3.S軸 S axis(CLFS)

GP-551E PARTS LIST ver03

3-2

3.S軸(CLFS)

3.S axis(CLFS)

番号図番 & ｺｰﾄﾞ番号個数品名規格備考

No. Drg.No. & Code No. QTY Description Rating Remarks

1CLFS0400 1 BKT, SLIDE BKT ｽﾗｲﾄﾞ

2CLFS0022 1 BKT BKT

3CLFS0031 1 PLATE ﾌﾟﾚｰﾄ

4CLFS0043 1 DOG ﾄﾞｯｸﾞ

5CLFS0051 2 BKT, SENSOR BKT ｾﾝｻ

6CLFS0062 1 BKT BKT

7CLFS0070 1 BLOCK, STOPPER ﾌﾞﾛｯｸｽﾄｯﾊﾟ

8CLFS0081 1 BALL SCREW ﾎﾞｰﾙﾈｼﾞ

9CLFS0090 1 BKT, BALL SCREW BKT ﾎﾞｰﾙﾈｼﾞ

10CLFS0102 1 HOLDER, BEARING ﾎﾙﾀﾞﾍﾞｱﾘﾝｸﾞ

11CLFS0120 1 BKT BKT

12CLFS0133 1 COVER ｶﾊﾞｰ

13CLFS0140 2 BOLT, STUD ﾎﾞﾙﾄｽﾀｯﾄﾞ

14CLFS0160 1 BLOCK ﾌﾞﾛｯｸ

15CLFS0171 1 GUIDE, RAIL ｶﾞｲﾄﾞﾚｰﾙ

16CLFS0181 1 GUIDE, RAIL ｶﾞｲﾄﾞﾚｰﾙ

17CLFS0223 1 CASE, BEARING ｹｰｽﾍﾞｱﾘﾝｸﾞ

18CLFS0231 1 HOLDER, BEARING ﾎﾙﾀﾞﾍﾞｱﾘﾝｸﾞ

19CLFS0240 1 BKT BKT

20CLFS0250 1 STOPPER ｽﾄｯﾊﾟ

21CLFS0261 1 BKT, SENSOR BKT ｾﾝｻ

22CLFS0271 1 BKT, SENSOR BKT ｾﾝｻ

23CLFS0390 1 BKT BKT

24CLFS0290 1 BLOCK ﾌﾞﾛｯｸ

25CLFS0380 1 HOLDER 受け

26CLFS0310 1 STOPPER ｽﾄｯﾊﾟ

27CLFS0320 1 MANIFOLD ﾏﾆﾎｰﾙﾄﾞ

28CLFS0330 1 COLLAR ｶﾗｰ

29CLFS0340 1 PIN ﾋﾟﾝ

30CLFS0360 1 BKT, COVER BKT ｶﾊﾞｰ

31CLFS0371 1 BKT BKT

32BSFS0280 1 BKT, ADJUSTING BKT 調整

33BSGC1440 1 BKT BKT

34TFS4100 1 COLLAR ｶﾗｰ

35TFS4110 1 COLLAR ｶﾗｰ

36TFS4210 1 COLLAR ｶﾗｰ

37TFS4270 1 PULLEY, TIMING ﾌﾟｰﾘﾀｲﾐﾝｸﾞ

38TFS4340 1 PULLEY, TIMING ﾌﾟｰﾘﾀｲﾐﾝｸﾞ

39TFS4430 3 COLLAR ｶﾗｰ

40TFS4440 3 STOPPER ｽﾄｯﾊﾟ

41TFS4760 1 PLATE ﾌﾟﾚｰﾄ

42BSFS0310 1 BOLT ﾎﾞﾙﾄ

43TFS4481 1 BKT, RETAINER BKT 押え

44H4219G 1 BEARING ﾍﾞｱﾘﾝｸﾞ 7202ADBC8P5

3.S軸 S axis(CLFS)

GP-551E PARTS LIST ver03

3-3

3.S軸(CLFS)

3.S axis(CLFS)

