序号 料号 部品名称 数量 规格 备注
010 NB16817023AA PINBOARD 5
011 NB16817008AA BLOCK 2
012 NB16817009AA BRACKET 2
013 NB168P0947AA PIN 2
014 NB16817010AA BRACKET 40
015 NB16817012AA PIN 40
016 NB16817011AA BUSHING 40
017 NB168FX551AA AMPLIFIER 1 FX-551-C2-HT
018 NB168KCE3XAA BRACKET 1
019 NB168CJ2B16AA CYLINDER 4 CJ2B16-37
020 NB168MF32AA CYLINDER 2
021 NB16817014AA SEAL RING 16
022 NB168JR09WAA RETAINING RING C-TYPE 4
023 NB168JR05WAA RETAINING RING C-TYPE 80
025 NB168M10125AA ROD END 2 M10X1.25
026 NB168BM2032AA BAND 2 BM2-032
027 NB168DC73AA SWITCH 2 D-C73
028 NB168FT001AA FIXED TRESTLE 2
029 NB168AS0106SAA SPEED CONTROLLER 2 AS2201F-01-06S
030 NB16817024AA PC-PLATE 5
X001 NB168SH0406 ROUND HEAD SCREW 2 M4-L6
X003 NB168SH0518 SOKET HEAD CAP SCREW 24 M5-L18
17 FEEDER CARRIAGE SECT.(TAPA FEEDER DRIVING SECT.-2)
X003 NB168SH0518 SOKET HEAD CAP SCREW 24 M5-L18
X004 NB168SH0616 SOKET HEAD CAP SCREW 4 M6-L16
X005 NB168SH0860 SOKET HEAD CAP SCREW 4 M8-L60
X006 NB168SH0880 SOKET HEAD CAP SCREW 2 M8-L80
X007 NB168SH1020 SOKET HEAD CAP SCREW 2 M10-L20
X008 NB168HEX08 HEXAGON NUT 2 M8
X009 NB168HEX10 HEXAGON NUT 2 M10X1.25
X010 NB168FG0617 FLAT WASHER 4 6-17-H3
X011 NB168SW05 SPRING WASHER 24 5-8-H1.3
X012 NB1680312TR TOOTH ROD 8 M3-L12
X013 NB1680306TR TOOTH ROD 8 M3-L06
X014 NB168CS0306 COMBINATION SCREW 8 M3-L06
N194
序号 料号 部品名称 数量 规格 备注
A001 NB168PBS001AA PARTS BOX SECT 1
A002 NB16818001AA FRAME 1
A003 NB16818002AA FRAME 1
A004 NB16818003AA FRAME 1
001 NB16818004AA BRACKET 1
002 NB16818005AA BRACKET 1
003 NB168DJ60AA ADJUSTING BOLT 4
X001 NB168SH0612 SOKET HEAD CAP SCREW 20 M6-L12
18 PARTS BOX SECT.
N196
