序号 料号 部品名称 数量 规格 备注
028 NB16882GIUAA MOTOR 1 MSMF082L1U2M
029 NB16807027AA SUPPORT 1
030 NB16807028AA BRACKET 1
031 NB16807029AA SPACER 1
032 NB16807030AA SPRING 1
033 NB16807031AA BRACKET(SENSOR) 1
035 NB16807033AA BRACKET 1
036 NB16807034AA SHIFTER 1
037 NB16807035AA PULLEY 1
039 NB16807037AA COLLAR 1
040 NB16807038AA LOCK-NUT 1
042 NB16807039AA BUSHING 1
043 NB16807040AA SET PIECE 2
044 NB16807041AA SHAFT 1
046 NB16807043AA SPRING HOLDER 1
047 NB16807044AA PIN 1
048 NB16807045AA BRACKET 1
049 NB16807046AA BRACKET 1
050 NB16807047AA WASHER 1
053 NB168698ZZAA BEARING 2 698ZZ
054 NB1685GT420AA BELT(TIMING) 1 420-EV5GT-15
055 NB168X1R5E2AA SENSOR 1 E2E-X1R5E2
7 INSERTION HEAD SECT.(MAIN BODY SECT.-2)
055 NB168X1R5E2AA SENSOR 1 E2E-X1R5E2
056 NB168RZ36MAA CAMERA 1 USB2-36M
057 NB168M2514A LENS 1 M2514-MP2
X001 NB168SH0308 SOKET HEAD CAP SCREW 2 M3-L8
X002 NB168SH0410 SOKET HEAD CAP SCREW 2 M4-L10
X003 NB168SH0510 SOKET HEAD CAP SCREW 4 M5-L10
X004 NB168SH0512 SOKET HEAD CAP SCREW 4 M5-L12
X005 NB168SH0516 SOKET HEAD CAP SCREW 2 M5-L16
X006 NB168SH0518 SOKET HEAD CAP SCREW 6 M5-L18
X007 NB168SH0530 SOKET HEAD CAP SCREW 1 M5-L30
X008 NB168SH0625 SOKET HEAD CAP SCREW 2 M6-L25
X009 NB168SH0830 SOKET HEAD CAP SCREW 2 M8-L30
X010 NB168SS0304 SUNK SCREW 2 M3-L4
X011 NB168HEX05 HEXAGON NUT 1 M5
X012 NB168FG0515 FLAT WASHER 4 5-15-H2
X013 NB168FG0307 FLAT WASHER 2 3-7-H0.5
X014 NB168SH0312 SOKET HEAD CAP SCREW 3 M3-L12
X015 NB168SW03 SPRING WASHER 1 3-4-H1.0
X016 NB168FG0409 FLAT WASHER 2 4-9-H1.0
X017 NB168SW04 SPRING WASHER 2 4-7-H1.0
X018 NB168SW05 SPRING WASHER 16 5-8-H1.3
X019 NB168SW06 SPRING WASHER 2 6-9.5-H1.6
X020 NB168FG0821 FLAT WASHER 3 8-21-H3
N78
序号 料号 部品名称 数量 规格 备注
058 NB168AB3CAA ROTARY ENCODER 1 E6F-AB3C
059 NB16807048AA CAM 1
060 NB16807049AA CAM 1
061 NB16807050AA CAM 1
062 NB16807051AA CAM 1
063 NB16807052AA CAM 1
064 NB16807053AA CAM 1
065 NB16807054AA CAM 1
066 NB16820013AA KEY 1
067 NB168T6368AA PULLEY 1
068 NB16807057AA CAM BOX 1
069 NB16807058AA FLANGE 1
070 NB16807059AA KEY 2
071 NB16807060AB SHAFT 1
072 NB168W50E07AA REDUCTION GEAR 1 SW50E07LF-ST2
073 NB168D0425AA WASHER 1
074 NB16807062AA WASHER 1
075 NB168FU4SCAA LOCK-NUT 1 FU04SC
076 NB16807063AA KEY 1
077 NB168FU07SSAA NUT 1 FU07SS (M35X1.5)
078 NB1686007ZZAA BALL BEARING 1 6007ZZ
079 NB168GC1010AA COUPLING 1 GC-28.5X38-10X10
7 INSERTION HEAD SECT.(INSERTION POWER SECT.-1)
079 NB168GC1010AA COUPLING 1 GC-28.5X38-10X10
080 NB16807157AA FITTING 1 KS-1/4
X001 NB168SH0310 SOKET HEAD CAP SCREW 7 M3-L10
X002 NB168SH0312 SOKET HEAD CAP SCREW 4 M3-L12
X003 NB168SH0620 SOKET HEAD CAP SCREW 5 M6-L20
X004 NB168SW03 SPRING WASHER 11 3-4-H1.0
X005 NB168SH0630 SOKET HEAD CAP SCREW 14 M6-L30
X006 NB168SS0506 SUNK SCREW 2 M5-L6
X007 NB168SS0808 SUNK SCREW 6 M8-L8
X008 NB168SW06 SPRING WASHER 19 6-9.5-H1.6
N80
