SP60P-M Mechanical 20120628 - 第170页
5-A カートリ ッジヘッド対応 Ca rt ridg e H ead su pp ort パーツレイアウト Kit N o . キット品 番 Kit N am e キット名称 KXFX 039V A00 ｾｸｼｮﾝNo. PARTS LAYOUT Section No. - - S9 ( KKXFX039VA00-04-1 )
Ref
No.
Remarks
R
1
Q'ty
4
基板下受
け
ピン
M
(
一括交換
)
Board-Support Pins M (Collectively Changing)
ｲﾗｽﾄ
No.
Part No.
品 名品番 数量
R
2
パーツリスト
Kit No.
キット
品番
Kit Name
キット 名称
KXFX033YA00
Part Name
備 考
ｾｸｼｮﾝ
No
.
PARTS LIST
Section No.
R
3
PIN
200
1 KXFB00FFA00
PLATE
2
2 KXFB04MKA01
PLATE
2
3 KXFB04MLA01
PLATE
3
4 KXFB04MMA00
PLATE
4
5 KXFB04MNA00
SHAFT
4
6 KXFB03AQA00
DOG
4
7 KXFB04MPA00
DOG
4
8 KXFB0257A02
DOG
6
9 KXFB0258A02
DOG
8
10 KXFB0259A02
BOLT
22
11 KXF09TBAA00 GUTB3-4-20
O-RING
22
12 KXF0DY5ZA00 P5
S8
-
-
( KKXFX033YA00-02 )
5-A
カートリッジヘッド対応
Cartridge Head support
パーツレイアウト
Kit N
o
.
キット品
番
Kit Name
キット名称
KXFX039VA00
ｾｸｼｮﾝNo.
PARTS LAYOUT
Section No.
--
S9
( KKXFX039VA00-04-1 )
Ref
No.
Remarks
R
1
Q'ty
5-A
カートリッジヘッド
対応
Cartridge Head support
ｲﾗｽﾄ
No.
Part No.
品 名品番 数量
R
2
パーツリスト
Kit No.
キット
品番
Kit Name
キット 名称
KXFX039VA00
Part Name
備 考
ｾｸｼｮﾝ
No
.
PARTS LIST
Section No.
R
3
HINGE
2
1 KXFB029YA00
SHAFT
1
2 KXFB029ZA00
SHAFT
1
3 KXFB02A0A00
KNOB
1
4 KXFB02A1A01
JOINT
2
5 KXFB02A4A00
COLLAR
2
6 KXFB02A5A00
PLATE
1
7 KXFB02A7A00
ARM
1
8 KXFB02A8A00
ARM
1
9 KXFB02A9A00
KNOB
2
10 KXFB02AAA00
COLLAR
2
11 KXFB02ABA00
PLATE
1
12 N210001466AA
BLOCK
1
13 KXFB02ADA01
BLOCK
1
14 KXFB02AEA00
PLATE
1
15 KXFB02AFA00
PLATE
1
16 KXFB02AGA00
BRACKET
1
17 KXFB02ALA00
COVER
1
18 KXFB02ANA00
BRACKET
1
19 KXFB02ASA00
COVER
1
20 KXFB02ATA00
BRACKET
1
21 KXFB02AUA00
CYLINDER
1
22 KXF0A7SAA00 CQSB20-25D
CYLINDER
1
23 KXF0A7TAA00 CDQSB20-25D-A93L
TUBE
1
24 KXF0DWYGA00
Coil Tube D4XD2.5X5-Conductor(DA KXF0DWYGA00)
BOLT
2
25 N510017544AA
Hexagon socket button head screw M5X20-10.9 A2J (Trivalent)
SPACER
2
26 N510020129AA 3382330-40040
PLUNGER
1
27 KXF09WSAA00 BSZ6
SCREW
1
28 N510018974AA
Hexagon socket set screw Cup point M6X5-45H A2J (Trivalent)
BOLT
2
29 KXF0DWULA00 GUTB6-8-20
SHAFT
2
30 KXF0CP6AA00 SSFRD10-30.0-F12-B9-P6-N6-SC11
JOINT
3
31 KXF02BTAA00 KQL04-M5
JOINT
1
32 KXF0A7XAA00 KQK04-M5
PIN
2
33 KXF0BY4AA00 SPP1.5-6
NUT
5
34 KXF0DWUMA00 Domed cap nut M4 3-type(SUS)
SCREW
5
35 N510018282AA
Cross recessed Truss head machine screw M4X8-4.8 A2J (Trivalent)
PLUNGER
4
36 KXF0A7YAA00 PFSSN4
SHAFT
2
37 KXF0CP2AA00 NBJ02-6-65-M3-MA55
LINEAR-BUSH
2
38 KXF0A80AA00 LHIFC6
SCREW
2
39 N510018259AA
Cross recessed Truss head machine screw M4X12-4.8 A2J (Trivalent)
S10
-
-
( KKXFX039VA00-04-1 )
