SIPLACE GEM for S25HM, S27HM, HS50, HS60 SW Version GEM 503.02
HOST Interface Manual
©Siemens AG, all rights reserved page 187 of 243
VID Class Format Name and Description
<L
<I2 CompPickedUp>
<I2 PickUpErrors>
<I2 CompPlaced>
<I2 PlaceErrors>
>
.....
>
The first element in this list refers to segment 1, the
second to segment 2, and so on.
The variable can be linked e.g. to event PCBReady. It
is reseted when a PCB reaches the center conveyor.
For a detailed description of the data item see „4.2
Data Item Dictionary“.
2312008 SV L PLACEINFOREV3SUB1
Subset of PLACEINFOREVx variable. Detailed
description see there.
<L
L <
<U4 X-position> [1/1000 mm]
<U4 Y-position> [1/1000 mm]
<F8 Angle> [1/100 degrees]
<U1 ForceIndex>
<A ReferenceDesignator>
<A ComponentName>
<U2 PackageFormNumber>
<U1 PlacementResult>
<I4 PlacementVacuum> [mbar]
<U2 DataValid>
<I4 X-deviation> [1/1000 mm]
<I4 Y-deviation> [1/1000 mm]
<F8 Angle> [1/100 degrees]
<F8 MaxLeadDev>
<F8 MaxBallDev>
>
....
(for each segment)
... .
SIPLACE GEM for S25HM, S27HM, HS50 , HS60 SW Version GEM 503.02
HOST Interface Manual
Page 188 of 243 ©Siemens AG, all rights reserved
VID Class Format Name and Description
>
The first element in this list refers to segment 1, the
second to segment 2 and so on. If a segment was not
in use in the last placement cycle the list for that
segment is left empty.
SIPLACE Revolver Head 4
2412001 SV I4 HEIGHTREV4
Height of revolver head 4. Only valid after reference
run. Units are 1/1000 mm
During the reference run the SIPLACE measures the
distance between the upper edge of the conveyor belt
and the nozzle on segment 1. The
HEIGHTREVOLVER4 is then calculated by subtracting
the length of the nozzle on segment 1 from the
measured value. The nozzle length is defined in the
machine data. So HEIGHTREVOLOR4 is a relative
not an absolute value.
A value of 0 indicates an error
2412002 SV L GANTRYINFOREV4
Gantry information for revolver head 4. The data is
automatically reseted when a PCB reaches the center
conveyor.
<L
<I2 CompPickedUp>
<I2 CompPlaced>
<I2 CompLeft2Place>
>
CompPickedUp Number of components which
were picked up successfully since
the last PCB reached the center
conveyor
CompPlaced Number of components which
were placed since the last PCB
reached the center conveyor
CompLeft2Place Number of components which
were not placed on the actual
PCB
An empty list indicates an error.
For a detailed description of the data item see „4.2
Data Item Dictionary“.
2412003 SV L PLACEINFOREV4
Placement information for revolver head 4.
<L
SIPLACE GEM for S25HM, S27HM, HS50, HS60 SW Version GEM 503.02
HOST Interface Manual
©Siemens AG, all rights reserved page 189 of 243
VID Class Format Name and Description
L <
<U4 X-position> [1/1000 mm]
<U4 Y-position> [1/1000 mm]
<F8 Angle> [1/100 degrees]
<U1 ForceIndex>
<A ReferenceDesignator>
<A ComponentName>
<U2 PackageFormNumber>
<U1 PlacementResult>
<I4 PlacementVacuum> [mbar]
<I4 Vacuum> [mbar]
<U2 DataValid>
<I4 X-deviation> [1/1000 mm]
<I4 Y-deviation> [1/1000 mm]
<F8 Angle> [1/100 degrees]
<U1 Quality> [0 - 100]
<U4 Length> [1/1000 mm]
<U4 Width> [1/1000 mm]
<L
<I4 Pitch_per_lead_group>
....
<I4 Pitch_per_lead_group>
>
<F8 MaxLeadDev>
<F8 MaxBallDev>
<F8 OrthoDev> [degrees]
<U2 LeadCount>
>
.....
>
The first element in this list refers to segment 1, the
second to segment 2 and so on. If a segment was not
in use in the last placement cycle the list for that
segment is left empty
For a detailed description of the data item see „4.2
Data Item Dictionary“.
An empty list indicates an error.
2412004 SV L PICKUPINFOREV4
Pick-up information for revolver head 4
