SIPLACE GEM for S25HM, S27HM, HS50, HS60 SW Version GEM 503.02
HOST Interface Manual
©Siemens AG, all rights reserved page 215 of 243
CEID Name Description
511094 FM_OPT_POS_NV_L Position: evaluation not possible (l) *
511095 FM_OPT_POS_NV_G Position: evaluation not possible (g) *
511096 FM_OPT_POS_NV_B Position: evaluation not possible (b) *
511097 FM_OPT_POS_NR_DEF Position: no result*
511098 FM_OPT_POS_NR_S Position: no result (s) *
511099 FM_OPT_POS_NR_R Position: no result (r) *
511100 FM_OPT_POS_NR_C Position: no result (c) *
511101 FM_OPT_POS_NR_G Position: no result (g) *
511102 FM_OPT_POS_NR_L Position: no result (l) *
511103 FM_OPT_POS_NR_B Position: no result (b) *
511104 FM_OPT_DIM_NV_DEF Dimension: evaluation not possible*
511105 FM_OPT_DIM_NV_S Dimension: evaluation not possible
(s) *
511106 FM_OPT_DIM_NV_R Dimension: evaluation not possible (r)
*
511107 FM_OPT_DIM_NV_C Dimension: evaluation not possible (c)
*
511108 FM_OPT_DIM_NV_L Dimension: evaluation not possible (l)
*
511109 FM_OPT_DIM_NV_G Dimension: evaluation not possible (g)
*
511110 FM_OPT_DIM_NV_B Dimension: evaluation not possible (b)
*
511111 FM_OPT_BEIN_NV_DEF No. of pins: evaluation not possible*
511112 FM_OPT_BEIN_NV_C No. of pins: evaluation not possible (c)
*
511113 FM_OPT_BEIN_NV_L No. of pins: evaluation not possible (l)
*
511114 FM_OPT_REIH_NV_DEF Colinearity: evaluation not possible*
511115 FM_OPT_TEIL_NV_DEF Spacing: evaluation not possible*
511116 FM_OPT_REIH_NV_C Colinearity: evaluation not possible (c)
*
511117 FM_OPT_REIH_NV_L Colinearity: evaluation not possible (l)
*
511118 FM_OPT_TEIL_NV_C Spacing: evaluation not possible (c) *
511119 FM_OPT_TEIL_NV_L Spacing: evaluation not possible (l) *
511120 FM_OPT_BEIN_NR_DEF No. of pins: no result*
511121 FM_OPT_BEIN_NR_C No. of pins: no result (c) *
511122 FM_OPT_BEIN_NR_L No. of pins: no result (l) *
511123 FM_OPT_DIM_NR_DEF Dimension: no result*
511124 FM_OPT_DIM_NR_S Dimension: no result (s) *
SIPLACE GEM for S25HM, S27HM, HS50 , HS60 SW Version GEM 503.02
HOST Interface Manual
Page 216 of 243 ©Siemens AG, all rights reserved
CEID Name Description
511125 FM_OPT_DIM_NR_R Dimension: no result (r) *
511126 FM_OPT_DIM_NR_C Dimension: no result (c) *
511127 FM_OPT_DIM_NR_L Dimension: no result (l) *
511128 FM_OPT_DIM_NR_G Dimension: no result (g) *
511129 FM_OPT_DIM_NR_B Dimension: no result (b) *
511130 FM_OPT_REIH_NR_DEF Colinearity: no result*
511131 FM_OPT_REIH_NR_C Colinearity: no result (c) *
511132 FM_OPT_REIH_NR_L Colinearity: no result (l) *
511133 FM_OPT_TEIL_NR_DEF Spacing: no result*
511134 FM_OPT_TEIL_NR_C Spacing: no result (c) *
511135 FM_OPT_TEIL_NR_L Spacing: no result (l) *
511136 FM_OPT_DIM_NK_DEF Dimension: component outside feed
tol. *
511137 FM_OPT_DIM_NK_S Dimension: component outside feed
tol. (s) *
511138 FM_OPT_DIM_NK_R Dimension: component outside feed
tol. (r) *
511139 FM_OPT_DIM_NK_C Dimension: component outside feed
tol. (c) *
511140 FM_OPT_DIM_NK_L Dimension: component outside feed
tol. (l) *
511141 FM_OPT_DIM_NK_G Dimension: component outside feed
tol. (g) *
511142 FM_OPT_DIM_NK_B Dimension: component outside feed
tol. (b) *
511143 FM_OPT_BEIN_NK_DEF No. of pins: component outside feed
tol. *
511144 FM_OPT_BEIN_NK_C No. of pins: cmpnt outside feed tol. (c)
*
511145 FM_OPT_BEIN_NK_L No. of pins: cmpnt outside feed tol. (l)
*
511149 FM_OPT_TEIL_NK_DEF Spacing: component outside feed
tolerance*
511150 FM_OPT_TEIL_NK_C Spacing: component outside feed tol.
(c) *
511151 FM_OPT_TEIL_NK_L Spacing: component outside feed tol.
(l) *
511152 FM_MVSBILD_UPLOAD_SYST
EM
Error upon saving the component
image*
511153 FM_MVSBILD_UPLOAD_ABSP
EICHERN
Error upon saving the MVS image to
file*
511155 FM_VS_AUSWERTEZEIT VS: Max. evaluation time for optical
centering exceeded*
SIPLACE GEM for S25HM, S27HM, HS50, HS60 SW Version GEM 503.02
HOST Interface Manual
©Siemens AG, all rights reserved page 217 of 243
CEID Name Description
511158 FM_MESSUNG_UNVOLLSTAE
NDIG
Calibration tool not fully measured *
511159 FM_QUALITAET GF or Fiducial quality not sufficient
or brightness of ink spot recognition
not sufficient*
511160 FM_MVS_FEHLER MVS: communication error*
511161 FM_OPT_SPURLEER Track empty, optical centering
incorrect
511162 FM_VS_DATA_ANF_DSV VS: Data inaccurate or not available
when requested
511163 FM_VS_SYSTEM VS: General system error
511164 FM_VS_TIMEOUT VS: Timeout in communication
* Depending on the collection event, some of the status variables <ERRORTYPE>,
<GANTRYONERROR>, <SEGMENTONERROR>, <TRACKONERROR>,
<ERRORINFO1> and <ERRORINFO2> will be updated at each of these vision
collection events.
Transport
CEID Name Description
610031 PCBreachedInputConveyor The light barrier of the input conveyor
1 signals the arrival of a PCB
1
610061 PCBreachedFirstProcessingCon
veyor
The light barrier of the conveyor 1
(processing 1 area) signals the arrival
of a PCB
1
610062 PCBreachedIntermediateConvey
or
The light barrier of the conveyor 1
(intermediate area) signals the arrival
of a PCB
1
610063 PCBreachedSecondProcessing
Conveyor
The light barrier of the conveyor 1
(processing 2 area) signals the arrival
of a PCB
1
610033 PCBreachedOutputConveyor The light barrier of the output
conveyor 1 signals the arrival of a
PCB
1
610034 PCBreachedInputConveyor2 The light barrier of the input conveyor
on twin side signals the arrival of a
PCB
1
610066 PCBreachedFirstProcessingCon
veyor2
The light barrier of the conveyor 2
(processing 1 area) signals the arrival
of a PCB
1
610067 PCBreachedIntermediateConvey
or2
The light barrier of the conveyor 2
(intermediate area) signals the arrival
of a PCB
1
