1-E 本 体部 (M) Main Body (M) パーツレイアウト Ki t N o . キット 品番 Kit N am e キット名称 KXFX039AA00 ｾｸｼｮﾝNo. PARTS LAYOUT Section No. - - M9 ( KKXFX039AA00-14-5 )
Ref
No.
Remarks
R
1
Q'ty
1-D
本
体部
(M)
Main Body(M)
ｲﾗｽﾄ
No.
Part No.
品 名品番 数量
R
2
パーツリスト
Kit N
o
.
キット品
番
Kit Name
キット名称
KXFX039AA00
Part Name
備 考
ｾｸｼｮﾝNo.
PARTS LIST
Section No.
R
3
BRACKET
1
1 N210014164AA
COVER
1
2 N210014165AA
REGULATOR
1
3 N510022117AA AR10-M5-Y-X2121-A
REGULATOR
1
4 KXF0DY7RA00 AR20-02-X2111(DDA)
SWITCH
1
5 KXF09F6AA00
A
IS1000-01S-X202
REGULATOR
1
6 KXF09ZLAA00 IR2010-02
GAUGE
3
7 KXF0DY1DA00 G46-4-01-C
JOINT
3
8 KXF02APAA00 KQF04-01
JOINT
1
9 KXF02BPAA00 KQL04-01S
JOINT
1
10 KXF0DWRMA00 KQ2V08-02S
JOINT
6
11 KXF02BTAA00 KQL04-M5
JOINT
1
12 KXF0DY1EA00 KQN10-12
JOINT
1
13 KXF09ERAA00 KQU12-99
JOINT
1
14 KXF0DWGBA00 KQE10-02
BUSH
1
15 N510019584AA (Bu)1/4X1/8
GROMMET
1
16 KXF0DY1HA00 C-30-SG-48A
JOINT
1
17 KXF0DY1MA00 KQ2V06-02S
VALVE
1
18 KXF08UAAA00 VZM550-01-34B
SILENCER
2
19 N510064382AA AN10-01
SPEED-CONTROLLER
1
20 KXF00ZEAA00 AS2211F-01-04S
REGULATOR
1
21 KXF0E0JRA00 AR20K-01-X2107(DDA)
GAUGE
1
22 KXF0DWRJA00 G46-10-01M-C
M8
--
( KKXFX039AA00-14-4 )
1-E
本
体部
(M)
Main Body(M)
パーツレイアウト
Ki
t
N
o
.
キット
品番
Kit Name
キット名称
KXFX039AA00
ｾｸｼｮﾝNo.
PARTS LAYOUT
Section No.
--
M9
( KKXFX039AA00-14-5 )
Ref
No.
Remarks
R
1
Q'ty
1-E
本
体部
(M)
Main Body(M)
ｲﾗｽﾄ
No.
Part No.
品 名品番 数量
R
2
パーツリスト
Kit N
o
.
キット品
番
Kit Name
キット名称
KXFX039AA00
Part Name
備 考
ｾｸｼｮﾝNo.
PARTS LIST
Section No.
R
3
BRACKET
1
1 KXFB0380A00
COUPLING
1
2 KXFB030WA00
BRACKET
1
3 KXFB02Y9B00
HOLDER
1
4 KXFB030UB00
BLOCK
1
5 KXFB035QB00
BUSHING
6
6 KXFB01GBA00
PLATE
1
7 N210028697AA
LINEAR-WAY
2
8 KXF0DZGQA00
SHS20V1UUE.20LV2UUC1E+1420LH-II(01369592G000)
MOTOR
1
9 KXF0DZEPA00
S
MDMA102S2A 130(DDA)
SUPPORT-UNIT
1
10 KXF0DWX8A00 WBK15-01A
BALL-SCREW
1
11 KXF0DZGTA00 W2010-259X-C3T20
SENSOR
2
12 KXF07B3AA00
A
PM-T53B-C1
SENSOR
1
13 KXF07B2AA00
A
PM-T53-C1
BEARING
1
14 KXF00K2AA00 6002ZZ
SPACER
3
15 N510019586AA ASF-555E
SCREW
3
16 N510018378AA
Hexagon socket set screw Cup point M5X20-45H A2J
BOLT
2
17 N510017368AA
Hexagon socket head cap screw M4X45-10.9 A2J (Trivalent)
M10
--
( KKXFX039AA00-14-5 )
