NB168-Parts List 配件手册 - 第62页
序号 料号 部品名称 数量 规格 备注 001 NB16826001AA BRACKET 1 002 NB168FG0501AA FLAT WASHER 1 5-10-H1 003 NB16805037AA COLLAR 1 004 NB16805040AA BRACKET 1 005 NB16805035AB PLATE 1 006 NB16805039AA BRACKET 1 007 NB16805038AA SPRING 1 00…
序号 料号 部品名称 数量 规格 备注
001 NB16826001AA BRACKET 1
002 NB168FG0501AA FLAT WASHER 1 5-10-H1
003 NB16805037AA COLLAR 1
004 NB16805040AA BRACKET 1
005 NB16805035AB PLATE 1
006 NB16805039AA BRACKET 1
007 NB16805038AA SPRING 1
008 NB168F605ZZAA BEARING 1 F605ZZ
009 NB168625ZZAA BEARING 1 625ZZ
X001 NB168SH0518 SOKET HEAD CAP SCREW 1 M5-L18
X002 NB168SH0510 SOKET HEAD CAP SCREW 1 M5-L10
X003 NB168FG0510 FLAT WASHER 1 5-10-H2
X004 NB168HEX03 HEXAGON NUT 2 M3
X005 NB168SH0318 SOKET HEAD CAP SCREW 2 M3-L18
X006 NB168SH0408 SOKET HEAD CAP SCREW 2 M4-L8
X007 NB168FG0412 FLAT WASHER 2 4-12-H1.5
X008 NB168FG0307 FLAT WASHER 4 3-7-H0.5
X009 NB168SH0306 SOKET HEAD CAP SCREW 2 M3-L6
X010 NB168SH0310 SOKET HEAD CAP SCREW 2 M3-L8
5 LOADER SECT.(P.C.B SINGLE LEFT TO RIGHT)
N46
