SP60P-M Mechanical 20120628 - 第21页

Ref No. Remark s R 1 Q'ty 1-A 本 体部 (M) Main Body (M) ｲﾗｽﾄ No. Part No. 品 名 品番 数量 R 2 パーツリスト Kit N o . キット品 番 Kit Name キット名称 KXFX039AA00 Part Nam e 備 考 ｾｸｼｮﾝNo. PARTS LIST Section No. R 3 FRAME 1 1 N210002182AD BAR 1…

100%1 / 264
1-A
本
体部
(M)
Main Body(M)
パーツレイアウト
Ki
t
N
o
.
キット
品番
Kit Name
キット名称
KXFX039AA00
ｾｸｼｮﾝNo.
PARTS LAYOUT
Section No.
--
M1
( KKXFX039AA00-14-1 )
Ref
No.
Remarks
R
1
Q'ty
1-A
本
体部
(M)
Main Body(M)
ｲﾗｽﾄ
No.
Part No.
品　　名品番 数量
R
2
パーツリスト
Kit N
o
.
キット品
番
Kit Name
キット名称
KXFX039AA00
Part Name
備　　　考
ｾｸｼｮﾝNo.
PARTS LIST
Section No.
R
3
FRAME
1
1 N210002182AD
BAR
1
2 N210044657AA
BOLT
4
3 KXFB05CGA01
PLATE
4
4 N210009258AA
COLLAR
4
5 KXFB05CKA01
BRACKET
1
6 N210002187AB
COLLAR
1
7 KXFB04KZA01
BLOCK
1
8 KXFB065AA00
SHEET
1
9 KXFB02W6A00
BRACKET
1
10 KXFB0056A00
BRACKET
1
11 KXFB02YYA01
BRACKET
1
12 N210044658AA
BRACKET
2
13 N210044791AA
COVER
1
14 N210044659AA
COVER
1
15 N210044660AA
BRACKET
1
16 N210002193AA
PLATE
1
17 KXFB06T0A01
BRACKET
1
18 KXFB037VA03
BRACKET
1
19 KXFB02Z5A02
COVER
1
20 N210014166AA
BRACKET
1
21 N210044662AA
BRACKET
1
22 N210002195AC
BRACKET
1
23 N210022546AB
COVER
1
24 KXFB06T2A00
BRACKET
2
25 KXFB07LLA00
BRACKET
1
26 KXFB02WHA01
BRACKET
2
27 KXFB0335A00
PW004A0
1
28 KXFB01CCA00
BRACKET
1
29 KXFB07LCA00
BOLT
4
30 N510018800AA
Eyebolt M24 Steel Unichrome white (Trivalent)
SCREW
6
31 N510018258AA
Cross recessed Truss head machine screw M4X10-4.8 A2S (Trivalent)
SPACER
2
32 N510019583AA ASF-480E
CAP
4
33 KXF09WEAA00 CP-30-BC-24
NUT
4
34 N510017920AA
Hexagon nut Type-3 Best class M30-6H-4T A2J (Trivalent)
WASHER
4
35 N510018488AA
Small round-plain washer 30 10H A2J (Trivalent)
WASHER
1
36 KXF0E08VA00 WSSB30-12-2
NUT
2
37 N510017897AA
Hexagon nut Type-3 Best class M12-6H-4T A2J (Trivalent)
WASHER
1
38 KXF0DZH4A00 WSSB30-16-2
PLUNGER
1
39 KXF08N6AA00 PXK10
BOLT
1
40 KXF0DZG2A00 MSB16-110
SCRAPER
1
41 KXF0E4JMA00 soft hera R10(DDA)
CABLE-BEAR
1
42 KXF0DWSVA00 TKP0450-58BR50X15 link IA.KA
SENSOR
1
43 KXF07B1AA00 PM-K53-C1
SENSOR
1
44 KXF07B0AA00 PM-K53B-C1
SPACER
2
45 N510017089AA CB-304E
BOLT
8
46 N510017555AA
Hexagon socket button head screw M6X12-10.9 A2J (Trivalent)
BOLT
8
47 N510017558AA
Hexagon socket button head screw M6X20-10.9 A2J (Trivalent)
SENSOR
1
48 KXF07JSAA00 PM-L53B-C1
SENSOR
1
49 KXF07JRAA00 PM-L53-C1
M2
--
( KKXFX039AA00-14-1 )
1-B
本
体部
(M)
Main Body(M)
パーツレイアウト
Ki
t
N
o
.
キット
品番
Kit Name
キット名称
KXFX039AA00
ｾｸｼｮﾝNo.
PARTS LAYOUT
Section No.
--
M3
( KKXFX039AA00-14-2 )
