SIPLACE GEM for S25HM, S27HM, HS50, HS60 SW Version GEM 503.02
HOST Interface Manual
©Siemens AG, all rights reserved page 209 of 243
CEID Name Description
interrogation*
311222 FM_AX_ANFRAGE_FUNC Axis error: Communication during
function address interrogation*
311227 FM_X_INIT_SCHRITTM X axis: Step motor initialisation
incorrect*
311228 FM_Y_INIT_SCHRITTM Y axis: Step motor initialisation
incorrect*
311229 FM_S_INIT_SCHRITTM S axis: Step motor initialisation
incorrect*
311230 FM_Z_SP_INIT_SCHRITTM RV/Z axis: Step motor initialisation
incorrect*
311231 FM_D_INIT_SCHRITTM RV/D axis: Step motor initialisation
incorrect*
311234 FM_X_TACHOBRUCH X axis: Tachometer defective*
311235 FM_Y_TACHOBRUCH Y axis: Tachometer defective*
311236 FM_S_TACHOBRUCH S axis: Tachometer defective*
311237 FM_Z_SP_TACHOBRUCH RV/Z axis: Tachometer defective*
311238 FM_D_TACHOBRUCH RV/D axis: Tachometer defective*
311241 FM_X_SERVO_FREI_VC X axis: Faulty servo activation
(counting track error) *
311242 FM_Y_SERVO_FREI_VC Y axis: Faulty servo activation
(counting track error) *
311243 FM_S_SERVO_FREI_VC S axis: Faulty servo activation
(counting track error) *
311244 FM_Z_SP_SERVO_FREI_VC RV/Z axis: Faulty servo activation
(counting track error) *
311245 FM_D_SERVO_FREI_VC RV/D axis: Faulty servo activation
(counting track error) *
311248 FM_X_NOREF_I_EFF X-axis: Not referenced *
311249 FM_Y_NOREF_I_EFF Y-axis: Not referenced *
311250 FM_S_NOREF_I_EFF S--axis: Not referenced *
311251 FM_Z_SP_NOREF_I_EFF RV/Z--axis: Not referenced *
311252 FM_D_NOREF_I_EFF RV/D-axis: Not referenced *
311255 FM_X_ZAEHLF_KOMMUTF X-axis: counting error (machine stop
or commutation)*
311256 FM_Y_ZAEHLF_KOMMUTF Y-axis: counting error (machine stop)*
311257 FM_S_ZAEHLF_KOMMUTF S-axis: counting error (machine stop
or commutation)*
311258 FM_Z_SP_ZAEHLF_KOMMUTF RV/Z-axis: counting error (machine
stop or commutation) *
311259 FM_D_ZAEHLF_KOMMUTF RV/D-axis: counting error (machine
stop or commutation) *
SIPLACE GEM for S25HM, S27HM, HS50 , HS60 SW Version GEM 503.02
HOST Interface Manual
Page 210 of 243 ©Siemens AG, all rights reserved
CEID Name Description
311262 FM_ABH_BO_AUS Bero for Z-axis top position not
released
311263 FM_CAN_MSG_Z_ACHSE_OB_
SP
RV/Z axis: light barrier z-top not
covered
311264 FM_CAN_MSG_START_STERN S axis: must not be rotated
311265 FM_CAN_MSG_START_XY Due to Z axis, portal must not be
moved
311266 FM_CAN_MSG_EINSCHWENK
EN
RV/D axis: Cannot be swung in
311267 FM_CAN_MSG_AUSSCHWENK
EN
RV/D axis: Cannot be swung out
311268 FM_CAN_MSG_ABHOLEN_SP RV: bottom Z light barrier did not
respond at pick-up
311269 FM_CAN_MSG_BESTUECKEN_
SP
RV: bottom Z light barrier did not
respond during placement
311272 FM_GUI_TEXT_MA_ERR_X_AC
HSE_SERVO_FREI
x-axis servo disabled
311273 FM_GUI_TEXT_MA_ERR_Y_AC
HSE_SERVO_FREI
y-axis servo disabled
311276 FM_GUI_TEXT_MA_ERR_WAR
