2 2 . エアー配管図 5 P n e u m a t i c c i r c u i t d i a g r a m 5 ( C L P I ) GP-551E P ARTS LIST ver03 2 2 - 3 2 2 . エアー配管図 5 ( C L P I ) 2 2 . P n e u m a t i c c i r c u i t d i a g r a m 5 ( C L P I ) 番号 図番 & ｺ ｰ ﾄ …
22.エアー配管図 5 Pneumatic circuit diagram 5(CLPI)
GP-551E PARTS LIST ver03
22-2
22.エアー配管図 5(CLPI)
22.Pneumatic circuit diagram 5(CLPI)
番号 図番 & ｺｰﾄﾞ番号 個数 品名 規格 備考
No. Drg.No. & Code No. QTY Description Rating Remarks
1H1331A 3 VALVE ﾊﾞﾙﾌﾞ VQ1101-5
2H1332A 6 VALVE ﾊﾞﾙﾌﾞ VQ1201-5
7. 1 MANIFOLD ﾏﾆﾎｰﾙﾄﾞ VV5Q11-09-X548
17BSFC0821 1 SYRINGE ｼﾘﾝｼﾞ
18H1050T 1 VALVE, CHECK ﾊﾞﾙﾌﾞ ﾁｪｯｸ
20H1130H 2
VALVE, SOL
ﾊﾞﾙﾌﾞ SOL VXD2130-02-5DZ-B
22H1051F 1 VALVE, CHECK ﾊﾞﾙﾌﾞ ﾁｪｯｸ CVF01-01-BF-1.0
23H1033T 1
VALVE, THREE-WAY
ﾊﾞﾙﾌﾞ 三方
USG3-6-2-B-DC24V
46S21213 2 CYLINDER, AIR ｼﾘﾝﾀﾞ ｴｱｰ CQ2A40-15D
47S21005 1 CYLINDER, AIR ｼﾘﾝﾀﾞ ｴｱｰ CDQSWB25-10DC-F9NL
48CLFC0430 1 CYLINDER, AIR ｼﾘﾝﾀﾞ ｴｱｰ
49S2100E 1 CYLINDER, AIR ｼﾘﾝﾀﾞ ｴｱｰ CDM2RA32-40-H7A1L
50S2100Y 1
CYLINDER, AIR
ｼﾘﾝﾀﾞ ｴｱｰ CDQSB25-22DM-F9NL
51S2118T 1 CYLINDER, AIR ｼﾘﾝﾀﾞ ｴｱｰ CJPB15-30D
52S2107W 1 CYLINDER, AIR ｼﾘﾝﾀﾞ ｴｱｰ CDQ2B32-22DM-F9NL
53CLFC0091 1 CYLINDER, AIR ｼﾘﾝﾀﾞ ｴｱｰ
60K5337H 2
CONTROLLER, SPEED
ｺﾝﾄﾛｰﾗ ｽﾋﾟｰﾄﾞ AS1201F-M5-04
61K5337M 2
CONTROLLER, SPEED
ｺﾝﾄﾛｰﾗ ｽﾋﾟｰﾄﾞ AS1201F-M5-06
62K5337T 1
CONTROLLER, SPEED
ｺﾝﾄﾛｰﾗ ｽﾋﾟｰﾄﾞ AS1211F-M5-04
63K5344H 1 CONTROLLER, SPEED ｺﾝﾄﾛｰﾗ ｽﾋﾟｰﾄﾞ AS2211F-01-04S
65K5340T 4
CONTROLLER, SPEED
ｺﾝﾄﾛｰﾗ ｽﾋﾟｰﾄﾞ AS2001F-06
66K5342A 3
CONTROLLER, SPEED
ｺﾝﾄﾛｰﾗ ｽﾋﾟｰﾄﾞ AS2201F-01-06S
69K5335Z 1
CONTROLLER, SPEED
ｺﾝﾄﾛｰﾗ ｽﾋﾟｰﾄﾞ AS1001F-06
