SIPLACE GEM for S25HM, S27HM, HS50, HS60 SW Version GEM 503.02
HOST Interface Manual
©Siemens AG, all rights reserved page 217 of 243
CEID Name Description
511158 FM_MESSUNG_UNVOLLSTAE
NDIG
Calibration tool not fully measured *
511159 FM_QUALITAET GF or Fiducial quality not sufficient
or brightness of ink spot recognition
not sufficient*
511160 FM_MVS_FEHLER MVS: communication error*
511161 FM_OPT_SPURLEER Track empty, optical centering
incorrect
511162 FM_VS_DATA_ANF_DSV VS: Data inaccurate or not available
when requested
511163 FM_VS_SYSTEM VS: General system error
511164 FM_VS_TIMEOUT VS: Timeout in communication
* Depending on the collection event, some of the status variables <ERRORTYPE>,
<GANTRYONERROR>, <SEGMENTONERROR>, <TRACKONERROR>,
<ERRORINFO1> and <ERRORINFO2> will be updated at each of these vision
collection events.
Transport
CEID Name Description
610031 PCBreachedInputConveyor The light barrier of the input conveyor
1 signals the arrival of a PCB
1
610061 PCBreachedFirstProcessingCon
veyor
The light barrier of the conveyor 1
(processing 1 area) signals the arrival
of a PCB
1
610062 PCBreachedIntermediateConvey
or
The light barrier of the conveyor 1
(intermediate area) signals the arrival
of a PCB
1
610063 PCBreachedSecondProcessing
Conveyor
The light barrier of the conveyor 1
(processing 2 area) signals the arrival
of a PCB
1
610033 PCBreachedOutputConveyor The light barrier of the output
conveyor 1 signals the arrival of a
PCB
1
610034 PCBreachedInputConveyor2 The light barrier of the input conveyor
on twin side signals the arrival of a
PCB
1
610066 PCBreachedFirstProcessingCon
veyor2
The light barrier of the conveyor 2
(processing 1 area) signals the arrival
of a PCB
1
610067 PCBreachedIntermediateConvey
or2
The light barrier of the conveyor 2
(intermediate area) signals the arrival
of a PCB
1
SIPLACE GEM for S25HM, S27HM, HS50 , HS60 SW Version GEM 503.02
HOST Interface Manual
Page 218 of 243 ©Siemens AG, all rights reserved
CEID Name Description
610068 PCBreachedSecondProcessing
Conveyor2
The light barrier of the conveyor 2
(processing 2 area) signals the arrival
of a PCB
1
610036 PCBreachedOutputConveyor2 The light barrier of the output
conveyor 2 signals the arrival of a
PCB.
1
610037 TransportWidthMeasured The SIPLACE finished the
measurement of the
<TRANSPORTWIDTH> (initiated by
line computer)
4
610044 TransportWidthMeasured2 The SIPLACE finished the
measurement of the
<TWINTRANSPORTWIDTH>on
conveyor 2 (initiated by line computer)
4
610051 TakeOutInConv A PCB was taken out of the input
conveyor 1
1
610069 TakeOutProcessing1Conv A PCB was taken out of the conveyor
1 (processing 1 area)
1
610070 TakeOutIntermediateConv A PCB was taken out of the
intermediate conveyor 1
1
610071 TakeOutProcessing2Conv A PCB was taken out of the conveyor
1 (processing 2 area)
1
610052 TakeOutOutConv A PCB was taken out of the output
conveyor 1
1
610053 TakeOutInConv2 A PCB was taken out of the input
