SIPLACE GEM for S25HM, S27HM, HS50 , HS60 SW Version GEM 503.02
HOST Interface Manual
Page 174 of 243 ©Siemens AG, all rights reserved
VID Class Format Name and Description
>
....
>
The first element in this list refers to segment 1, the
second to segment 2 and so on. If a segment was not
in use in the last pick up cycle the list for that segment
is left empty.
If the component was picked up from a feeder
Level
will contain -1.
In the case that the component was picked up from a
tray in the matrix tray changer
TrackNumber will
contain the
tower of the MTC(1,2). In this way
PICKINFOREVx has the same format as in previous
versions.
For a detailed description of the data item see „4.2
Data Item Dictionary“.
An empty list indicates an error.
1412005 SV L NOZZLECONF2
Nozzle configuration on revolver head 2. Only valid for
SIPLACE 80S. On a SIPLACE 80F this variable will
contain an empty list.
<L
<L [12]
<U4 NOZZLE_TYPE>
<I4 REAL_NOZZLE_LENGTH> [1/1000 mm]
>
>
The nozzle length is measured during the reference
run. It depends on the HEIGHTREVOLVER2 value. So
REAL_NOZZLE_LENGTH is not a absolute but a
relative value.
It is calculated by subtracting the measured distance
between the nozzle and the upper edge of the
transport belt from the HEIGHTREVOLVER2 value.
For a detailed description of the data item see „4.2
Data Item Dictionary“.
An empty list indicates an error.
1412006 SV L VACUUMDATAREV2
Vacuum measurements from the last reference run on
revolver head 2. Only valid for SIPLACE 80S. On a
SIPLACE 80F this variable will contain an empty list.
<L
<L
SIPLACE GEM for S25HM, S27HM, HS50, HS60 SW Version GEM 503.02
HOST Interface Manual
©Siemens AG, all rights reserved page 175 of 243
VID Class Format Name and Description
<I4 open_nozzle>
<I4 closed_nozzle>
<I4 cubic_nozzle>
<I4 not_cubic_nozzle>
<I4 tol_dirty_nozzle>
<I4 tol_leaky_nozzle>
>
.....
>
The first element in this list refers to segment 1, the
second to segment 2 and so on.
tol_dirty_nozzle and tol_leaky_nozzle are currently not
used.
For a detailed description of the data item see „4.2
Data Item Dictionary“.
An empty list indicates an error.
1412007 SV L SEGMENTINFOREV2
Summation of information per segment.
<L
<L
<I2 CompPickedUp>
<I2 PickUpErrors>
<I2 CompPlaced>
<I2 PlaceErrors>
>
.....
>
The first element in this list refers to segment 1, the
second to segment 2, and so on.
The variable can be linked e.g. to event PCBReady. It
is reseted when a PCB reaches the center conveyor.
For a detailed description of the data item see „4.2
Data Item Dictionary“.
1412008 SV L PLACEINFOREV2SUB1
Subset of PLACEINFOREVx variable. Detailed
description see there.
<L
L <
SIPLACE GEM for S25HM, S27HM, HS50 , HS60 SW Version GEM 503.02
HOST Interface Manual
Page 176 of 243 ©Siemens AG, all rights reserved
VID Class Format Name and Description
<U4 X-position> [1/1000 mm]
<U4 Y-position> [1/1000 mm]
<F8 Angle> [1/100 degrees]
<U1 ForceIndex>
<A ReferenceDesignator>
<A ComponentName>
<U2 PackageFormNumber>
<U1 PlacementResult>
<I4 PlacementVacuum> [mbar]
<U2 DataValid>
<I4 X-deviation> [1/1000 mm]
<I4 Y-deviation> [1/1000 mm]
<F8 Angle> [1/100 degrees]
<F8 MaxLeadDev>
<F8 MaxBallDev>
>
....
(for each segment)
... .
>
The first element in this list refers to segment 1, the
second to segment 2 and so on. If a segment was not
in use in the last placement cycle the list for that
segment is left empty.
Miscellaneous
2012013 SV U2 ERRORTYPE
Type of the most recent error
2 Transport
3 Track error
4 Machine error
5 Miscellaneous
A value of 0 indicates an error.
2012014 SV U2 GANTRYONERROR
Gantry associated with the most recent error (1...4)
A value of 0 indicates an error.
2012015 SV U2 SEGMENTONERROR
Segment number associated with the most recent
