SIPLACE GEM for S25HM, S27HM, HS50 , HS60 SW Version GEM 503.02

HOST Interface Manual

VID Class Format Name and Description

.....

The first element in this list refers to segment 1, the

second to segment 2, and so on.

The variable can be linked e.g. to event PCBReady. It

is reseted when a PCB reaches the center conveyor.

For a detailed description of the data item see „4.2

Data Item Dictionary“.

2412008 SV L PLACEINFOREV4SUB1

Subset of PLACEINFOREVx variable. Detailed

description see there.

L <

<U4 X-position> [1/1000 mm]

<U4 Y-position> [1/1000 mm]

<F8 Angle> [1/100 degrees]

<I4 PlacementVacuum> [mbar]

<I4 X-deviation> [1/1000 mm]

<I4 Y-deviation> [1/1000 mm]

<F8 Angle> [1/100 degrees]

....

(for each segment)

... .

The first element in this list refers to segment 1, the

second to segment 2 and so on. If a segment was not

in use in the last placement cycle the list for that

segment is left empty.

2512001 DV L TRACE_PCB_DATA

SIPLACE GEM for S25HM, S27HM, HS50, HS60 SW Version GEM 503.02

HOST Interface Manual

VID Class Format Name and Description

Traceability data for the actual PCB

2512002 DV L TRACE_ALL_COMPONENTS

....

Each reference represents one component batch used

for the actual pcb.
