SP60P-M Mechanical 20120628 - 第76页
8-C スキージヘッド Squeeg ee Head パーツレイアウト Ki t N o . キット 品番 Kit N am e キット名称 KXFX039HA00 ｾｸｼｮﾝNo. PARTS LAYOUT Section No. - - M57 ( KKXFX039HA00-07-3 )
Ref
No.
Remarks
R
1
Q'ty
8-B
スキージヘッド
Squeegee Head
ｲﾗｽﾄ
No.
Part No.
品 名品番 数量
R
2
パーツリスト
Kit N
o
.
キット品
番
Kit Name
キット名称
KXFX039HA00
Part Name
備 考
ｾｸｼｮﾝNo.
PARTS LIST
Section No.
R
3
PLATE
2
1 KXFB00J9A00
BRACKET
2
2 KXFB04HQA00
SHAFT
2
3 N210022417AA
HOLDER
2
4 KXFB06L5A00
PLATE
2
5 N210028192AA
PLATE
2
6 KXFB06APA01
HOLDER
2
7 KXFB06L6A00
HOLDER
2
8 KXFB06KYA00
COVER
2
10 KXFB04HRA00
LM-SHAFT
4
12 KXF0DWY6A00 SF16X165(DA KXF0DWY6A00)
COUPLING
2
13 N510001266AA MOL-16-D6XD6
SHAFT
2
18 KXF03GDAA00 SFJ10-55
WASHER
4
19 KXF028TAA00 K16
BEARING
4
20 KXF07EGAA00 UP000
KNOB
2
21 KXF09Y4AA00 KCF-24XM6-BK
BOLT
2
22 KXF0DXJDA00 HFMB6-40
PLUNGER
2
23 KXF09WSAA00 BSZ6
NUT
2
24 N510017869AA
Hexagon nut Type-3 Best class M6-6H-4T A2J (Trivalent)
PIN
4
25 KXF02XVAA00 MS3-10
SCREW
2
26 N510018453AA
Hexagon socket set screw Flat point M6X6-45H A2J (Trivalent)
BOLT
4
27 KXF0CK8AA00 Hexagon head bolt M4X45L(SUS)
SCREW
2
29 N510018452AA
Hexagon socket set screw Flat point M6X25-45H A2J (Trivalent)
PLATE
2
30 KXFB06MHA00
CABLE
1
31 N610033688AB JC22E 5K 1%
CABLE
1
32 N610033689AB JC22E 5K 1%
M56
--
( KKXFX039HA00-07-2 )
8-C
スキージヘッド
Squeegee Head
パーツレイアウト
Ki
t
N
o
.
キット
品番
Kit Name
キット名称
KXFX039HA00
ｾｸｼｮﾝNo.
PARTS LAYOUT
Section No.
--
M57
( KKXFX039HA00-07-3 )
Ref
No.
Remarks
R
1
Q'ty
8-C
スキージヘッド
Squeegee Head
ｲﾗｽﾄ
No.
Part No.
品 名品番 数量
R
2
パーツリスト
Kit N
o
.
キット品
番
Kit Name
キット名称
KXFX039HA00
Part Name
備 考
ｾｸｼｮﾝNo.
PARTS LIST
Section No.
R
3
COLLAR
2
1 KXFB06KZA00
BRACKET
1
2 N210024117AA
COVER
1
3 N210024116AB
COVER
1
4 N210014689AA
VALVE
4
5 KXF0DWXGA00 B5132-MOQ-M5-FL273676-DC24V(DDA)
JOINT
3
6 KXF02TAAA00 M-5HL-6
BUTTON
2
7 KXF0A79AA00 C-33
SCREW
4
8 N510018435AA
Hexagon socket set screw Flat point M4X4-45H A2S
SCREW
4
9 N510018252AA
Cross recessed Truss head machine screw M3X5-4.8 A2S (Trivalent)
JOINT
3
10 KXF02TCAA00 M-5J
JOINT
1
11 KXF02T4AA00 M-5AU-6
JOINT
2
12 KXF02TLAA00 M-5UT
SCREW
2
14 N510018279AA
Cross recessed Truss head machine screw M4X6-4.8 A2J (Trivalent)
REGULATOR
1
16 KXF0DWYEA00 EV2500-108-C11E2B4-FL280525(DA KXF0DWYEA00)
JOINT
7
17 KXF029LAA00 KJL06-M5
M58
--
( KKXFX039HA00-07-3 )
