CS DWG NO. OF REV DESCRIPTION SHEET DESCRIPTION NO. PART NO. PART INFORMATION AND IS NOT TO BE USED OR DO NOT SCALE REPRODUCED WITH OUT PERMISSION OF THIS DRAWING CON TAINS PROPRIETARY ALL CAPACITORS ARE IN µ F ALL RESIS…
CS DWG NO.
OF
REV
DESCRIPTION
SHEET
DESCRIPTION
NO.
PART
NO.
PART
INFORMATION AND IS NOT TO BE USED OR
DO NOT SCALE
REPRODUCED WITHOUT PERMISSION OF
THIS DRAWING CONTAINS PROPRIETARY
ALL CAPACITORS ARE IN µ F
ALL RESISTORS ARE IN Ω
ALL DIM ARE IN mm
UNLESS OTHERWISE SPECIFIED
A S M
DWG REV
(MI)UPF, PROGRAMMABLE TRACK
01-E18704
CS-01-E18704
11
FROM: 01-E18704_G_2015.03.17
G1
G
ASM Pacific Technology
ASM CUSTOMER SERVICE DRAWINGASM CUSTOMER SERVICE DRAWING
ASM CUSTOMER SERVICE DRAWINGASM CUSTOMER SERVICE DRAWINGASM CUSTOMER SERVICE DRAWINGASM CUSTOMER SERVICE DRAWING ASM CUSTOMER SERVICE DRAWINGASM CUSTOMER SERVICE DRAWINGASM CUSTOMER SERVICE DRAWINGASM CUSTOMER SERVICE DRAWING
ASM CUSTOMER SERVICE DRAWINGASM CUSTOMER SERVICE DRAWING
ASM CUSTOMER SERVICE DRAWINGASM CUSTOMER SERVICE DRAWINGASM CUSTOMER SERVICE DRAWINGASM CUSTOMER SERVICE DRAWING ASM CUSTOMER SERVICE DRAWINGASM CUSTOMER SERVICE DRAWINGASM CUSTOMER SERVICE DRAWINGASM CUSTOMER SERVICE DRAWING
ASM CUSTOMER SERVICE DRAWINGASM CUSTOMER SERVICE DRAWING ASM CUSTOMER SERVICE DRAWINGASM CUSTOMER SERVICE DRAWING
21 3 4 5 6 7 8
8765431 2
B
A
C
D
E
F F
E
D
C
A
B
ITEM PART NO. DESCRIPTION QTY.
1 00-99996 MAGNET DISC DIA6.35-0.254 X 2.54THK 3
2 01-E34232 (MI)G2 UPF,TRACK DRIVERING L-SCREW ASSY. 1
3 02-E01668 (MI) STACK LOADER CLOSE SENSOR 1
4 02-E01670 (MI) STACK LOADER OPEN LIMIT SENSOR 1
5 02-E23905 (MI) STACK LOADER DRIVING MOTOR 1
6 19-00006 RETAINING RING FOR SHAFT 15MM STWS15 2
7 24-00051 FLANGED BEARING ID8XOD22XW7 2
8 24-01028 LINEAR BUSH LM8LUU 2
9 24-13001 LINEAR BUSHING 8X15X24 2
10 24-35002 SELF ALIGNING BALL BEARING 8X22X7 1
11 26-53745 (WH) UCMV, MTR PULLEY C-CLAMP 1
12 26-E53971 C-CLAMP ID11 1
13 26-F74378 (MI) UPF, ROD FOR TRACK WIDTH ADJ. 2
14 26-F74379 (MI) UPF, FRONT TRACK 1
15 26-F74380 (MI) UPF, REAR TRACK 1
16 26-F74387 (MI) UPF, BUSH COVER A 2
17 26-F74388 (MI) UPF, BUSH COVER B 2
18 26-F74389 (MI) UPF, PULLEY 32T 1
19 26-F74390 (MI) UPF, PULLEY 22T 1
20 26-F74409 (MI) UPF, STOPPER BKT FOR REAR TRACK 1
21 26-F74411 (MI) UPF, RUBBER PAD FOR FRONT TRACK 2
22 26-F74412 (MI) UPF, REAR STOPPER PAD FOR TRACK 1
23 26-F74413 (MI) UPF, FRONT STOPPER PAD FOR TRACK 1
24 53-00790 REFLECTIVE SENSING FIBER E32-D36P1 1
25 73-00286 TIMING BELT B135MXL6.4 1
26 S01-E30656 (MI) UPF, FRONT TRACK STOPPER 1
20
2
6
7
8
9
10
11
12
13
14
15
18
19
22
23
25
3
4
17
16
5
26
21
1
Assembly View
24
NOTE:53-00790 is included of 02-E31126 in the assembly.
A
DETAIL A
1-24
(MI83)G2 INPUT COMBO MAGAZINE ELEVATOR
CS DWG NO.
OF
REV
DESCRIPTION
SHEET
DESCRIPTION
NO.
PART
NO.
