SIPLACE GEM for S25HM, S27HM, HS50, HS60 SW Version GEM 503.02
HOST Interface Manual
©Siemens AG, all rights reserved page 225 of 243
CEID Name Description
pressed
1120105 ToGUIEmergencyButton Message to GUI: Emergency button
pressed
1
1120117 ToGUIBarcodeError Message to GUI: PCB-Barcode error 1
1120216 ToGUICtrlModeChanged Control Mode change (Stand-alone,
GEM-Host or LCU) is completed.
1
1120258 ToGUIRefRunReady Machine is ready to start reference
run
1
1120259 ToGUInewjobname display new jobname 1
1120300 MessageFromGuiGeneral General Event for all Messages from
GUI
Messages from GUI can be reported
either with specific events (one
event with one CEID for each
individual message) or with the
Event MessageFromGuiGeneral.
The variable 1122007
<GUIMESSAGENUMBER >
contains the CEID of the specific
GUI message.
45
1120301 MessageToGuiGeneral General Event for all Messages to
GUI
Messages to GUI can be reported
either with specific events (one
event with one CEID for each
individual message) or with the
Event MessageToGuiGeneral.
The variable 1122007 <
GUIMESSAGENUMBER> contains
the CEID of the specific Message To
Gui.
45
CAN-Bus
CEID Name Description
1211001 FM_CAN_INI_APL CAN bus: Initialization faulty*
1211002 FM_CAN_SND_OVL CAN bus: transmission source
overflow*
1211003 FM_CAN_NO_CAR CAN bus: reception job before
transmission job*
1211004 FM_CAN_RCV_TOUT CAN bus: reception call aborted
with timeout*
1211005 FM_CAN_RCV_OVR CAN bus: reception source
overflow*
1211006 FM_CAN_CNT_EXL CAN bus: error hysteresis counter
exceeded*
SIPLACE GEM for S25HM, S27HM, HS50 , HS60 SW Version GEM 503.02
HOST Interface Manual
Page 226 of 243 ©Siemens AG, all rights reserved
CEID Name Description
1211007 FM_CAN_BUS_OFF CAN bus: switched out*
1211008
FM_CAN_FHL_NR_UNBEKANNT
CAN bus: unknown error number*
1211013
FM_CAN_MSG_LS_ZHS_FALSE
Star can't be turned due to light
barrier z-top*
1211014
FM_CAN_MSG_SM_DPS_FALSE
Star can't be turned due to d-axis
feed drive*
1211015
FM_CAN_MSG_SM_ZHS_FALSE
Star can't be turned due to pick-
up/place valve actuator*
1211016
FM_CAN_MSG_SM_BAS_FALSE
Star can't be turned due to ejection
valve actuator*
1211017 FM_CAN_MSG_LS_ZHS_
START_XY
RV: Gantry can't be moved due to
light barrier z-top*
1211019 FM_CAN_MSG_ZHS_ABH RV: Fault in pick-up/place valve
actuator during pick-up*
1211020 FM_CAN_MSG_LS_Z_O_ABH_
SP
RV: Light barrier z-top not triggered
during pick-up*
1211022 FM_CAN_MSG_ZHS_BST RV: Fault in pick-up/place valve
actuator during placement*
1211023 FM_CAN_MSG_LS_Z_O_BST_S
P
RV: Light barrier z-top not triggered
during placement*
1211025 FM_CAN_MSG_VAKUUM_
MESS_SP
RV: vacuum cannot be measured
1211026
FM_CAN_MSG_BLASL_MESS_SP
RV: forced air cannot be measured
1211027
FM_CAN_MSG_VAKUUM_AUS_SP
RV: vacuum cannot be switched
off
1211028
FM_CAN_MSG_VAKUUM_EIN_SP
RV: vacuum cannot be switched on
1211029
FM_CAN_MSG_BLASL_EIN_SP
RV: forced air cannot be switched
on
1211030
FM_CAN_MSG_BLASL_AUS_SP
RV: forced air cannot be switched
off
1211031 FM_CAN_MSG_INIT_Z Valve adjustment drive pick-
up/placement cannot be initialized
1211032 FM_CAN_MSG_INIT_D RV/D axis: feeder drive cannot be
initialized
1211033 FM_CAN_MSG_INIT_ABW Valve adjustment drive ejection
cannot be initialized
1211034 FM_CAN_MSG_BELEUCHT_BE
_SP
RV: component camera
illumination cannot be operated
1211037 FM_CAN_MSG_BELEUCHT_LP Board camera illumination cannot
be operated
1211038 FM_CAN_MSG_FHL_NR_
UNBEK_SP
RV: unknown error number from
head board
1211039 FM_GUI_TEXT_TI_CCAN_NO_ System error in CAN
SIPLACE GEM for S25HM, S27HM, HS50, HS60 SW Version GEM 503.02
HOST Interface Manual
©Siemens AG, all rights reserved page 227 of 243
CEID Name Description
SYNC_CALL communication (CCAN_NOK)
1211040 FM_GUI_TEXT_TI_CCANDL_
NO_SYNC_CALL
System error in CAN
communication (CCANDL_NOK)
1211041
FM_GUI_TEXT_TI_CAN_M_NOK
Component table: Error in
communication with CAN bus (no
status signal)
1211042
FM_GUI_TEXT_TI_CAN_M_BUSY
Component table: Error in
communication with CAN bus
(overload)
1211043
FM_GUI_TEXT_TI_CAN_M_TIME_
OUT
Component table: Error in
communication with CAN bus
(timeout)
1211044 FM_GUI_TEXT_TI_CAN_M_NO
_PROG
Component table: Error in
communication with CAN bus (no
program)
1211045 FM_GUI_TEXT_TI_CAN_M_CM
D_FALSE
Component table: Error in
communication with CAN bus
(incorrect command)
1211046 FM_GUI_TEXT_TI_CAN_M_NO
_TARGET
Component table: Error in
communication with CAN bus
(incorrect receiver)
1211047 FM_GUI_TEXT_TI_CAN_WRON
G_QUITT
Component table: Unknown
acknowledgment from CAN bus
1211048 FM_GUI_TEXT_TI_CAN_WR_Q
UITT_L
Component table: Incorrect length
of acknowledgment message from
CAN bus
1211049 FM_GUI_TEXT_TI_CCAN_NO_
NORM
System error (CCAN_NO_NORM)
1211050 FM_GUI_TEXT_TI_CCAN_NO_
VIRT
System error (CCAN_NO_VIRT)
1211051
FM_GUI_TEXT_GS_CAN_M_NOK
Tape cutting unit: Error in
communication with CAN bus (no
status signal)
1211052
FM_GUI_TEXT_GS_CAN_M_BUSY
Tape cutting unit: Error in
communication with CAN bus
(overload)
1211053 FM_GUI_TEXT_GS_CAN_M_TI
ME_OUT
Tape cutting unit: Error in
communication with CAN bus
(timeout)
1211054 FM_GUI_TEXT_GS_CAN_M_N
O_PROG
Tape cutting unit: Error in
communication with CAN bus (no
program)
1211055 FM_GUI_TEXT_GS_CAN_M_C
MD_FALSE
Tape cutting unit: Error in
communication with CAN bus
(incorrect command)
1211056 FM_GUI_TEXT_GS_CAN_M_N
O_TARGET
Tape cutting unit: Error in
communication with CAN bus
(incorrect command)
