SIPLACE GEM for S25HM, S27HM, HS50, HS60 SW Version GEM 503.02 HOST Inter fac e Manual ©Siemens AG, all rights reser ved page 233 of 243 2010006 RefRunGantr y1 Ref erence r un com plete f or the gantry 1 axis 1 2010007 R…

SIPLACE GEM for S25HM, S27HM, HS50 , HS60 SW Version GEM 503.02

HOST Interface Manual

<ERRORINFO1> and <ERRORINFO2> will be updated at each of these trolley

collection events.

Filling Level

CEID Name Description

1711030 FM_FK_TRACK_RUN_LOW_MIN The track will run empty in a few

minutes.

1711031

FM_FK_TRACK_RUN_LOW_VALUE

The track will run empty because the

amount is below the minimum

amount.

1711032 FM_FK_TRACK_RUN_LOW_PER

CENT

The track will run empty because the

amount is at the percentile

minimum.

1711035 FM_FK_TRACK_ISEMPTY_PERC

ENT

The track has been deactivated

because the amount is below the

percentile minimum

1711036 FM_FK_TRACK_INACT_BC The track has been deactivated

because the barcode of one

component is incorrect.

· Depending on the collection event, some of the status variables <ERRORTYPE>,

<GANTRYONERROR>, <SEGMENTONERROR>, <TRACKONERROR>,

<ERRORINFO1> and <ERRORINFO2> will be updated at each of these trolley

collection events.

Miscellaneous

CEID Name Description

2010001 CoverOpen The protective covers was opened 1

2010002 CoverClosed The protective covers was closed 1

2010004 TrackFull Track reset to full

MACHINESIDE <2012022>,

LOCATION <2012035>,

TRACKNUMBER <2012023>

are valid

LOCATION = -1 means that all tracks of

all locations have been refilled

TRACKNUMBER = -1 means that all

tracks of the specified location have been

refilled

2010005 TrackEmpty Track set to empty

In the case of a feeder (not MTC)

TRACKNUMBER <2012023>,

SEGMENT <2012026>,

MACHINESIDE <2012022>,

LOCATION <2012035>

are valid

SIPLACE GEM for S25HM, S27HM, HS50, HS60 SW Version GEM 503.02

HOST Interface Manual

2010006 RefRunGantry1 Reference run complete for the gantry 1

axis

2010007 RefRunGantry2 Reference run complete for the gantry 2

axis

2010008 TableDownload Software downloaded to the table and

<SOFTWAREREVTABLE> will be

updated.

2010009 SingleCircuitOmit The machine signals that it found a single

circuit to omit (Ink Punkt)

Variables HEADID (VID 1022030),

GANTRYID (2012028) and

GANTRYDROUPID (2012029)

are valid.

2010010 TapeCut1 Tape cut at location 1 1

2010011 TapeCut2 Tape cut at location 2 1

2010015 MachineReStarted SIPLACE station is re-booting 1

2010016 PickupError An Pickup-Error has occured and

<SEGMENT>, <COMPONENTNAME>,

<MASCHINESIDE>, <LOCATION>,

<TRACKNUMBER>, <DIVISION>,

<LEVEL>, <GANTRYID>,

will be updated

2010017 PlaceError An Place-Error has occured and

<SEGMENT>,

<REFERENCEDESIGNATOR>,

<COMPONENTNAME>, <GANTRYID>,

<GANTRYGROUPID>, <HEADID>,

<PACKAGEFORMNUMBER> and

<PLACEERRORDESCRIPTION> will be

updated

2010018 RefRunGantry3 Reference run complete for the gantry 3

axis

2010019 RefRunGantry4 Reference run complete for the gantry 4

axis

2010033 MTCDownload Software downloaded to the MTC and

<SOFTWAREREVMTC> will be updated.

2010021 PCBstartProc1Conv1 Start of the placement process for the

PCB in the conveyor 1 processing area 1

<GANTRYINFOREV1>,

<GANTRYINFOREV4>,

<SEGMENTINFO1 >,

will be resetted.

2010022 PCBreadyProc1Conv1 Placement is finished for the PCB in the

conveyor 1 processing area 1.

2010023 PCBstartProc2Conv1 Start of the placement process for the

PCB in the conveyor 1 processing area 2

<GANTRYINFOREV2>,

<GANTRYINFOREV3>,

SIPLACE GEM for S25HM, S27HM, HS50 , HS60 SW Version GEM 503.02

HOST Interface Manual

<SEGMENTINFO2 >,

will be resetted.

2010024 PCBreadyProc2Conv1 Placement is finished for the PCB in the

conveyor 1 processing area 2.

2010025 PCBstartProc1Conv2 Start of the placement process for the

PCB in the conveyor 2 processing area 1

<GANTRYINFOREV1>,

<GANTRYINFOREV4>,

<SEGMENTINFO1 >,

will be resetted.

2010026 PCBreadyProc1Conv2 Placement is finished for the PCB in the

conveyor 2 processing area 1.

2010027 PCBstartProc2Conv2 Start of the placement process for the

PCB in the conveyor 2 processing area 2

<GANTRYINFOREV2>,

<GANTRYINFOREV3>,

<SEGMENTINFO2 >,

will be resetted.

2010028 PCBreadyProc2Conv2 Placement is finished for the PCB in the

conveyor 2 processing area 2.

2010029 PickPlaceStartProc1 The machine is starting to pick up and

place components in Processing1 Area.

2010030 PickPlaceStopProc1 The Pick/Place process in Processing 1

Area has been interrupted or is finished.

2010031 PickPlaceStartProc2 The machine is starting to pick up and

place components in Processing2 Area.

2010032 PickPlaceStopProc2 The Pick/Place process in Processing 2

Area has been interrupted or is finished.

2010034 TapeCut3 Tape cut at location 3 1

2010035 TapeCut4 Tape cut at location 4 1

Other Error-Events

CEID Name Description

2211001 FM_ABH_KEIN_BE Component not at nozzle after pick-

2211002 FM_BEST_KEIN_BE Component not at nozzle before

placement

2211003 FM_ABH_SPURLEER Track empty, no component during

pick-up

2211004 FM_FM_SPURLEER Flatpack magazine is empty

2211005 FM_MHS_CRASH_GEFAHR Second gantry in travel range

2211006 FM_VAK_DELTA_GRENZE_SP RV: intervals open - closed vacuum