番号図番 & ｺｰﾄﾞ番号個数品名規格備考

No. Drg.No. & Code No. QTY Description Rating Remarks

45H4257A 1 BEARING ﾍﾞｱﾘﾝｸﾞ 6202ZZ

46H4514A 1

BELT, TIMING

ﾍﾞﾙﾄﾀｲﾐﾝｸﾞ 800SP8M15

47S4046M 2

SENSOR, PHOTO

ｾﾝｻﾌｫﾄ EE-SPX404-W2A

48S4046E 2

SENSOR, PHOTO

ｾﾝｻﾌｫﾄ EE-SPX302-W2A

49H3076T 1

BUSHING

ﾌﾞｯｼｭ ETP-K-12

50H30760 1

BUSHING

ﾌﾞｯｼｭ ETP-K-16

51S1034A 1

CIR-CLIP

ｻｰｸﾘｯﾌﾟ STW15

52N1025N 1

NUT, LOCK

ﾅｯﾄﾛｯｸ ZM015

54H4232S 2

BEARING

ﾍﾞｱﾘﾝｸﾞ HR32005XJ

55N1020T 1

NUT, FINE U

ﾅｯﾄﾌｧｲﾝU FU05SC

56N1108T 1

NUT, DOMED CAP

ﾅｯﾄ六角袋

M16ﾕﾆｸﾛﾒｯｷﾂｷ

57S30963 1

SENSOR, PROXIMITY

ｾﾝｻ近接 E2E-X5E1-M1

58K5028R 1 CONNECTOR ｺﾈｸﾀ XS2F-D422-DC0-A

59S3090D 1

SENSOR, PROXIMITY

ｾﾝｻｷﾝｾﾂ E2E-C1C1

60S21213 1 CYLINDER, AIR ｼﾘﾝﾀﾞｴｱｰ CQ2A40-15D

61Y3050A 2

UNION, ELBOW

ﾕﾆｵﾝｴﾙﾎﾞ KQL06-01S

62H30765 1

BUSHING

ﾌﾞｯｼｭ SPBZ30-15

63K4146N 1 FLEXIBLE TRACK ｹｰﾌﾞﾙﾍﾞｱ 25.4-055-14-20A

64Y3056A 1

UNION, HALF

ﾕﾆｵﾝﾊｰﾌ KQH06-M5

65Y3049A 2

UNION, ELBOW

ﾕﾆｵﾝｴﾙﾎﾞ KQL06-M5

66Y3050E 1

UNION, ELBOW

ﾕﾆｵﾝｴﾙﾎﾞ KQL06-M6

67A5151A 6

O RING

Oﾘﾝｸﾞ P5

68K5340T 2

CONTROLLER, SPEED

ｺﾝﾄﾛｰﾗｽﾋﾟｰﾄﾞ AS2001F-06

69H5137C 1 BOLT, STOPPER ﾎﾞﾙﾄｽﾄｯﾊﾟ SGPB6-12

70H3154K 1 PLUNGER ﾌﾟﾗﾝｼﾞｬ BSJ10

71Y3059H 12

UNION, HALF

ﾕﾆｵﾝﾊｰﾌ KQS06-01S

72S4046H 1

SENSOR, PHOTO

ｾﾝｻﾌｫﾄ EE-SPX304-W2A

73W1021A

WASHER, LOCK

ﾜｯｼｬｽﾌﾟﾘﾝｸﾞ 3M/M

74W1022A

WASHER, LOCK

ﾜｯｼｬｽﾌﾟﾘﾝｸﾞ 4M/M

75W1023A

WASHER, LOCK

ﾜｯｼｬｽﾌﾟﾘﾝｸﾞ 5M/M

76W1024A

WASHER, LOCK

ﾜｯｼｬｽﾌﾟﾘﾝｸﾞ 6M/M

77W1025A

WASHER, LOCK

ﾜｯｼｬｽﾌﾟﾘﾝｸﾞ 8M/M

78W1029A

WASHER, LOCK

ﾜｯｼｬｽﾌﾟﾘﾝｸﾞ 16M/M

79W1043A

WASHER, FLAT

ﾜｯｼｬ平

4W-4

80W1045A WASHER, FLAT ﾜｯｼｬ平 4W-6

81W1046A