TE_ACHSEN_IN_POS
Axes fail to respond to command
(WARTE_ACHSE_IN_POS)
311277 FM_GUI_TEXT_MA_ERR_ACH
SEN_IN_POS_TIMEOUT
Axes fail to reach position at creep
speed
311278 FM_GUI_TEXT_MA_ERR_ACH
SEN_IN_POSITION
Axes fail to respond to command
(ACHSE_IN_POS)
311279 FM_GUI_TEXT_MA_ERR_SCH
ALTE_SERVOS
Axes fail to respond to command
(SCHALTE_SERVO)
311280 FM_GUI_TEXT_MA_ERR_PRO
G_ACHSEN
Axes fail to respond to command
(PROG_ACHSEN)
311281 FM_GUI_TEXT_MA_ERR_BREA
K_AN_ACHSEN
Axes fail to respond to command
(BREAK)
311282 FM_GUI_TEXT_MA_ERR_STAR
TTASTE_ACHSEN
Axes fail to respond to command
(STARTTASTE_ACHSE_OBEN)
311283 FM_GUI_TEXT_MA_ERR_STER
N_ACHSE_SERV
Star axis servo disabled
311284 FM_GUI_TEXT_MA_ERR_D_AC
HSE_SERVO_FREI
d-axis servo disabled
311285 FM_GUI_TEXT_MA_ERR_Z_AC
HSE_SERVO_FREI
z-axis servo disabled
311286 FM_GUI_TEXT_MA_ERR_KOPF
_ACHSFEHLER
Unable to execute axis function
311287 FM_GUI_TEXT_PORTAL_ERR_
ACHSFEHLER
Unable to execute axis function
311288 FM_GUI_TEXT_PORTAL_ERR_
ACHSSTATUS
Unable to determine state of a gantry
axis
SIPLACE GEM for S25HM, S27HM, HS50, HS60 SW Version GEM 503.02
HOST Interface Manual
©Siemens AG, all rights reserved page 211 of 243
CEID Name Description
311289 FM_GUI_TEXT_PORTAL_ERR_
SET_PORTAL_PARA
Unable to set axis parameters
311290 FM_GUI_TEXT_PORTAL_ERR_
ACHSKOMMANDO
Axis command failed
311291 FM_GUI_TEXT_PORTAL_ERR_
ACHS_NICHT_REF
Gantry axis/axes not referenced
311292 FM_GUI_TEXT_PORTAL_ERR_
ACHS_WARTEPOS
Gantry axis/axes fail to reach setpoint
position
311293 FM_GUI_TEXT_F_HW_SICHER
UNG
Motor control voltage failure, 30V fuse
defective
311294 FM_AX_TEMP_NOK Motor temerature too high
311295 FM_AX_CRASH_WARNING Crash warning activated
311296 FM_AX_ADJUSTMENT_NOK Axis adjustment not OK
* Depending on the collection event, some of the status variables <ERRORTYPE>,
<GANTRYONERROR>, <SEGMENTONERROR>, <TRACKONERROR>,
<ERRORINFO1> and <ERRORINFO2> will be updated at each of these axis
collection events.
Fiducials
CEID Name Description
410002 PCBfiducal PCB <FIDUCIALDATA> recognized
Variables HEADID (VID 1022030),
GANTRYID (2012028) and
GANTRYDROUPID (2012029)
are valid.
13
410003 FeederFiducial Feeder / MTC - <FIDUCIALDATA>
recognized
Variables HEADID (VID 1022030),
GANTRYID (2012028) and
GANTRYDROUPID (2012029)
are valid.
13
411001 FM_LAGE_DETERMINANTE 94 DETERMINANT not correct during
position recognition*
411002 FM_LAGE_MARKE_FEHLT 95 Fiducial missing in position
recognition*
411005 FM_FLE_N_MOEGL Limited conveyor position recognition*
411006 FM_FLE_N_MOEGL_SPUR Conveyor position recognition not
possible*
411009 FM_PORTALUNRUHE_X X-axis moving during measurement*
411010 FM_PRTALUNRUHE_Y Y-axis moving during measurement*
411011 FM_INKHISTO_KEINE_DATEI Parameter file for inkspot not available
411012
FM_INKHISTO_DATEI_DEFEKT
Incorrect parameters in inkspot file
