1 6 . 2 . クリーナ下 L o w e r c l e a n e r ( C L F C ) GP-551E P ARTS LIST ver03 1 6 - 7 1 6 . 2 . クリーナ下( C L F C ) 1 6 . 2 . L o w e r c l e a n e r ( C L F C ) 番号 図番 & ｺ ｰ ﾄ ﾞ 番号 個数 品名 規格 備考 N o . D r g . N o . &…
16.2.クリーナ下 Lower cleaner(CLFC)
GP-551E PARTS LIST ver03
16-6
16.2.クリーナ下(CLFC)
16.2.Lower cleaner(CLFC)
番号 図番 & ｺｰﾄﾞ番号 個数 品名 規格 備考
No. Drg.No. & Code No. QTY Description Rating Remarks
75BSFC6781 2 SCREW ﾈｼﾞ TYPE5000
78MCA0012 3 WHEEL, RATCHET ﾎｲｰﾙ ﾗﾁｪｯﾄ
79MCA0152 1 SPACER ｽﾍﾟｰｻ
80MCA0280 1 SPRING ｽﾌﾟﾘﾝｸﾞ
81S2100Y 1
CYLINDER, AIR
ｼﾘﾝﾀﾞ ｴｱｰ CDQSB25-22DM-F9NL
82Y3049Z 1
UNION, ELBOW
ﾕﾆｵﾝ ｴﾙﾎﾞ KQL04-M5
83H2044H 1
PIN, SPRING
ﾋﾟﾝ ｽﾌﾟﾘﾝｸﾞ 2.5ﾟX6
84H2041A 3
PIN, SPRING
ﾋﾟﾝ ｽﾌﾟﾘﾝｸﾞ 2ﾟX8
85K5337T 1
CONTROLLER, SPEED
ｺﾝﾄﾛｰﾗ ｽﾋﾟｰﾄﾞ AS1211F-M5-04
88A5151H 4 O RING O ﾘﾝｸﾞ P-4 3ｼｭ
90T2061E 1 TUBE ﾁｭｰﾌﾞ ﾅﾌﾛﾝPTE ﾁｭｰﾌﾞ2X3
93Y3049E 1
UNION, ELBOW
ﾕﾆｵﾝ ｴﾙﾎﾞ KJL04-M5
94S2100E 1 CYLINDER, AIR ｼﾘﾝﾀﾞ ｴｱｰ CDM2RA32-40-H7A1L
95S1022A 30
CIR-CLIP
ｻｰｸﾘｯﾌﾟ ST-EW-4
96H4332H 4
BEARING, DRY
ﾍﾞｱﾘﾝｸﾞ ﾄﾞﾗｲ MB1012DU
97K5030T 4 CONNECTOR ｺﾈｸﾀ PN-1/8-PT1/8-BS
106S30200 4
SPRING, COIL
ｽﾌﾟﾘﾝｸﾞ ｺｲﾙ WM5-15
115N1013Y 2 NUT, JOINT ﾅｯﾄ ｼﾞｮｲﾝﾄ KNT-6
116S5025Z 1
SOCKET
ｿｹｯﾄ CPSE3-4
117H31265 1 PLUG ﾌﾟﾗｸﾞ CPPE3H-M5
118K5342A 2
CONTROLLER, SPEED
ｺﾝﾄﾛｰﾗ ｽﾋﾟｰﾄﾞ AS2201F-01-06S
120Y30408 1
UNION
ﾕﾆｵﾝ KQT04-06
121W1021A
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 3M/M
122W1022A
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 4M/M
123W1023A
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 5M/M
125W1042A
WASHER, FLAT
ﾜｯｼｬ 平
4W-3
126W1043A
WASHER, FLAT
ﾜｯｼｬ 平
4W-4
127W1044A
WASHER, FLAT
ﾜｯｼｬ 平
4W-5
130N1081A
NUT, HEX
ﾅｯﾄ 六角
M4-L
131N1084A
NUT, HEX
ﾅｯﾄ 六角
M5-L
132W1014A WASHER, CONICAL ﾜｯｼｬ 皿 M8-H
133N1076A
NUT, HEX
ﾅｯﾄ 六角
M3P=0.5
134N1080A
NUT, HEX
ﾅｯﾄ 六角
M4P=0.7
135N1082A
NUT, HEX
ﾅｯﾄ 六角
M5P=0.8
136N1085A
NUT, HEX
ﾅｯﾄ 六角
M6P=1.0
137K5255T
SCREW, HEX SOCKET BUTTON
小ﾈｼﾞ六角穴ﾎﾞﾀﾝ M3X6L
144N4032A
SCREW, HEX SOCKET SET
ﾈｼﾞ 六角穴止め
M4X12L
145N4050A
SCREW, HEX SOCKET SET
ﾈｼﾞ 六角穴止め
M6X20L
146H5172T
BOLT, HEX
ﾎﾞﾙﾄ 六角
M4X25L
148H5274A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M3X6L
149H5275A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M3X8L
150H5276A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M3X10L
155H5288A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M4X10L
156H5289A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M4X12L
16.2.クリーナ下 Lower cleaner(CLFC)
GP-551E PARTS LIST ver03
16-7
16.2.クリーナ下(CLFC)
16.2.Lower cleaner(CLFC)
番号 図番 & ｺｰﾄﾞ番号 個数 品名 規格 備考
No. Drg.No. & Code No. QTY Description Rating Remarks
159H5298A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M5X10L
160H5299A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M5X12L
161H5300A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M5X15L
164H5332T
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M6X55L
167H5346A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M8X45L
168CLFC1891 1 BKT, SENSOR BKT ｾﾝｻ
169S4141G 1 SW, PHOTOELECTRIC SW 光電 DL-S5RWG-TFL
170. SCREW, S/R PAN 小ﾈｼﾞ十穴鍋 M3X15L
171W1040A
WASHER, FLAT
ﾜｯｼｬ 平
1W-3 ･
17.メインコンベアローラ搬送 Roller guided main conveyor(CLQC)
GP-551E PARTS LIST ver03
17-1
17.メインコンベアローラ搬送(オプション)(CLQC)
17.Roller guided main conveyor(Option)(CLQC)
x4
3121
6
5
3
3
3
3
6
5
6
6
6
5
5
5
4
4
1
2
5
6
6
5
5
5
5
6
6
6
6
3
3
3
3
4
4
