SIPLACE GEM for S25HM, S27HM, HS50 , HS60 SW Version GEM 503.02
HOST Interface Manual
Page 230 of 243 ©Siemens AG, all rights reserved
Revolver Head 2
CEID Name Description
1410001 Place2Cycle Placement cycle completed on SP-head 2 and
<PLACEINFOREV2>, <PLACEINFOREV2SUB1>
will be updated.
6
1410002 PickUp2Cycle Pick-up cycle completed on SP-head 2 and
<PICKUPINFOREV2> will be updated.
9
1410003 Nozzle2changed <NOZZLECONF2> changed on revolver head 2
(not in single function mode).
15
1410004 RefRunHead2 Head <HEIGHTREV2> reference run complete on
revolver head 2.
20
1410005 NozzleRefRun2 <NOZZLECONF2> length reference run complete
on revolver head 2.
15
1410006 VacRefRun2 <VAKUUMDATAREV2> reference run complete on
revolver head 2.
22
Data Preparation
CEID Name Description
1611012 FM_LRR_DA_MA_AKT_NOK Data preparation : cannot
save current MA data*
1611046 FM_LRR_DA_NU Data preparation : error in
cluster data*
1611056 FM_LRR_DA_RS Data preparation : error in set-
up data*
1611065 FM_LRR_DA_GF Data preparation : error in
package form data*
1611077 FM_LRR_DA_MK Data preparation : error in
fiducial data*
1611080 FM_LRR_DA_LMKD_GEM DP: Fiducial message in
mixed line not allowed*
1611122 FM_LRR_GEM DP cannot correctly create
GEM data structures*
1611123 FM_LRR_GEM_FILE DP for GEM: Error upon
writing a file for storing GEM
data*
1611126 FM_HDA_MAKE_AKTUELL_HST HDP: Process program file for
MC cannot be created*
1611127 FM_HDA_MAKE_AKTUELL_DAT HDP: Copy of MC structures
cannot be created*
1611131 FM_HDA_PARSE HDP: Faulty placement
program*
SIPLACE GEM for S25HM, S27HM, HS50, HS60 SW Version GEM 503.02
HOST Interface Manual
©Siemens AG, all rights reserved page 231 of 243
CEID Name Description
1611136 FM_GF_DATA_STORE Error upon saving GF data
1611137 FM_MK_DATA_STORE Error upon saving MK data
1611138 FM_GUI_TEXT_MA_ERR_READING_R
EAL_MA
Error reading REAL.MA file
1611139 FM_GUI_TEXT_MA_ERR_WRITING_R
EAL_MA
Error writing REAL.MA file
1611140 FM_GUI_TEXT_LP_NO_VERM_DATA No measuring data available
1611141 FM_GUI_TEXT_BB_HO_MA_DAT_ERR Error in machine data supply
1611142 FM_GUI_TEXT_BB_HO_RS_DAT_ERR Error in setup data supply
1611143 FM_LRR_DA_MA Error in the machine data
1611144 FM_SIPRO_COMM_CONF Communication error or
configuration error with
SIPLACE Pro
* Depending on the collection event, some of the status variables <ERRORTYPE>,
<GANTRYONERROR>, <SEGMENTONERROR>, <TRACKONERROR>,
<ERRORINFO1> and <ERRORINFO2> will be updated at each of these CAN-bus
collection events.
Trolley
CEID Name Description
1711005
FM_WAG_F_KOMM_UNTERBR
Communication table-feeder
interrupted*
1711017
FM_GUI_TEXT_TI_CCAN_NO_TISCH
Component table: System error
(CCAN_NO_TISCH)
1711018
FM_GUI_TEXT_TI_CCAN_NO_GS
Tape cutting unit: System error
(CCAN_NO_GS)
1711019
FM_GUI_TEXT_TI_CCAN_NO_DIAG_T
I
Component table: System error
(CCAN_NO_DIAG_TI)
1711020
FM_GUI_TEXT_TI_CCAN_NO_DIAG_
GS
Tape cutting unit: System error
(CCAN_NO_DIAG_GS)
1711021
FM_GUI_TEXT_TI_CCAN_NO_SIMU
Component table: System error
(CCAN_NO_SIMU)
1711022
FM_GUI_TEXT_TI_NO_TISCHKAL
System error (NO_TISCHKAL)
1711023
FM_GUI_TEXT_TI_BE_KEIN_ZIEL
Component table: System
configuration error
(BE_KEIN_ZIEL)
1711024
FM_GUI_TEXT_TI_GS_KEIN_ZIEL
Tape cutting unit: System
configuration error
(GS_KEIN_ZIEL)
1711025
FM_GUI_TEXT_GS_CAN_GENERAL
Tape cutting unit: General error
· Depending on the collection event, some of the status variables <ERRORTYPE>,
<GANTRYONERROR>, <SEGMENTONERROR>, <TRACKONERROR>,
SIPLACE GEM for S25HM, S27HM, HS50 , HS60 SW Version GEM 503.02
HOST Interface Manual
Page 232 of 243 ©Siemens AG, all rights reserved
<ERRORINFO1> and <ERRORINFO2> will be updated at each of these trolley
collection events.
Filling Level
CEID Name Description
1711030 FM_FK_TRACK_RUN_LOW_MIN The track will run empty in a few
minutes.
1711031
FM_FK_TRACK_RUN_LOW_VALUE
The track will run empty because the
amount is below the minimum
amount.
1711032 FM_FK_TRACK_RUN_LOW_PER
CENT
The track will run empty because the
amount is at the percentile
minimum.
1711035 FM_FK_TRACK_ISEMPTY_PERC
ENT
The track has been deactivated
because the amount is below the
percentile minimum
1711036 FM_FK_TRACK_INACT_BC The track has been deactivated
because the barcode of one
component is incorrect.
· Depending on the collection event, some of the status variables <ERRORTYPE>,
<GANTRYONERROR>, <SEGMENTONERROR>, <TRACKONERROR>,
<ERRORINFO1> and <ERRORINFO2> will be updated at each of these trolley
collection events.
Miscellaneous
CEID Name Description
2010001 CoverOpen The protective covers was opened 1
2010002 CoverClosed The protective covers was closed 1
2010004 TrackFull Track reset to full
MACHINESIDE <2012022>,
LOCATION <2012035>,
TRACKNUMBER <2012023>
are valid
LOCATION = -1 means that all tracks of
all locations have been refilled
TRACKNUMBER = -1 means that all
tracks of the specified location have been
refilled
1
2010005 TrackEmpty Track set to empty
In the case of a feeder (not MTC)
TRACKNUMBER <2012023>,
SEGMENT <2012026>,
MACHINESIDE <2012022>,
LOCATION <2012035>
are valid
1