PART
INFORMATION AND IS NOT TO BE USED OR
DO NOT SCALE
REPRODUCED WITHOUT PERMISSION OF
THIS DRAWING CONTAINS PROPRIETARY
ALL CAPACITORS ARE IN µ F
ALL RESISTORS ARE IN Ω
ALL DIM ARE IN mm
UNLESS OTHERWISE SPECIFIED
A S M
DWG REV
(MI)UPF, BUMPER
01-E18705
CS-01-E18705
11
FROM: 01-E18705_B_2012.10.29
B3
B
ASM Pacific Technology
ASM CUSTOMER SERVICE DRAWINGASM CUSTOMER SERVICE DRAWING
ASM CUSTOMER SERVICE DRAWINGASM CUSTOMER SERVICE DRAWINGASM CUSTOMER SERVICE DRAWINGASM CUSTOMER SERVICE DRAWING ASM CUSTOMER SERVICE DRAWINGASM CUSTOMER SERVICE DRAWINGASM CUSTOMER SERVICE DRAWINGASM CUSTOMER SERVICE DRAWING
ASM CUSTOMER SERVICE DRAWINGASM CUSTOMER SERVICE DRAWING
ASM CUSTOMER SERVICE DRAWINGASM CUSTOMER SERVICE DRAWINGASM CUSTOMER SERVICE DRAWINGASM CUSTOMER SERVICE DRAWING ASM CUSTOMER SERVICE DRAWINGASM CUSTOMER SERVICE DRAWINGASM CUSTOMER SERVICE DRAWINGASM CUSTOMER SERVICE DRAWING
ASM CUSTOMER SERVICE DRAWINGASM CUSTOMER SERVICE DRAWING ASM CUSTOMER SERVICE DRAWINGASM CUSTOMER SERVICE DRAWING
21 3 4 5 6 7 8
8765431 2
B
A
C
D
E
F F
E
D
C
A
B
ITEM PART NO. DESCRIPTION QTY.
1 02-E04439 (MI) MAGAZINE BUMPER SENSOR 1
2 26-F74403 (MI) UPF, BUMPER BUSHING 5
3 26-F74417 (MI) UPF, BUMPER BUSHING GUIDE 2
4 26-F74418 (MI) UPF, BUMPER UP/DOWN GUIDE 3
5 26-F79791 (MI) STOPPING SCREW 1
6 75-00012 COMPRESSION SPRING WF4-15 5
Assembly View
2
3
5
6
1
4
1-25
(MI83)G2 INPUT COMBO MAGAZINE ELEVATOR
CS DWG NO.
OF
REV
DESCRIPTION
SHEET
DESCRIPTION
NO.
PART
NO.
PART
INFORMATION AND IS NOT TO BE USED OR
DO NOT SCALE
REPRODUCED WITHOUT PERMISSION OF
THIS DRAWING CONTAINS PROPRIETARY
ALL CAPACITORS ARE IN µ F
ALL RESISTORS ARE IN Ω
ALL DIM ARE IN mm
UNLESS OTHERWISE SPECIFIED
A S M
DWG REV
(MI)UPF, MAG. EXISTING SENSOR ASSY.
S01-E47076
CS-S01-E47076
11
FROM: S01-E47076_A_2015.06.03
A1
A
ASM Pacific Technology
ASM CUSTOMER SERVICE DRAWINGASM CUSTOMER SERVICE DRAWING
ASM CUSTOMER SERVICE DRAWINGASM CUSTOMER SERVICE DRAWINGASM CUSTOMER SERVICE DRAWINGASM CUSTOMER SERVICE DRAWING ASM CUSTOMER SERVICE DRAWINGASM CUSTOMER SERVICE DRAWINGASM CUSTOMER SERVICE DRAWINGASM CUSTOMER SERVICE DRAWING
ASM CUSTOMER SERVICE DRAWINGASM CUSTOMER SERVICE DRAWING
ASM CUSTOMER SERVICE DRAWINGASM CUSTOMER SERVICE DRAWINGASM CUSTOMER SERVICE DRAWINGASM CUSTOMER SERVICE DRAWING ASM CUSTOMER SERVICE DRAWINGASM CUSTOMER SERVICE DRAWINGASM CUSTOMER SERVICE DRAWINGASM CUSTOMER SERVICE DRAWING
ASM CUSTOMER SERVICE DRAWINGASM CUSTOMER SERVICE DRAWING ASM CUSTOMER SERVICE DRAWINGASM CUSTOMER SERVICE DRAWING
21 3 4 5 6 7 8
8765431 2
B
A
C
D
E
F F
E
D
C
A
B
ITEM PART NO. DESCRIPTION QTY.
1 02-E01671 (MI) UPPER PLATFORM MAG BUFFER FULL SNR 1
2 26-F73858 (MI) SPACER FOR MAG EXIST SNR 2
3 75-00254 COMPRESSION SPRING SSC-WR1015-2 1
4 S26-H02080 (MI) MAG EXIST SNR SPRING HOLDER 1
Assembly View
4
2
1
3
1-26
(MI83)G2 INPUT COMBO MAGAZINE ELEVATOR
