SIPLACE GEM for S25HM, S27HM, HS50 , HS60 SW Version GEM 503.02
HOST Interface Manual
Page 170 of 243 ©Siemens AG, all rights reserved
VID Class Format Name and Description
<I4 closed_nozzle> [mbar]
<I4 cubic_nozzle> [mbar]
<I4 not_cubic_nozzle> [mbar]
<I4 tol_dirty_nozzle> [mbar]
<I4 tol_leaky_nozzle> [mbar]
>
.....
>
The first element in this list refers to segment 1, the
second to segment 2, and so on.
tol_dirty_nozzle and tol_leaky_nozzle are currently not
used.
An empty list indicates an error.
For a detailed description of the data item see „4.2
Data Item Dictionary“.
1312007 SV L SEGMENTINFOREV1
Summation of information per segment.
<L
<L
<I2 CompPickedUp>
<I2 PickUpErrors>
<I2 CompPlaced>
<I2 PlaceErrors>
>
.....
>
The first element in this list refers to segment 1, the
second to segment 2, and so on.
The variable can be linked e.g. to event PCBReady. It
is reseted when a PCB reaches the center conveyor.
For a detailed description of the data item see „4.2
Data Item Dictionary“.
1312008 SV L PLACEINFOREV1SUB1
Subset of PLACEINFOREVx variable. Detailed
description see there.
<L
L <
<U4 X-position> [1/1000 mm]
SIPLACE GEM for S25HM, S27HM, HS50, HS60 SW Version GEM 503.02
HOST Interface Manual
©Siemens AG, all rights reserved page 171 of 243
VID Class Format Name and Description
<U4 Y-position> [1/1000 mm]
<F8 Angle> [1/100 degrees]
<U1 ForceIndex>
<A ReferenceDesignator>
<A ComponentName>
<U2 PackageFormNumber>
<U1 PlacementResult>
<I4 PlacementVacuum> [mbar]
<U2 DataValid>
<I4 X-deviation> [1/1000 mm]
<I4 Y-deviation> [1/1000 mm]
<F8 Angle> [1/100 degrees]
<F8 MaxLeadDev>
<F8 MaxBallDev>
>
....
(for each segment)
... .
>
The first element in this list refers to segment 1, the
second to segment 2 and so on. If a segment was not
in use in the last placement cycle the list for that
segment is left empty.
Revolver Head 2 (SIPLACE 80 S 20 only)
1412001 SV I4 HEIGHTREV2
Height of revolver head 2. Only valid after reference
run. Units are 1/1000 mm. Only valid for SIPLACE
80S. On a SIPLACE 80F this variable will contain 0
During the reference run the SIPLACE measures the
distance between the upper edge of the conveyor belt
and the nozzle on segment 1. The
HEIGHTREVOLVER2 is then calculated by subtracting
the length of the nozzle on segment 1 form the
measured value. The nozzle length is defined in the
machine data. So HEIGHTREVOLOR2 is a relative
not an absolute value.
For a detailed description of the data item see „4.2
Data Item Dictionary“.
A value of 0 indicates an error.
1412002 SV L GANTRYINFOREV2
Gantry information for revolver head 2. The data is
automatically reseted when a PCB reaches the center
SIPLACE GEM for S25HM, S27HM, HS50 , HS60 SW Version GEM 503.02
HOST Interface Manual
Page 172 of 243 ©Siemens AG, all rights reserved
VID Class Format Name and Description
conveyor.
<L
<I2 CompPickedUp>
<I2 CompPlaced>
<I2 CompLeft2Place>
>
CompPickedUp Number of components which
were picked up successfully since
the last PCB reached the center
conveyor
CompPlaced Number of components which
were placed since the last PCB
reached the center conveyor
CompLeft2Place Number of components which
were not placed on the actual
PCB
For a detailed description of the data item see „4.2
Data Item Dictionary“.
An empty list indicates an error.
1412003 SV L PLACEINFOREV2
Placement information for revolver head 2. Only valid
for SIPLACE 80S. On a SIPLACE 80F this variable will
contain an empty list.
<L
L <
<U4 X-position> [1/1000 mm]
<U4 Y-position> [1/1000 mm]
<F8 Angle> [1/100 degrees]
<U1 ForceIndex>
<A ReferenceDesignator>
<A ComponentName>
<U2 PackageFormNumber>
<U1 PlacementResult>
<I4 PlacementVacuum>
<I4 Vacuum>
<U2 DataValid>
<I4 X-deviation> [1/1000 mm]