conveyor 2
1
610072 TakeOutProcessing1Conv2 A PCB was taken out of the conveyor
2 (processing 1 area)
1
610073 TakeOutIntermediateConv2 A PCB was taken out of the
intermediate conveyor 2
1
610074 TakeOutProcessing2Conv2 A PCB was taken out of the conveyor
2 (processing 2 area)
1
610054 TakeOutOutConv2 A PCB was taken out of the output
conveyor 2
1
611025 FM_LSAUT_VERFAHRBER Conveyor belt target width outside
travel range*
611030 FM_LSK_MAX_SCHRITT Proximity switch not found during
conveyor belt width check*
611031 FM_LSK_PROXIMITY
SWITCH_N_FREI
Proximity switch switched before
conveyor belt width check*
611059
FM_GUI_TEXT_F_UEBERN_EB
Error upon PCB transfer in input
conveyor
611060
FM_GUI_TEXT_F_UEBERG_EB
Error upon PCB transfer in input
conveyor
611061
FM_GUI_TEXT_F_LP_LANG_EB
Overlength PCB in input conveyor
611062
FM_GUI_TEXT_F_UEBERN_BB1
Error upon PCB transfer in processing
conveyor 1
SIPLACE GEM for S25HM, S27HM, HS50, HS60 SW Version GEM 503.02
HOST Interface Manual
©Siemens AG, all rights reserved page 219 of 243
CEID Name Description
611063
FM_GUI_TEXT_F_UEBERG_BB1
Error upon PCB transfer in processing
conveyor 1
611064
FM_GUI_TEXT_F_HT1_TIMEOUT
Lifting table 1 Timeout
611065
FM_GUI_TEXT_F_HT1_BERO1
Lifting table 1 Bero 1 defective
611066
FM_GUI_TEXT_F_HT1_BERO2
Lifting table 1 Bero 2 defective
611067
FM_GUI_TEXT_F_HT1_
DREHRICHT
Lifting table 1 incorrect direction of
rotation
611068 FM_GUI_TEXT_F_STOPPER1 Stopper ahead (Processing area 1)
defect
611069 FM_GUI_TEXT_F_ZENTR1 Error ceramic substrate centering 1
611070 FM_GUI_TEXT_F_LP_
ZURUECK_BB1
Pull back PCB in first processing
conveyor
611071 FM_GUI_TEXT_F_LP_LANG_
BB1
Overlength PCB in first processing
conveyor
611072 FM_GUI_TEXT_F_LP_ENTNO
MMEN_BB1
PCB removed from first processing
conveyor in automatic mode
611073 FM_GUI_TEXT_F_UEBERN_ZB Error upon PCB transfer in
intermediate conveyor
611074
FM_GUI_TEXT_F_UEBERG_ZB
Error upon PCB transfer in
intermediate conveyor
611075
FM_GUI_TEXT_F_LP_LANG_ZB
Overlength PCB in intermediate
conveyor
611076
FM_GUI_TEXT_F_UEBERN_BB2
Error upon PCB transfer in second
processing conveyor
611077
FM_GUI_TEXT_F_UEBERG_BB2
Error upon PCB transfer in second
processing conveyor
611078
FM_GUI_TEXT_F_HT2_TIMEOUT
Lifting table 2 timeout
611079 FM_GUI_TEXT_F_HT2_BERO1 Lifting table 2 Bero 1 defective
611080 FM_GUI_TEXT_F_HT2_BERO2 Lifting table 2 Bero 2 defective
611081 FM_GUI_TEXT_F_HT2_DREH
RICHT
Lifting table 2 incorrect direction of
rotation
611082 FM_GUI_TEXT_F_STOPPER2 Stopper at the back (processing area
2) defect
611083 FM_GUI_TEXT_F_ZENTR2 Error ceramic substrate centering 2
611084 FM_GUI_TEXT_F_LP_ZURUEC
K_BB2
Pull back PCB in second processing
conveyor
611085
FM_GUI_TEXT_F_LP_LANG_BB2
Overlength PCB second processing
conveyor
611086
FM_GUI_TEXT_F_LP_ENTNOMME
N_BB2
PCB removed from processing
conveyor 2 in automatic mode
611087
FM_GUI_TEXT_F_UEBERN_AB
Error upon PCB transfer in output
conveyor
