indicates an error.
1312004 SV L PICKUPINFOREV1
Pick-up information for revolver head 1
<L
<L
<A ComponentName>
<I2 TrackNumber>
<U2 FeederType>
<I2 Level>
<I2 Division>
<U1 Location>
<U1 PickUpResult>
<I4 PickUpVacuum> [mbar]
<i4 Vacuum>
>
....
>
The first element in this list refers to segment 1, the
second to segment 2 and so on. If a segment was not