WASHER, FLAT

ﾜｯｼｬ平

4W-8

82W1049A

WASHER, FLAT

ﾜｯｼｬ平

4W-16

83W1012A

WASHER, CONICAL

ﾜｯｼｬ皿

M-5-L

84W1013A

WASHER, CONICAL

ﾜｯｼｬ皿

M-6-H

85W1014A

WASHER, CONICAL

ﾜｯｼｬ皿

M-8-H

86.

NUT, HEX

ﾅｯﾄ六角

M5 P=0.8

87N4021A

SCREW, HEX SOCKET SET

ﾈｼﾞ六角穴止め

M3X6L

88K5208A

SCREW, TRUSS

ｺﾈｼﾞﾄﾗｽ M4X6L

89H5308A

BOLT, HEX SOCKET

ﾎﾞﾙﾄ六角穴

M5X45L

3.S軸 S axis(CLFS)

GP-551E PARTS LIST ver03

3-4

3.S軸(CLFS)

3.S axis(CLFS)

番号図番 & ｺｰﾄﾞ番号個数品名規格備考

No. Drg.No. & Code No. QTY Description Rating Remarks

90H5273A

BOLT, HEX SOCKET

ﾎﾞﾙﾄ六角穴

M3X5L

91H5275A

BOLT, HEX SOCKET

ﾎﾞﾙﾄ六角穴

M3X8L

92H5287A

BOLT, HEX SOCKET

ﾎﾞﾙﾄ六角穴

M4X8L

93H5288A

BOLT, HEX SOCKET

ﾎﾞﾙﾄ六角穴

M4X10L

94H5290A

BOLT, HEX SOCKET

ﾎﾞﾙﾄ六角穴

M4X15L

95H5297A

BOLT, HEX SOCKET

ﾎﾞﾙﾄ六角穴

M5X8L

96H5299A

BOLT, HEX SOCKET

ﾎﾞﾙﾄ六角穴

M5X12L

97H5300A

BOLT, HEX SOCKET

ﾎﾞﾙﾄ六角穴

M5X15L

98H5301A

BOLT, HEX SOCKET

ﾎﾞﾙﾄ六角穴

M5X18L

99H5304A

BOLT, HEX SOCKET

ﾎﾞﾙﾄ六角穴

M5X25L

100H5320A

BOLT, HEX SOCKET

ﾎﾞﾙﾄ六角穴

M6X10L

101H5321A

BOLT, HEX SOCKET

ﾎﾞﾙﾄ六角穴

M6X12L

102H5322A

BOLT, HEX SOCKET

ﾎﾞﾙﾄ六角穴

M6X15L

103H5323A

BOLT, HEX SOCKET

ﾎﾞﾙﾄ六角穴

M6X18L

104H5326T

BOLT, HEX SOCKET

ﾎﾞﾙﾄ六角穴

M6X30L

105H5329A

BOLT, HEX SOCKET

ﾎﾞﾙﾄ六角穴

M6X35L

106H5340A

BOLT, HEX SOCKET

ﾎﾞﾙﾄ六角穴

M8X15L

107H5341A

BOLT, HEX SOCKET

ﾎﾞﾙﾄ六角穴

M8X20L

108H5342A

BOLT, HEX SOCKET

ﾎﾞﾙﾄ六角穴

M8X25L

109H5344A

BOLT, HEX SOCKET

ﾎﾞﾙﾄ六角穴

M8X35L

110H5345A

BOLT, HEX SOCKET

ﾎﾞﾙﾄ六角穴

M8X40L

111H5346A

BOLT, HEX SOCKET

ﾎﾞﾙﾄ六角穴

M8X45L

112H5349A

BOLT, HEX SOCKET

ﾎﾞﾙﾄ六角穴

M8X60L

113. 1 MOTOR, SERVO ﾓｰﾀACｻｰﾎﾞ SGM-08A312 ･
