SIPLACE GEM for S25HM, S27HM, HS50 , HS60 SW Version GEM 503.02 HOST Inter fac e Manual Page 42 of 243 ©Siemens AG, all rights reser ved 3.6 Material M ovement The Events and Variables f rom the Material Movem ent depend…
SIPLACE GEM for S25HM, S27HM, HS50, HS60 SW Version GEM 503.02
HOST Interface Manual
©Siemens AG, all rights reserved page 41 of 243
Variable Name VID
CONFIGALARMS 1002018
WBITS5 1002019
ALARMID 1002013
ALARMSERIAL 1002015
ALARMSENABLED 1002020
ALARMSSET 1002021
ALARMSTATE 1002014
3.5.7 Related Collection Events
Each alarm defined on the SIPLACE has two unique collection events associated with it, a
"Going-On" event, and a "Going-Off" event. The CEIDs are listed in "Appendix B --
Collection Events".
SIPLACE GEM for S25HM, S27HM, HS50 , HS60 SW Version GEM 503.02
HOST Interface Manual
Page 42 of 243 ©Siemens AG, all rights reserved
3.6 Material Movement
The Events and Variables from the Material Movement depend on the structure of the
machine at hand. The following diagram shows the individual areas of the PCB conveyor:
Conveyor HS50, HS60
Conveyor S25HM, S27HM
3.6.1 Related Variables
The following table lists the variables which are relevant to material movement. 'TWIN'
variables are required for the dual conveyor.
For a more complete description of these variables, see "Appendix A -- Variables".
Variable Name VID
HS50,
HS60
S25HM,
S27HM
INPUTCONVEYORSTATE 612011
4 4
FIRSTPROCESSINGCONVEYORSTATE 612012
4 4
INTERMEDIATECONVEYORSTATE 612013
4
SECONDPROCESSINGCONVEYORSTATE 612014
4
OUTPUTCONVEYORSTATE 612015
4 4
TWININPUTCONVEYORSTATE 612021
4 4
TWINFIRSTPROCESSINGCONVEYORSTATE 612022
4 4
TWININTERMEDIATECONVEYORSTATE 612023
4
TWINSECONDPROCESSINGCONVEYORSTATE 612024
4
TWINOUTPUTCONVEYORSTATE 612025
4 4
TRANSPORTWIDTH 612007
4 4
TWINTRANSPORTWIDTH 612017
4 4
3.6.2 Related Collection Events
There are 5 CEID related to then Material Movement Capability. For a more complete
listing of these collection events, please see "Appendix B -- Collection Events".
Input
Conveyor
First
Processing
Conveyor
Intermediate
Conveyor
Output
Conveyor
Second
Processing
Conveyor
Input
Conveyor
First
Processing
Conveyor
Output
Conveyor
SIPLACE GEM for S25HM, S27HM, HS50, HS60 SW Version GEM 503.02
HOST Interface Manual
©Siemens AG, all rights reserved page 43 of 243
The Events with a '2' at the end of the Event name (e.g., PCBreachedOutputConveyor2)
refer to the 2
nd
belt of a dual conveyor.
Collection Event CEID
HS50,
HS60
S25HM,
S27HM
PCBreachedInputConveyor 610031
4 4
PCBreachedFirstProcessingConveyor 610061
4 4
PCBreachedIntermediateConveyor 610062
4
PCBreachedSecondProcessingConveyor 610063
4
PCBreachedOutputConveyor 610033
4 4
PCBreachedInputConveyor2 610034
4 4
PCBreachedFirstProcessingConveyor2 610066
4 4
PCBreachedIntermediateConveyor2 610067
4
PCBreachedSecondProcessingConveyor2 610068
4
PCBreachedOutputConveyor2 610036
4 4
TransportWidthMeasured 610037
4 4
TransportWidthMeasured2 610044
4 4
TakeOutInConv 610051
4 4
TakeOutProcessing1Conv 610069
4 4
TakeOutIntermediateConv 610070
4
TakeOutProcessing2Conv 610071
4
TakeOutOutConv 610052
4 4
TakeOutInConv2 610053
4 4
TakeOutProcessing1Conv2 610072
4 4
TakeOutIntermediateConv2 610073
4
TakeOutProcessing2Conv2 610074
4
TakeOutOutConv2 610054
4 4