79Y3061B 1 UNION, HALF ﾕﾆｵﾝ ﾊｰﾌ KJS04-M3
81Y3061D 3 UNION, HALF ﾕﾆｵﾝ ﾊｰﾌ KJS04-M5
83Y3061T 2
UNION, HALF
ﾕﾆｵﾝ ﾊｰﾌ KJS06-M5
93Y3049D 1 UNION, ELBOW ﾕﾆｵﾝ ｴﾙﾎﾞ KJL04-M3
94Y3049E 3 UNION, ELBOW ﾕﾆｵﾝ ｴﾙﾎﾞ KJL04-M5
95Y3049C 1
UNION, ELBOW
ﾕﾆｵﾝ ｴﾙﾎﾞ KJL04-01S
96Y3049H 4
UNION, ELBOW
ﾕﾆｵﾝ ｴﾙﾎﾞ KJL06-M5
97Y3049T 1
UNION, ELBOW
ﾕﾆｵﾝ ｴﾙﾎﾞ KJL06-01S
98Y3049Z 1
UNION, ELBOW
ﾕﾆｵﾝ ｴﾙﾎﾞ KQL04-M5
102CLPI0090 1 VALVE UNIT ﾊﾞﾙﾌﾞ ﾕﾆｯﾄ
104Y3049A 1
UNION, ELBOW
ﾕﾆｵﾝ ｴﾙﾎﾞ KQL06-M5
105Y3050A 4
UNION, ELBOW
ﾕﾆｵﾝ ｴﾙﾎﾞ KQL06-01S
106Y3052A 2
UNION, ELBOW
ﾕﾆｵﾝ ｴﾙﾎﾞ KQL06-02S
107Y3054A 2
UNION, ELBOW
ﾕﾆｵﾝ ｴﾙﾎﾞ KQL08-02S
120CLFC0351 1 NOZZLE ﾉｽﾞﾙ
121CLFC1361 1 NOZZLE ﾉｽﾞﾙ
122CLFC1340 1 PLATE, SIDE ﾌﾟﾚｰﾄ ｻｲﾄﾞ
123CLFC1351 1 PLATE, SIDE ﾌﾟﾚｰﾄ ｻｲﾄﾞ
124CLFC0320 1 MANIFOLD ﾏﾆﾎｰﾙﾄﾞ
126BSFC4100 1 TANK ﾀﾝｸ
131Y3034F 1
UNION
ﾕﾆｵﾝ KJU04-00
22.エアー配管図 5 Pneumatic circuit diagram 5(CLPI)
GP-551E PARTS LIST ver03
22-3
22.エアー配管図 5(CLPI)
22.Pneumatic circuit diagram 5(CLPI)
番号 図番 & ｺｰﾄﾞ番号 個数 品名 規格 備考
No. Drg.No. & Code No. QTY Description Rating Remarks
137Y30408 1
UNION
ﾕﾆｵﾝ KQT04-06
143Y3040X 1
UNION
ﾕﾆｵﾝ KQR04-08
156S5025Z 1
SOCKET
ｿｹｯﾄ CPSE3-4
157H31265 1 PLUG ﾌﾟﾗｸﾞ CPPE3H-M5
158Y3032T 2
UNION
ﾕﾆｵﾝ PTU-1/8-BS
159K5030T 4
CONNECTOR
ｺﾈｸﾀ PN-1/8-PT1/8-BS
160A40305 4
ELBOW
ｴﾙﾎﾞ PL-1/8-PT1/8-BS ･
23.エアー機器 1 Air device 1(CLPI)
GP-551E PARTS LIST ver03
23-1
23.エアー機器 1(CLPI)
23.Air device 1(CLPI)
x7.5
C
For hermetic squeegee
密閉スキ−ジ
3
31
34
12
13
13
12
11
11
34
30
34
30
7
29
33
10
9
8
29
33
29
33
5
24,28
25,27
26,28
15
14
15
16
4
29
33
6
29
33
32
35
1
31
34
20
20
36
2
C
